BODY STRUCTURE [DIMENSIONS]

09–80D–11

09

End Of Sie

ROOM STRAIGHT-LINE DIMENSIONS (2)

DPE098070001B02

.

H-H'

I-I'

A

B

C

D

E

F

G

1,364

{53.70}

{46.73}

{38.23}

{62.01}

{28.58}

{46.46}

{60.71}

{65.35}

1,660

1,542

1,180

1,575

1,187

971

726

{in}

mm

DPE0980B020

A

B

C

D

E

F

G

H

I

Fr

Fr

Fr

Fr

Fr

Fr

Fr

Fr

Fr

DPE0980B021

09–80D–12

BODY STRUCTURE [DIMENSIONS]

End Of Sie

ROOM STRAIGHT-LINE DIMENSIONS (3)

DPE098070001B03

Point

symbol

Designation

Hole diameter

or bolt or nut

size mm {in}

A

Adjuster installation hole

ø16 {0.63}

B

Trim installation hole

ø10.2 {0.40}

C

Harness installation slot

ø7 x 10

{0.28 x 0.39}

D

Center floor pan datum hole

ø11 {0.43}

E

Trim installation square hole

10 x 15

{0.39 x 0.59}

F

Trim installation hole

ø8.6 {0.34}

G

Harness installation hole

ø7 {0.28}

H

Female wedge installation
hole

ø10 {0.39}

I

Female wedge installation
hole

ø10 {0.39}

Point

symbol

Designation

Hole diameter

or bolt or nut

size mm {in}

A

B

H-H'

C

D

E

F

G

{in}

mm

1,130

972

1,576

741

1,205

{29.17}

{62.05}

{38.27}

{44.49}

{47.44}

{38.19}

{41.57}

1,056

970

DPE0980B022

BODY STRUCTURE [DIMENSIONS]

09–80D–13

09

.

End Of Sie

Fr

A

B

C

D

E

F

G

H

Fr

Fr

Fr

Fr

Fr

Fr

Fr

DPE0980B023

Point

symbol

Designation

Hole diameter

or bolt or nut

size mm {in}

A

Trim installation square hole

10 x 15

{0.39 x 0.59}

B

Trim installation hole

ø8.6 {0.34}

C

Harness installation hole

ø7 {0.28}

D

Rear floor pan datum hole

ø16 {0.63}

E

Trim installation hole

ø8.6 {0.34}

F

Trim installation hole

ø8.6 {0.34}

G

Trim installation square hole

8 x 28

{0.31 x 1.10}

H

Striker installation hole

ø8.2 {0.32}

Point

symbol

Designation

Hole diameter

or bolt or nut

size mm {in}

09–80D–14

BODY STRUCTURE [DIMENSIONS]

REAR BODY STRAIGHT-LINE DIMENSIONS

DPE098070002B01

.

A

B

C

D

E

E'

B'

C'

A'

D'

{in}

mm

253

1,248

974

778

770

754

700

{50.31}

{48.11}

{38.35}

{49.13}

{30.63}

{29.69}

{30.31}

{9.96}

{51.77}

{51.34}

{27.56}

1,304

1,315

1,278

1,222

DPE0980B024

A

E'

B

C

D

E

Fr

Fr

Fr

Fr

Fr

Fr

DPE0980B025

Point

symbol

Designation

Hole diameter

or bolt or nut

size mm {in}

A

Liftgate installation hole

ø14 {0.55}

B

Rear combination light
installation hole

ø8.5 {0.33}

C

Rear pillar outer datum hole

ø12 {0.47}

D

Trim installation square hole

8 x 23

{0.31 x 0.91}

E

Rear end panel datum hole

ø20 {0.79}

E’

Rear end panel datum hole

ø20 x 24

{0.79 x 0.94}

Point

symbol

Designation

Hole diameter

or bolt or nut

size mm {in}
