Compact disc player

246

L

EJECTING COMPACT DISCS

It is only possible to eject a single disc, if it is
currently selected or playing.

To eject a disc, press and release the eject
button. A confirmation message will be shown
on the information display. After a short pause,
the disc will be presented. The disc should then
be removed.

Note: If the disc is not removed from the slot
within fifteen seconds, it will be drawn back
into the player.

EJECTING MULTIPLE COMPACT
DISCS

All the discs loaded in the player can be ejected
in sequence. To eject all of the discs, press and
hold the eject button. A confirmation message
will be shown on the information display. After
a short pause, the first disc will be presented.
The disc should then be removed.

The discs will be ejected one at a time with a
short pause in between each.

To stop the process, press any CD number
button (1 to 6).

COMPACT DISC SELECTION

To select one of the loaded discs, briefly press
the disc number required (1 to 6). If the
position selected does not contain a disc, there
will be a pause and a message will appear on
the information display.

Once a disc has been inserted, there will be a
pause while the player reads the disc
information. Playback will then begin at the
start of track one.

COMPACT DISC PLAYBACK

To start compact disc playback, briefly press
the CD mode button, followed by the disc
number required. If no disc number is selected,
playback will begin at one of two places:
• If the discs have not been removed since

their last use, playback will begin from the
point at which it was stopped previously.

• If the discs have not been used since they

were inserted, playback will begin at the
start of the first loaded disc.

TRACK SELECTION

Premium audio

Standard audio

To return to the start of a track, or skip to the
next track during playback, press and release
the appropriate button.

COMPACT DISC PAUSE

To pause or stop compact disc playback,
briefly press one of the other mode buttons,
AM or FM for example. Press the CD button to
continue playback.

On premium audio units, CD play will also
pause when the volume is turned down to 0
Play will resume when the volume is turned
back up.

E83962

E83961

247

Compact disc player

R

FAST FORWARD/REVERSE

Premium audio

Standard audio

To search forwards or backwards through the
current track, press and hold the relevant
search button.

COMPACT DISC FUNCTION MENU

Depending on the specification of the audio
unit, the following extra functions are available
using the compact disc function menu:
• Random
• CD text
• CD scan
• Repeat
• TA
• News

Select compact disc mode, then briefly press
the MENU button. Use the rotary control to
select CD settings. Press the rotary control to
confirm selection. Use the rotary control to
select the required function and press to
confirm selection. Rotate the control to enable
or disable the function.

COMPACT DISC DISPLAY OPTIONS

Some compact discs, including MP3 files, have
information which can be displayed on the
premium audio display screen. Instead of the
track number, it is possible to view the track
title with the CD text function enabled.

To enable or disable the CD text function, select
compact disc mode, then briefly press the
MENU button. Use the rotary control to
highlight CD settings and press to confirm
selection. Using the rotary control, select CD
TEXT
 from the menu. Rotate the control to
select On or Off and press to confirm selection.

SHUFFLE/RANDOM

Random alters the playback sequence for the
loaded discs. The tracks are selected randomly
by the player.

E83964

E83963

100.7

1

1 2 3 4

6

CD 1

Track

   1

00:01



  1:51

P

PTY

1

E82981

Compact disc player

248

L

Random selection - Premium audio

1. Press the Menu button to access the

menu.

2.  Use the rotary control to select Random

and press to confirm selection.

3. From the following menu, use the rotary

control to select OffAll discs or Single
disc
. Press the control to confirm
selection. Press the EXIT button to return
to the previous menu.

Note: When All discs is selected, the system
will ignore MP3 discs and only play standard
audio discs.

Random selection - Standard audio

1. Press the Menu button to access the

menu.

2.  Use the rotary control to select Random.

3. Press the rotary control to enable or

disable the function as required.

REPEAT COMPACT DISC TRACKS

Repeat allows the current track to play
repeatedly until it is stopped or cancelled.

Note: This feature is only available on standard
audio units.

1. Press the MENU button to view the menu.

2. Use the rotary control to select Repeat and

press the control to enable the function.

3. To disable the function, rotate the menu

control to select Repeat and press the
control. Pressing the C button, the next
track or previous track buttons will also
disable the function.

COMPACT DISC TRACK SCANNING

Compact disc track scan allows you to sample
the music on a compact disc. This feature plays
the first ten seconds of each track in numerical
order. Play will then begin at the start of track
one.

CD scan - Premium audio

Press the SCAN button to enable this function.

EXIT

SELECT

EXIT

SELECT

Random..

CD settings..

Single disc

All discs

Off

E83264

Repeat

CD Scan

Load All

E84068

PTY

1

1 2 3 4

6

CD 2

Track

4

         00:06

            2:04

P

1

2

Scan

E82983

249

Compact disc player

R

To disable the function, and to continue the
currently playing track, press the SCAN or EXIT
button again.

Note: While in CD scan mode, pressing the
previous track button will resume normal play
at the current track. Pressing the next track
button will move to the next track and resume
normal play.

CD Scan - Standard audio

1. Press the MENU button to access the

functions menu.

2. Use the rotary control to select CD Scan.

3. Press the rotary control to enable or

disable the function.

Note: While in CD scan mode, pressing the
previous track button will resume normal play
at the current track. Pressing the next track
button will move to the next track and resume
normal play.

MP3 FILE PLAYBACK

Note: Standard audio units do not have the
facility to play MP3 files.

When a data disc (containing MP3 encrypted
music data) is inserted into the compact disc
slot, MP3 will appear at the top of the display.

The disc will play the tracks in the order they
appear on the disc.

All folder information is ignored and the tracks
are numbered as they are ordered.

If you wish to navigate through folders to select
specific tracks, press the rotary control to
access the file structure. Use the rotary control
to highlight the required folder or track and
press to select.

If an MP3 recording is made with a
compression rate lower than 128k some Digital
Signal Processing (DSP) functionality may be
lost.

To make sure that the best sound quality is
achieved the instructions or information
provided with the recording software should be
read carefully and adhered to.

1

1 2 3 4

6

CD 3

Track

   45

00:06



  2:04

P

PTY

1

3

2

MP3

E82984

EXIT

SELECT

Artist name 1

PTY..

Artist name 2

Artist name 3

EXIT

SELECT

PTY..
01 Track name

02 Track name

E83753
