Vehicle identification

210

L

Vehicle identification

VEHICLE IDENTIFICATION PLATE

The Vehicle Identification Number (VIN) and
recommended maximum vehicle weights, are
stamped on a plate rivetted to the lock side of
the left-hand (right hand in China) front door
aperture at the bottom. VIN should match the
VIN recorded in the Service Portfolio, and the
VIN visible through the front windscreen.

VEHICLE IDENTIFICATION NUMBER
(VIN)

As a deterrent to thieves, and to assist the
Police, the VIN is stamped on a plate which is
visible through the lowest part of the left side of
the windscreen.

Note: If you need to communicate with a Land
Rover Dealer/Authorised repairer, you may be
asked to quote the VIN number.

VEHICLE BUILD DATE PLATE

This is the calendar month and year in which
the body and power train assemblies were
conjoined and the vehicle was driven from the
production line.

The vehicle built date is shown on a the tyre
pressure label attached to the right-hand 'B'
post.

E83693

Made by Land Rover

LRC PLREB RIMINI RED

LAND ROVER

SALFAXXXXXXXXXXXX

e11*XXXX/XXX*XXXX

XXXX kg
XXXX kg

1-
2-

XXXX kg
XXXX kg

E83694

SALFAXXXXXXXXXXXX

211

Technical specifications

R

Technical specifications

ENGINE SPECIFICATIONS

Data

Petrol

Number of cylinders

6

Displacement cc's

3192

Firing order

1-5-3-6-2-4

Compression ratio

10.8:1

Power output kW (PS)

171 (233) at 6300 rpm

Maximum torque Nm

317 at 3200 rpm

Data

Diesel

Diesel with DPF

Number of cylinders

4

4

Displacement cc's

2179

2179

Firing order

1-3-4-2

1-3-4-2

Compression ratio

16.5:1

16.5:1

Power output kW (PS)

118 (160) at 4000 rpm

Belgium 110 (150) at 4000

rpm

112 (152) at 4000 rpm

Belgium 110 (150) at 4000 rpm

Maximum torque Nm

400 at 2000 rpm

400 at 2000 rpm

Technical specifications

212

L

WEIGHTS

¹ This figure includes the tool kit, all fluids to
the correct levels, and spare wheel, but
excludes the driver and passengers.

² The maximum permissible weight of the
vehicle including passengers and load.

³ The maximum permissible weight of the
vehicle and braked trailer including their
respective loads.

Note: ¹ The front and rear axle maximum loads
can not be reached simultaneously as this will
exceed the GVW limit.

² This figure includes the weight of the roof
rack.

Variant

Approximate unladen

weight¹

Gross Vehicle Weight

(GVW)²

Gross Train Weight³

Petrol

1825 kg

 4020 lbs

2505 kg

5520 lbs

4505 kg

9930 lbs

Diesel

1820 kg

4010 lbs

2505 kg

5520 lbs

4505 kg

9935 lbs

Variant

Maximum front

axle load¹

Maximum rear

axle load¹

Maximum roof

rack load²

Maximum

payload

Petrol and Diesel

1310 kg

 2885 lbs

1360 kg

2995 lbs

75 kg

165 lbs

500 kg

1100 lbs

213

Technical specifications

R

DIMENSIONS

2

E82384

1

6

5

4

3

8

7

Item

Description

mm/inches

Degrees

1

Width

2180/85.7

-

1

Width with mirrors folded

2005/78.8

-

2

Maximum height (inc roof rails)

1820/71.6

-

3

Approach angle

-

31°

4

Breakover angle

-

157°

5

Wheelbase

2660/104.7

-

6

Length excluding number plate

plinth

4500/177.1

-

7

Track - front

1601/63

-

7

Track - rear

1614/63.5

-

8

Departure angle without tow hitch

-

34°

8

Departure angle with detachable tow

ball

-

18°

-

Turning circle (kerb to kerb)

11.3m/37.1ft

-

-

Maximum wading depth

500/19.7

-
