SYMPTOM TROUBLESHOOTING
02-03–5
02-03
No.2 TPMS WARNING LIGHT (LOW PRESSURE WARNING) ILLUMINATES AFTER ENGINE START AND
TURNS OFF AFTER DRIVING FOR PERIOD OF TIME
id020300800600
Caution
• The tire pressure cannot be measured accurately after driving for a long period due to increased
internal temperature and pressure. Stop the vehicle for approx. 1 hour and then perform the tire
pressure measurement and adjustment.
• Use a high accuracy digital gauge for measurement of the tire pressure.
Note
• The tire pressure normally decreases by approx. 7 kPa {0.07 kgf/cm
2
, 1.02 psi} per month even if the
tire is normal.
• The FFD (temperature and pressure) stored when the TPMS warning light is turned on or off can be
verified by operating the M-MDS.
End Of Sie
2
TPMS warning light (low pressure warning) illuminates after engine start and turns off after driving
for a period of time.
[TROUBLESHOOTING HINTS]
• The tire pressure decreases (approaches value to illuminate TPMS warning light) when the internal temperature of the tire
is low.
STEP
INSPECTION
ACTION
1
INSPECT THE TIRE
• Is there any foreign object adhering to the
tire?
Yes
Remove any foreign object. Replace the tire if necessary,
and then go to the next step.
No
Go to the next step.
2
MEASURE THE TIRE PRESSURE WHEN THE
ENGINE IS COLD
• Has the tire pressure decreased
(approaches value to illuminate TPMS
warning light)?
Yes
Adjust the tire pressure to the specification, and then go to
the next step.
No
Go to the next step.
3
IS THE MALFUNCTION CORRECTED?
Yes
Troubleshooting completed.
No
Verify troubleshooting again and return to Step 1 if the
malfunction recurs.
