FRONT ABS WHEEL-SPEED SENSOR REMOVAL/INSTALLATION

1. When removing the right front ABS wheel-speed sensor, perform the following procedure.

1. Remove the coolant reserve tank installation bolts and move the coolant reserve tank. (See

COOLANT RESERVE TANK REMOVAL/INSTALLATION [MZI-3.7] .)

2. Remove the power steering reserve tank installation bolt and nut, and move the power steering

reserve tank. (See POWER STEERING OIL PUMP REMOVAL/INSTALLATION .)

2. When removing the left front ABS wheel-speed sensor, perform the following procedure:

1. Remove the air cleaner case. (See INTAKE-AIR SYSTEM REMOVAL/INSTALLATION

[MZI-3.7] .)

3. Remove in the order indicated in the table.

Fig. 16: Identifying Front ABS Wheel Speed Sensor Connector, Front ABS Wheel Speed Sensor,
Bolt & Torque Specifications

Courtesy of MAZDA MOTORS CORP.

4. Install in the reverse order of removal.

Al

-

-

-

-

-

-

AJ

-

-

-

-

-

-

AK

Power supply
(ABS motor
operation)

Battery

Voltage

Under any
condition

B+

Wiring harness
(AK- battery)

AL

Power supply
(solenoid
operation)

Battery

Voltage

Under any
condition

B+

Wiring harness
(AL- battery)



2008 Mazda CX-9 Grand Touring

2008 BRAKES Dynamic Stability Control/Roll Stability Control - Mazda CX-9



Microsoft



Sunday, November 15, 2009 9:40:24 AM

Page 16

© 2005 Mitchell Repair Information Company, LLC.

FRONT ABS WHEEL-SPEED SENSOR INSPECTION

INSTALLATION VISUAL INSPECTION

1. Inspect the following items:

If there is any malfunction, replace the applicable part.

1. Excessive play of the ABS wheel-speed sensor

2. Deformation of the ABS wheel-speed sensor

3. Deformation or damage of the ABS sensor rotor

CLEARANCE INSPECTION

1. Verify the clearance between the ABS sensor rotor and the ABS wheel-speed sensor.

If there is any malfunction, check for improper installation, and replace if necessary.

Clearance

0.7-1.5 mm {0.028-0.059 in}



2008 Mazda CX-9 Grand Touring

2008 BRAKES Dynamic Stability Control/Roll Stability Control - Mazda CX-9



Microsoft



Sunday, November 15, 2009 9:40:24 AM

Page 17

© 2005 Mitchell Repair Information Company, LLC.

Fig. 17: Identifying Clearance Between ABS Sensor Rotor & ABS Wheel-Speed Sensor
Courtesy of MAZDA MOTORS CORP.

SENSOR OUTPUT VALUE INSPECTION

1. Turn the ignition switch off.



2008 Mazda CX-9 Grand Touring

2008 BRAKES Dynamic Stability Control/Roll Stability Control - Mazda CX-9



Microsoft



Sunday, November 15, 2009 9:40:24 AM

Page 18

© 2005 Mitchell Repair Information Company, LLC.

2. Connect the M-MDS to the DLC-2.

3. After the vehicle is identified, select the following items from the initialization screen of the M-MDS.

When using the IDS (laptop PC)

1. Select "DataLogger".

2. Select "Modules".

3. Select "ABS".

When using the PDS (Pocket PC)

1. Select "Module Tests".

2. Select "ABS".

3. Select "DataLogger".

Fig. 18: Connecting M-MDS To DLC-2
Courtesy of MAZDA MOTORS CORP.

4. Select the following PIDs using the M-MDS:

WSPD_LF

(LF ABS wheel-speed sensor)

WSPD_RF

(RF ABS wheel-speed sensor)

5. Start the engine and drive the vehicle.

6. Verify that the display of the M-MDS shows the same value as the speedometer.

If there is any malfunction, replace the front ABS wheel-speed sensor.
