Range Rover 2. Electrical Manual - part 184

PREMIUM RADIO

E6

20

CIRCUIT DIAGRAM

ADD: 11/99

B

S215

E0562

See Ground
Distribution

5

C0082

PB

2

Y

C0257

1

RY

K177
Driver’s Air Bag

Z119
Rotary Coupler

Z151
SRS Diagnostic
Control Unit

11

C0256

10

X269
Steering Wheel
Switches

[1]

Increase

[2]

Decrease

[3]

Mode Select

[4]

Volume Up

[5]

Volume Down

[6]

Reset/Decel

[7]

Set/Accel

[8]

Horn

6

C1254

PB

[8]

0

[1]

0

[2]

0

[3]

0

[4]

0

[5]

0

[6]

0

[7]

0

390

Ω

470 k

Ω

820 k

Ω

15 k

Ω

Z119
Rotary Coupler

4

2

3

C1254

LGR

W

R

2

C0082

5

Y

1

3

4

LGR

W

R

Y

Horns

Z249
Cruise Control
Converter/Inverter
Module

5

C0895P

6

Z111
Radio

2

C0098

C0895D

Petrol

Diesel

YR

YS

PB

SO

Premium Radio

PREMIUM RADIO

E6

21

CIRCUIT DIAGRAM

ADD: 11/99

Premium Radio

Z293
DSP Amplifier

4

3

4

YG

3

1

C0688L

2

C0688L

K202
Left Front Bass
Speaker

33

34

YW

1

C0369L

2

C0369L

K200
Left Front
Midrange
Speaker

C1367

C1380L

C0491

S755L

S754L

1

C0530L

2

C0530L

K197
Left Front
Tweeter

GY

WY

2

1

PREMIUM RADIO

E6

22

CIRCUIT DIAGRAM

ADD: 11/99

Premium Radio

Z293
DSP Amplifier

25

24

4

BG

3

1

C0688R

2

C0688R

K203
Right Front
Bass Speaker

11

12

6

BW

5

1

C0369R

2

C0369R

K201
Right Front
Midrange
Speaker

C0310

C0308

C0491

S755R

S754R

1

C0530R

2

C0530R

K198
Right Front
Tweeter

GB

WB

4

3

2

1

C1369

C1380R

PREMIUM RADIO

E6

23

CIRCUIT DIAGRAM

REV: 09/2001

Premium Radio

Z293
DSP Amplifier

2

1

2

UG

1

1

C0726L

2

C0726L

K209
Left Rear Bass
Speaker

31

32

6

WU

5

1

C0445L

2

C0445L

K211
Left Rear Mi-
drange Speaker

C1362

C1387L

C0491

GU

UW

C1360

C1386L
