CHASSIS AND BODY 63 REPAIR CHASSIS NON AMERICAN - 1990 ONWARDS Alignment check - RR2751M Diagram reference millimetres AA Wheelbase reference dimension 2540,00 .......................................... BB Centre line of front axle CC Centre line of rear axle DD Frame datum line EE Side member datum line FF Datum line 1 264,525 ............................................................................................. ± 1,27 2 Frame datum to underside of cross-member 150,80 ......................... 3 266,70 ............................................................................................... ± 2,54 4 237,74 ............................................................................................... ± 1,27 5 327,81 ............................................................................................... ± 2,54 6 979,94 ............................................................................................... 7 2179,73 ............................................................................................. ± 2,54 8 291,74 ............................................................................................... ± 2,54 9 707,96 ............................................................................................... ± 2,54 10 1468,49 ............................................................................................. ± 2,54 11 1025,27 ............................................................................................. ± 2,54 12 338,84 ............................................................................................... ± 2,54 13A 222,25 ............................................................................................... ± 2,54 13B 252,984 ............................................................................................. ± 2,54 14 Reference dimension 824,92 ............................................................. 15 To face of boss (both sides) 935,43 ................................................... ± 2,54 16 838,2 ................................................................................................. ± 0,38 17 Check figure 630,94 ........................................................................... ± 1,27 18 344,17 ............................................................................................... ± 1,27 19 485,77 ............................................................................................... ± 2,54 20 485,77 ............................................................................................... ± 2,54 21 828,68 ............................................................................................... ± 0,38 22 129,03 ............................................................................................... ± 2,54 23 2479,45 ............................................................................................. ± 0,25 24 1290,34 ............................................................................................. ± 0,38 25 1657,04 ............................................................................................. ± 0,38 26 2598,44 ............................................................................................. ± 0,38 27 79,09 ................................................................................................. ± 0,38 28 465,48 ............................................................................................... ± 2,54 29 1398,88 ............................................................................................. ± 0,38 30 Reference dimension 635,00 ............................................................. |
