Frelander 2. Manual - part 741

Digital audio broadcasting

242

L

From the DAB settings menu, choose DAB
radio text. Rotate the menu control and press
to select one of the following:

• Ensemble name to display the name of the

ensemble to which the current channel
belongs.

• PTY to display the name of the ensemble to

which the current channel belongs.

• Off to display only the channel name.

Advanced settings

From the DAB settings menu, choose
Advanced settings. Use the menu control to
navigate the menu options below.

Link DAB

Some DAB channels are broadcast in a number
of different ensembles. For example, some
national channels may broadcast a number of
regional variations of the same channel under
different ensembles.

EXIT

SELECT

Ensemble name
PTY
Off

EXIT

SELECT

Auto-tune

DAB radio text

Advanced settings

E88136

E88137

14 : 54

1 2 3 4

DAB1 [1]
BBC 5LIVE
BBC National DAB

E88138

14 : 54

1 2 3 4

DAB1 [1]
BBC 5LIVE
Sport

E88139

14 : 54

1 2 3 4

DAB1 [1]

BBC 5LIVE

EXIT

SELECT

DAB radio text

Advanced settings

FM traffic

E89492

243

Digital audio broadcasting

R

If the Link DAB setting is switched on and the
signal strength for a channel falls below an
acceptable level, the audio unit will
automatically search other available ensembles
for a channel with the same name.

If an alternative local channel is found, then the
message Switching ensemble is displayed and
the new channel is played automatically after
few seconds. If the channel is not found after a
few seconds, the message No signal is
displayed.

DAB country

If you move the vehicle to a different country,
you can change DAB country setting to make
sure that the audio unit gives the best possible
reception and sound quality. Rotate the menu
control to highlight the new country in the list.
Press and release the menu control to check
the box next to the selected country.

Note: When you change the DAB country, the
audio unit automatically starts auto-tuning.
See CHANNEL AUTOMATIC TUNING
(page 236).

EXIT

SELECT

Link DAB

DAB country
Band selection

EXIT

SELECT

On

Off

E88140

E88141

EXIT

SELECT

Link DAB

DAB country

Band selection

EXIT

SELECT

Australia

Austria
Belgium

Digital audio broadcasting

244

L

Band selection

Different regions or countries may use different
digital bands to broadcast DAB channels. If you
know the band(s) required then you can
choose from the Band selection menu. The
available bands are:
• LBand
• BandIII
• LBand & BandIII
• LBandCanada
• LBandCan & BandIII

Reset DAB settings

If you want to reset the DAB settings to the
manufacturer's defaults, use the menu control
to choose the Reset DAB settings menu
option. Press the menu control again to
confirm the reset.

FM traffic and news

The FM traffic function detects the presence of
local travel announcements, while the FM news
function detects local news announcements.
As soon as an announcement is received, radio
reception or CD play is interrupted. At the end
of the announcement, radio or CD play will
resume. You can use this menu option to turn
announcements on or off.

From the DAB settings menu, choose FM
traffic or FM news and then press and release
the menu control to select either On or Off. To
cancel a traffic or news announcement and
return to the digital channel, press and release
the EXIT button. Cancelling an announcement
temporarily will not prevent further
announcements from broadcasting when they
become available.

Note:

Both traffic and news information can be
selected at the same time. However, the audio
unit will always give priority to traffic
information.

Note:

Traffic and news announcements are not
currently available from DAB services, so the
audio unit switches to an FM channel just for
the duration of the announcement, so there
may be some temporary loss of sound quality.

EXIT

SELECT

Advanced settings

FM traffic

FM news

EXIT

SELECT

On

Austria

Off

E88142

245

Compact disc player

R

Compact disc player

LOADING COMPACT DISCS

Note: Some music CD manufacturers are
using data encryption to copy-protect their
recordings and prevent the production of
counterfeit copies. These CDs differ from the
internationally agreed CD audio standard,
RedBook, a standard that serves as the
operating basis for all CD players and
changers. Copy-protected CDs may fail to play
in your CD changer or may be played subject to
various limitations, e.g. sound quality may be
impaired. If you do experience a problem, try
the CD in other players before contacting the
CD vendor.

Loading a CD - Single disc player

To insert a disc into the player, make sure that
the label side of the disc is facing upwards and
present the disc to the slot. Ease the disc into
the slot until the mechanism takes over and
draws the disc in fully.

Loading a CD - Six disc player

Press the CD mode button, then press the
numbered button of the position in which the
compact disc is to be stored (1 to 6).

Make sure that the label side of the disc is
facing upwards then, when prompted, partially
insert the disc. The player mechanism will draw
the disc in automatically and the disc number
will appear on the display.

Note: If there is a problem with a disc that has
been loaded (inserted upside down, wrong
format etc.), Disc unreadable or Disc error will
appear in the information display, and the disc
will be ejected. If the problem can be corrected
(disc upside down for example), then re-insert
the disc in the correct manner. If the problem
cannot be rectified, do not re-insert the disc.

There will be a pause while the player reads
information from the disc, then play will start at
the first track.

To load another CD, press another numbered
button (1 to 6) and repeat the loading
procedure.

Note: The six circles in the top right-hand side
of the information display of the premium unit,
represent the six available CD positions. As
soon as a CD is loaded, its number will appear
in the circle.

Load all

This feature is only available on the standard
audio, six disc CD player.

1. Press and hold the CD button until Load

All appears on the display.

2. When prompted, partially insert the first

disc. The player mechanism will draw the
disc in automatically.

3. When prompted, continue to insert discs

until all six discs have been loaded. When
fully loaded, the CD player will commence
playing CD1.

CAUTION

Do not force the disc into the slot.

CAUTION

Do not use discs with paper labels, Dual
Discs or DVDPlus discs. The front
loading CD player may load and play this

type of disc, however, it is likely that the disc
will not eject and will block the CD mechanism.
Such damage to a CD player will not be
covered under warranty.
