|
|
09–80E–8 BODY STRUCTURE [PLASTIC BODY PARTS] 14—16 seconds/viscosimeter 20 °C {68 °F} Note • Mix the solutions at the specified ratio. c. Spray pressure 300—400 kPa {3—4 kg/cm 2 , 43—57 psi} d. Standard film thickness 30—40 µ e. Spray method Spot-spray primer surfacer on bumper three of four times 12. Air drying 20 °C {68 °F} — 8 hours minimum. Forced drying 60 °C {140 °F} — 1 hour 13. Lightly sand the complete surface of the bumper with #400—#600 sandpaper. Do not expose the surface of the polypropylene. (Wet or dry sanding is acceptable.) 14. Wipe the complete surface of the bumper with degreasing agent. Quickly wipe the surface with a clean rag to degrease it. 15. Apply a matching coat of body color to the polypropylene bumper. Note • Be sure to use only urethane primer for a urethane bumper and polypropylene primer for a polypropylene bumper. Other paints for repairing a polypropylene bumper are the same as those for the urethane 16. Air drying 20 °C {68 °F} — 8 hours minimum. Forced drying 60 °C {140 °F} — 1 hour Note • Let the part air dry when possible as forced drying could cause bubbles in the top coat. End Of Sie PLASTIC LIFTGATE DPE098062010B01 Characteristics of Plastic Liftgate • The material for the outer panel of the liftgate is polycarbonate; acrylonitrile-butadience styrene resin (ABS- resin), and the material for the inner panel is glass fiber; polypropylene. • The liftgate has a bonded structure of outer and inner panels. Configuration of Shipped Parts • The liftgate is shipped with the rear No.2 wiring harness and the complex antenna assembled and bonded. • The outer panel surface of the liftgate is not painted. However, it is coated with primer like a bumper. • A hole cover is affixed to the back monitor camera installation hole on the outer panel with double-sided adhesive tape. A waterproof pad is affixed to the back monitor camera installation hole on the inner panel. Repair Points • Scratches are repairable. Holes and cracks are not repairable. Urethane primer surfacer Softener Hardner Mixture A Mixture B 100 30 4 1 YMU980PD2 |
