Frelander 2. Manual - part 737





Audio unit operation

226

L

STATION PRESET BUTTONS

Premium audio

Standard audio

To store a station, press either of the search
buttons to find the next available station.
Having tuned to the desired station, press and
hold the preset number under which you would
like the station stored.

The audio output will be muted when the
button is pressed, and dependent on
specification, accompanied by the message
Station stored.

Premium audio

Standard audio

To access the stored stations, press and
release the required preset number.

TRAFFIC INFORMATION CONTROL

The Traffic Announcement (TA) feature detects
the presence of local travel announcements,
providing information on local conditions. As
soon as a traffic announcement is received,
radio reception or CD play is interrupted. At the
end of the traffic announcement, radio or CD
play will resume.

Press and release the INFO button to switch TA
on or off.

To cancel an announcement, briefly press the
EXIT or C button.

2

100.7

1 2 3 4

6

NEWS

FM1

1:29

P

TA

88.3

PTY

E82929

88. 3

FM1

14 : 54

E83957

100.7

1 2 3 4

6

NEWS

FM1

1:29

P

TA

89.5

PTY

2

E82930

BBC R2

2

FM1

14 : 54

E83958

227

Audio unit operation

R

Traffic Programme (TP) preference

With the Traffic Announcement (TA) feature
enabled, any announcement received by the
system will interrupt normal radio reception or
CD play. The TP preference feature on premium
audio units allows the system to receive only
traffic announcements from a particular
station.

1. With the preferred station selected, press

the MENU button.

2. Use the rotary control to select FM

Settings and press to confirm.

3. Use the rotary control to highlight

Advanced settings and press to select.

Note: The Advanced settings menu is not
available while the vehicle is moving.

4.  Rotate the control until TP station is

selected and press to confirm selection.

5. When the station name or frequency is

displayed along with the message Receive
TA from this station only?
, press the
rotary control to confirm.

EXIT

SELECT

PTY..

Advanced settings..

EXIT

SELECT

TP station..

News station..

EXIT

SELECT

FM settings..

Clock..

E83273

EXIT

SELECT

Classic
Receive TA from
this station only?

Audio unit menus

228

L

Audio unit menus

RADIO DATA SYSTEM (RDS)

Your audio system is equipped with RDS
(Radio Data System), which enables the audio
unit to receive extra information with the
normal radio signals.

On the FM waveband, RDS enables the audio to
receive traffic and news information
broadcasts. RDS also allows the audio unit to
automatically retune to stations that are linked
to the same network.

Note: Not all FM radio stations broadcast RDS.
If a non-RDS station is selected, RDS features
will not be available.

Selecting RDS

On standard audio units, RDS can be enabled
or disabled, according to preference. The
following procedure explains how to switch
RDS on or off.

1. With FM1FM2 or FMa selected, press the

MENU button to display the menu.

2. Using the rotary control, select RDS from

the menu. ON or OFF will be displayed,
dependent on status.

3. Press the rotary control to change status.

The RDS status will be displayed briefly on the
information screen.

REGIONAL MODE (REG)

As you drive into different radio reception
areas, the Radio Data System (RDS)
automatically retunes the radio to the strongest
signal. Regional mode is an RDS feature which
stops the system from tuning to another local
radio station with a stronger signal. With this
feature enabled, your selected local radio
station will remain tuned.

Regional mode - Premium audio

1. With FM1FM2 or FMA selected, press the

MENU button.

2. Use the rotary control to select FM

Settings and press to confirm selection.

3. Use the rotary control to select Advanced

settings from the menu and press to
confirm selection.

EXIT

SELECT

PTY..

Advanced settings..

EXIT

SELECT

EON..

Regional..

Reset settings..

EXIT

SELECT

FM settings..

Clock..

On

Off

E83261

EXIT

SELECT

229

Audio unit menus

R

Note: The Advanced settings menu is not
available while the vehicle is moving.

4. From the next menu select Regional and

press to confirm selection.

5.  To enable Regional mode, rotate the

control until On is selected and press to
confirm selection.

Regional mode - Standard audio

1. With FM1FM2 or FMa selected, press the

MENU button to display the menu.

2. Using the rotary control, select Regional

from the menu. ON or OFF will be
displayed, dependent on status.

3. Press the rotary control to change status.

The regional status will be displayed briefly on
the information screen.

ENHANCED OTHER NETWORK
(RDS-EON)

The Enhanced Other Network (EON) feature will
tune to any radio station of the same station
network as the one that you are listening to,
once the signal gets weak.

Either local or distant networks can be selected
by the EON feature.

1. With FM1FM2 or FMA selected, press the

MENU button.

2. Use the rotary control to select FM

Settings and press to select.

3. Use the rotary control to select Advanced

settings and press to confirm selection.

Note: The Advanced settings menu is not
available while the vehicle is moving.

4. Use the rotary control to select EON and

press to confirm selection.

5. To enable or disable the EON mode, rotate

the control to select Off, Local or Distant
and press to confirm selection.

ALTERNATIVE FREQUENCIES

As the Radio Data System (RDS) receives
information about the frequencies being used
by nearby transmitters, it can choose the
strongest signal for the selected station. With
the Alternative Frequencies (AF) feature
enabled, you will not need to retune the radio
as you drive between different transmitter
areas.

EXIT

SELECT

AF..

EON..

Regional..

Off

Local

Distant

E83263

EXIT

SELECT
