Mazda Protege 5. Manual - part 232





ON-BOARD DIAGNOSTIC

05–02–56

End Of Sie

DTC P0766

A3U050201030W28

Diagnostic procedure

DTC P0766

Shift solenoid D stuck OFF

DETECTION

CONDITION

When any of DTC P0731, P0732, and P0733 not output (correct judgment), and all conditions below are
satisfied.
— ATF temperature 20

°°°°

C {68

°°°°

F} or above.

— Driving in 4GR at D range.
— Engine run.
— Turbine speed within 225—4,988 rpm.
— Differential gear case (output) revolution speed 35 rpm or above.
— Vehicle speed 50 km/h {31 mph} or above.
— Throttle opening angle closed throttle position.
— Revolution ratio of forward clutch drum revolution to differential gear case revolution below 0.6 or 1.249

or above.

— Any of the following not generated: DTC P0500, P0705, P0706, P0710, P0715,P0751, P0752, P0753,

P0756, P0757, P0758, P0761, P0762, P0763, P0766, P0767, P0768, P0771, P0772, P0773.

Diagnostic support note:

This is a continuous monitor (CCM).

MIL illuminates if PCM detects the above malfunction conditions during two consecutive drive cycles.

PENDING CODE is available.

FREEZE FRAME DATA is available.

O/D OFF indicator light flashes.

DTC is stored in the PCM memory.

POSSIBLE

CAUSE

ATF level low

Deteriorated ATF

Shift solenoid D stuck

Control valve stuck

PCM malfunction

STEP

INSPECTION

ACTION

1

VERIFY FREEZE FRAME DATA HAS BEEN
RECORDED

Has FREEZE FRAME PID DATA been
recorded?

Yes Go to next step.

No

Record FREEZE FRAME PID DATA on repair order, then
go to next step.

2

VERIFY RELATED REPAIR INFORMATION
AVAILABILITY

Check for related Service Bulletins availability.

Is any related repair information available?

Yes Perform repair or diagnosis according to available repair

information.

If vehicle is not repaired, go to next step.

No

Go to next step.

3

CHECK ATF CONDITION

Turn ignition key to OFF.

Check ATF condition.
— Clear red: Normal
— Milky: Water mixed in fluid
— Reddish brown: Deteriorated ATF

Is it okay?

(See 05–17–17 Automatic Transaxle Fluid (ATF)
Condition Inspection.)

Yes Go to next step.

No

If ATF color milky or reddish brown, replace ATF, then go to
Step 5.
(See 05–17–18 AUTOMATIC TRANSAXLE FLUID (ATF)
REPLACEMENT.)

4

CHECK ATF LEVEL

Start engine.

Warm up ATX.

Is ATF level within specification?

(See 05–17–18 Automatic Transaxle Fluid (ATF)
Level Inspection.)

Yes Go to next step.

No

Adjust ATF level, then go to Step 7.
(See 05–17–18 Automatic Transaxle Fluid (ATF) Level
Inspection.)

1712-1U-01G(05-02).fm  56 ページ  2001年6月29日 金曜日 午後4時35分

ON-BOARD DIAGNOSTIC

05–02–57

05–02

End Of Sie

5

INSPECT LINE PRESSURE

Start engine.

Measure line pressure.

Specification
FS engine
Idle: 330—470 kPa {3.4—4.7 kgf/cm

2

, 49—66

psi}
Stall: 1,160—1,320 kPa {11.9—13.4 kgf/cm

2

170—190 psi}
ZM engine
Idle: 330—470 kPa {3.4—4.7 kgf/cm

2

, 49—66

psi}
Stall: 1,200—1,360 kPa {12.3—13.8 kgf/cm

2

175—196 psi}

Is line pressure within specification?

(See 05–17–12 Line Pressure Test.)

Yes Go to next step.

No

All ranges: Replace oil pump or control valve body, then
go to Step 7.

Any ranges: Replace ATX, then go to Step 7.

(See 05–17–31 AUTOMATIC TRANSAXLE (ATX)
REMOVAL/INSTALLATION.)
(See ATX Workshop Manual FN4A-EL (9999-95-FN4A-
99).)

6

CHECK OPERATION OF EACH VALVE AND
EACH SPRING

Turn ignition key to OFF.

Remove control valve body.

Disassemble control valve body.

Is each valve operation okay and is return
spring okay?

(See 05–17–36 CONTROL VALVE BODY
REMOVAL/INSTALLATION.)
(See ATX Workshop Manual FN4A-EL (9999-95-
FN4A-99).)

Yes Replace ATX, then go to next step

(See ATX Workshop Manual FN4A-EL (9999-95-FN4A-
99).)

No

Repair or replace shift valve and return spring, then go to
next step.
(See 05–17–36 CONTROL VALVE BODY REMOVAL/
INSTALLATION.)
(See ATX Workshop Manual FN4A-EL (9999-95-FN4A-
99).)

7

VERIFY TROUBLESHOOTING OF DTC P0766
COMPLETED

Make sure to reconnect all disconnected
connectors.

Clear DTC from memory using WDS or
equivalent.

Start engine.

Warm up ATX.

Drive the vehicle under the following conditions
and make sure that gears shift smoothly from
1GR to 4GR.
— ATF temperature: 20

°°°°

C {68

°°°°

F} or above

— Drive in D range
— Throttle opening angle (TP PID): 0% (4GR

only)

— Vehicle speed: 50 km/h {31 mph} or

above. (4GR only) (VSS PID)

Is pending code present?

Yes Replace PCM, then go to next step.

(See 01–40A–7 PCM REMOVAL/INSTALLATION [ZM].)
(See 01–40B–7 PCM REMOVAL/INSTALLATION [FS].)

No

Go to next step.

8

VERIFY AFTER REPAIR PROCEDURE

Perform “After Repair Procedure”.

(See 05–02–6 AFTER REPAIR PROCEDURE.)

Are any DTCs present?

Yes Go to applicable DTC inspection.

No

Troubleshooting completed.

STEP

INSPECTION

ACTION

1712-1U-01G(05-02).fm  57 ページ  2001年6月29日 金曜日 午後4時35分

ON-BOARD DIAGNOSTIC

05–02–58

DTC P0767

A3U050201030W29

Diagnostic procedure

DTC P0767

Shift solenoid D stuck ON

DETECTION

CONDITION

When any of DTC P0731, P0732, P0734, and P0741 are not generated, and all conditions below are
satisfied.
— ATF temperature 20

°°°°

C {68

°°°°

F} or above.

— Driving in D range.
— Engine run.
— Turbine speed within 225—4,988 rpm.
— Differential gear case (output) revolution speed 35 rpm or above.
— Revolution ratio of forward clutch drum revolution to differential gear case revolution below 0.863 or

1.249 or above.

— Any of the following not generated: DTC P0500, P0705, P0706, P0710, P0715,P0751, P0752, P0753,

P0756, P0757, P0758, P0761, P0762, P0763, P0766, P0767, P0768, P0771, P0772, P0773.

Diagnostic support note:

This is a continuous monitor (CCM).

MIL illuminates if PCM detects the above malfunction conditions during two consecutive drive cycles.

PENDING CODE is available.

FREEZE FRAME DATA is available.

O/D OFF indicator light flashes.

DTC is stored in the PCM memory.

POSSIBLE

CAUSE

ATF level low

Deteriorated ATF

Shift solenoid D stuck

Control valve stuck

PCM malfunction

STEP

INSPECTION

ACTION

1

VERIFY FREEZE FRAME DATA HAS BEEN
RECORDED

Has FREEZE FRAME PID DATA been
recorded?

Yes Go to next step.

No

Record FREEZE FRAME PID DATA on repair order, then
go to next step.

2

VERIFY RELATED REPAIR INFORMATION
AVAILABILITY

Check for related Service Bulletins availability.

Is any related repair information available?

Yes Perform repair or diagnosis according to available repair

information.

If vehicle is not repaired, go to next step.

No

Go to next step.

3

CHECK ATF CONDITION

Turn ignition key to OFF.

Check ATF condition.
— Clear red: Normal
— Milky: Water mixed in fluid
— Reddish brown: Deteriorated ATF

Is it okay?

(See 05–17–17 Automatic Transaxle Fluid (ATF)
Condition Inspection.)

Yes Go to next step.

No

If ATF color milky or reddish brown, replace ATF, then go to
Step 5.
(See 05–17–18 AUTOMATIC TRANSAXLE FLUID (ATF)
REPLACEMENT.)

4

CHECK ATF LEVEL

Start engine.

Warm up ATX.

Is ATF level within specification?

(See 05–17–18 Automatic Transaxle Fluid (ATF)
Level Inspection.)

Yes Go to next step.

No

Adjust ATF level, then go to Step 7.
(See 05–17–18 Automatic Transaxle Fluid (ATF) Level
Inspection.)

5

INSPECT LINE PRESSURE

Start engine.

Measure line pressure.

Specification
FS engine
Idle: 330—470 kPa {3.4—4.7 kgf/cm

2

, 49—66

psi}
Stall: 1,160—1,320 kPa {11.9—13.4 kgf/cm

2

170—190 psi}
ZM engine
Idle: 330—470 kPa {3.4—4.7 kgf/cm

2

, 49—66

psi}
Stall: 1,200—1,360 kPa {12.3—13.8 kgf/cm

2

175—196 psi}

Is line pressure within specification?

(See 05–17–12 Line Pressure Test.)

Yes Go to next step.

No

All ranges: Replace oil pump or control valve body, then
go to Step 7.

Any ranges: Replace ATX, then go to Step 7.

(See 05–17–31 AUTOMATIC TRANSAXLE (ATX)
REMOVAL/INSTALLATION.)
(See ATX Workshop Manual FN4A-EL (9999-95-FN4A-
99).)

1712-1U-01G(05-02).fm  58 ページ  2001年6月29日 金曜日 午後4時35分

ON-BOARD DIAGNOSTIC

05–02–59

05–02

End Of Sie

6

CHECK OPERATION OF EACH VALVE AND
EACH SPRING

Turn ignition key to OFF.

Remove control valve body.

Disassemble control valve body.

Is each valve operation okay and is return
spring okay?

(See 05–17–36 CONTROL VALVE BODY
REMOVAL/INSTALLATION.)
(See ATX Workshop Manual FN4A-EL (9999-95-
FN4A-99).)

Yes Replace ATX, then go to next step

(See ATX Workshop Manual FN4A-EL (9999-95-FN4A-
99).)

No

Repair or replace shift valve and return spring, then go to
next step.
(See 05–17–36 CONTROL VALVE BODY REMOVAL/
INSTALLATION.)
(See ATX Workshop Manual FN4A-EL (9999-95-FN4A-
99).)

7

VERIFY TROUBLESHOOTING OF DTC P0767
COMPLETED

Make sure to reconnect all disconnected
connectors.

Clear DTC from memory using WDS or
equivalent.

Start engine.

Warm up ATX.

Drive the vehicle under the following conditions
and make sure that gears shift smoothly from
1GR to 4GR.
— ATF temperature: 20

°°°°

C {68

°°°°

F} or above

— Drive in D range

Is pending code present?

Yes Replace PCM, then go to next step.

(See 01–40A–7 PCM REMOVAL/INSTALLATION [ZM].)
(See 01–40B–7 PCM REMOVAL/INSTALLATION [FS].)

No

Go to next step.

8

VERIFY AFTER REPAIR PROCEDURE

Perform “After Repair Procedure”.

(See 05–02–6 AFTER REPAIR PROCEDURE.)

Are any DTCs present?

Yes Go to applicable DTC inspection.

No

Troubleshooting completed.

STEP

INSPECTION

ACTION

1712-1U-01G(05-02).fm  59 ページ  2001年6月29日 金曜日 午後4時35分
