BODY STRUCTURE [PANEL REPLACEMENT]

09–80B–7

09

End Of Sie

SHROUD UPPER REINFORCEMENT REMOVAL

DPE098053152B01

1. Remove the shroud upper reinforcement.

Note

• When removing the shroud upper reinforcement and the front fender bracket separately, drill the 2

locations indicated by (A).

• Weld locations (B) in the figure indicate the same locations.

10

1

4

8

3

2

COWL SIDE REINFORCEMENT

DPE0980B053

09–80B–8

BODY STRUCTURE [PANEL REPLACEMENT]

End Of Sie

SHROUD UPPER REINFORCEMENT INSTALLATION

DPE098053152B02

1. When installing new parts, measure and adjust the body as necessary to conform with standard dimensions.
2. Drill holes for plug welds before installing new parts.
3. After temporarily installing new parts, make sure the related parts fit properly.

Note

• When replacing the shroud upper reinforcement and the front fender bracket separately, weld the 2

locations indicated by (A).

1

(B)1

(A)1

(B)1

(A)1

1

1

4

7

3

SHROUD UPPER REINFORCEMENT

FRONT FENDER BRACKET

DPE0980B054

BODY STRUCTURE [PANEL REPLACEMENT]

09–80B–9

09

End Of Sie

APRON REINFORCEMENT (LOWER) REMOVAL

DPE098053260B01

1. Drill the 1 location indicated by (A) from the engine compartment, as they cannot be seen from the outer side.
2. Remove the apron reinforcement (lower).

Note

• Weld locations (B) in the figure indicate the same locations.

1

1

(A)1

(A)1

1

1

4

7

3

SHROUD UPPER REINFORCEMENT

DPE0980B055

09–80B–10

BODY STRUCTURE [PANEL REPLACEMENT]

End Of Sie

APRON REINFORCEMENT (LOWER) INSTALLATION

DPE098053260B02

1. When installing new parts, measure and adjust the body as necessary to conform with standard dimensions.
2. Drill holes for plug welds before installing new parts.
3. After temporarily installing new parts, make sure the related parts fit properly.

5

2

1

12

(B)3

(A)1

(B)3

APRON REINFORCEMENT (LOWER)

DPE0980B056
