Mazda CX 7. Manual - part 391
SEATS
09-13–13
09-13
6. Using an ohmmeter, verify that there is continuity
between the seat warmer unit connector
terminals when temperature drops to approx. 28
°C {82 °F}.
• If not as indicated in the table, replace the
seat warmer unit.
Seat Back
1. Remove the front seat. (See 09-13-2 FRONT SEAT REMOVAL/INSTALLATION.)
2. Remove the seat back trim. (See 09-13-2 FRONT SEAT DISASSEMBLY/ASSEMBLY.)
3. Verify that the continuity between terminals A and
B is as indicated in the table.
• If not as indicated in the table, replace the
seat warmer unit.
End Of Sie
A
B
A
B
acxuuw00000908
: Continuity
Thermostat
temperature
More than approx. 37
°
C
{99
°
F}
Less than approx. 28
°
C
{82
°
F}
Terminal
B
A
acxuuw00000909
A
B
A
B
acxuuw00000910
Under any condition
Test condition
Terminal
A B
: Continuity
acxuuw00000911
