SIDE LAMPS

H4

CIRCUIT OPERATION

1

CIRCUIT OPERATION

Side lamps:

Activation of the side lamp switch, when the ignition
key is in, when the ignition is on, or when the head
lamp switch is on, will result in the operation of the
following; front LH and RH side lamps, rear LH and
RH side lamps, number plate lamps, lamps on warn-
ing lamp and the rear door switch pack illumination.

The following lamps will also operate through the
activation of the side lamp switch:

Clock, fascia switch pack, console switch pack, gear
select assembly, instrument pack, front cigar lighter,
Hevac panel switches and I.C.E. (remote telephone
dial, when fitted).

Parking lamps:

With the ignition and auxiliary off, the key out and the
headlamp switch in the side lamp position, the park-
ing lamps will be activated according to the position
of the direction indicator switch as follows:

D

If the indicator switch is in the central position,
then all the side lamps will be on.

D

If the indicator switch is in the RH position, then
the front right and rear right side lamps will be
on.

D

If the indicator switch is in the LH position, then
the front left and rear left side lamps will be on.

If the headlamp switch is set to the headlamp posi-
tion, then normal side lamps will operate in conjunc-
tion with the headlamps.

Side lamp Warning lamps:

The side lamp warning lamp will be active whenever
the side lamp switch is on and the side lamps are
operating in side lamp mode, but not when the key is
removed and the parking lamp mode is on.

SIDE LAMPS

H4

2

CIRCUIT DIAGRAM

Z238
Body Electrical
Control Module
(BECM)

S205

4

C242

14

Z142
Instrument
Cluster
[15] Control Unit

and Message
Centre Dis-
play

[15]

8

18

14

5

2

12

2

10

3

13

1

9

5

15

11

17

7

Z238
Body Electrical
Control Module
(BECM)

9

X145
Main Lighting
Switch
[1]

Side Lamps

C257

S208

E252

1

C219

0

[1]

E254

7

C258

C242

C256

3

3

C219

P

P

B

B

BG

BG

RG

RG

OG

OG

LG

LG

OR

B

30

F 1
10 A

See Ground Dis-
tribution

See Fuse Details

SIDE LAMPS

H4

3

CIRCUIT DIAGRAM

E154

S101

Z238
Body Electrical
Control Module
(BECM)

5

C120

9

C113

B115
Left Front Lamp
Assembly
[1]

Direction In-
dicator Lamp

[2]

Side Lamp

1

C158B

[2]

[1]

2

C158B

3

B116
Left Headlamp
[1]

Side Lamp

6

C163

5

C163

[1]

NAS

Except NAS

E181

S111

B128
Right Front Lamp
Assembly
[1]

Direction In-
dicator Lamp

[2]

Side Lamp

1

C187B

[2]

[1]

2

C187B

3

B130
Right Headlamp
[1]

Side Lamp

6

C189

5

C189

[1]

NAS

Except NAS

NAS

NAS

Direction Indi-
cator Lamps

Direction Indica-
tor Lamps

RW

B

B

GR

RB

GW

B

B

See Ground Dis-
tribution

See Ground Dis-
tribution

SIDE LAMPS

H4

4

CIRCUIT DIAGRAM

Z238
Body Electrical
Control Module
(BECM)

RB

12

17

GP

C361

3

2

C366

14

GR

4

E367

C366

B

1

S356

[1]

[2]

[3]

B175
Left Rear Lamp
Assembly
[1]

Direction

[2]

Tail

[3]

Stop

RW

10

12

GP

C325

3

4

C316

4

GW

2

E322

C316

B

1

S301

[1]

[2]

[3]

B176
Right Rear Lamp
Assembly
[1]

Direction

[2]

Tail

[3]

Stop

GP

RW

Trailer Auxiliary
Socket

See Ground Dis-
tribution

See Ground Dis-
tribution
