Maintenance

158

L

One or both types of service interval (distance
and time) may be displayed. For example, if an
engine oil service is due based on mileage, and
a brake fluid change is due based on time, both
distance and time countdowns will display.

Service Portfolio

The Service Portfolio book includes a Service
Record section, which enables a record to be
kept of all the servicing and inspections that are
carried out on the vehicle. This section of the
book also has an area for brake fluid changes
to be recorded.

Ensure your service provider signs and stamps
the book after each service and inspection.

Owner Maintenance

In addition to the routine maintenance, a
number of simple checks must be carried out
more frequently. Advice is given on the pages
that follow.

Daily checks
• Operation of lamps, horn, direction

indicators, wipers, washers and warning
indicators.

• Operation of seat belts and brakes.
• Look for fluid deposits underneath the

vehicle that might indicate a leak.

Weekly checks
• Engine oil level.  See ENGINE OIL CHECK

(page 162).

• Engine coolant check.  See ENGINE

COOLANT CHECK (page 163).

• Brake/clutch fluid level.  See BRAKE AND

CLUTCH FLUID CHECK (page 165).

• Power steering fluid level.  See POWER

STEERING FLUID CHECK (page 166).

• Screen washer fluid level.  See WASHER

FLUID CHECK (page 167).

• Tyre pressures and condition.
• Operate air conditioning.
Note: The engine oil level should be checked
more frequently if the vehicle is driven for
prolonged periods at high speeds.

Driving in arduous conditions

When a vehicle is operated in extremely
arduous conditions, more frequent attention
must be paid to servicing requirements.

For example, if your vehicle experiences deep
wading conditions, even daily servicing could
be necessary to ensure the continued safe and
reliable operation of the vehicle.

Arduous driving conditions include:
• Driving in dusty and/or sandy conditions.
• Driving on rough and/or muddy roads

and/or wading.

• Driving in extremely hot conditions.
• Towing a trailer or driving in mountainous

conditions.

Contact a Land Rover Dealer/Authorised
Repairer for advice.

Emission control

Your vehicle is fitted with various items of
emission and evaporative control equipment,
designed to meet specific territorial
requirements. You should be aware that
unauthorised replacement, modification or
tampering with this equipment by an owner or
repair shop, may be unlawful and subject to
legal penalties.

CAUTION

Any significant or sudden drop in fluid
levels, or uneven tyre wear, should be

reported to a qualified technician without
delay.

159

Maintenance

R

In addition, engine settings must not be
tampered with. These have been established to
ensure that your vehicle complies with
stringent exhaust emission regulations.
Incorrect engine settings may adversely affect
exhaust emissions, engine performance and
fuel consumption. They may also cause high
temperatures, which will result in damage to
the catalytic converter and the vehicle.

Road testing dynamometers (rolling
roads)

Because your vehicle is equipped with anti-lock
brakes and four wheel drive, it is essential that
any dynamometer testing is carried out only by
a qualified person, familiar with the
dynamometer testing and safety procedures
practised by Land Rover Dealers/Authorised
Repairers.

Safety in the garage

Fuel system

Poisonous fluids

Fluids used in motor vehicles are poisonous
and should not be consumed or brought into
contact with open wounds. These include;
battery acid, antifreeze, brake, clutch and
power steering fluid, petrol, diesel, engine oil
and windscreen washer additives.

For your own safety, always read and obey all
instructions printed on labels and containers.

Used engine oil

Prolonged contact with engine oil may cause
serious skin disorders, including dermatitis
and cancer of the skin. Always wash
thoroughly after contact.

It is illegal to pollute drains, water
courses or soil. Use authorised
waste disposal sites to dispose of

used oil and toxic chemicals.

WARNINGS

If the vehicle has been driven recently,
do not touch exhaust and cooling

system components until the engine has
cooled.

Never leave the engine running in an
unventilated area - exhaust gases are

poisonous and extremely dangerous.

Do not work beneath the vehicle with
the wheel changing jack as the only

means of support.

Keep your hands and clothing away
from drive belts and pulleys.

Remove metal wrist bands and
jewellery, before working in the engine

compartment.

Do not touch electrical leads or
components while the engine is

running, or with the starter switch turned on.

Do not allow tools or metal parts of the
vehicle to make contact with the battery

leads or terminals.

WARNINGS

Under no circumstances should any
part of the fuel system be dismantled or

replaced by anyone other than a suitably
qualified vehicle technician. Failure to comply
with this instruction, may result in fuel spillage
with a consequent serious risk of fire.

Ensure sparks and naked lights are kept
away from the engine compartment.

Wear protective clothing, including,
where practicable, gloves made from

an impervious material.

WARNINGS

Maintenance

160

L

OPENING AND CLOSING THE
BONNET

Opening the bonnet

1. Pull the bonnet release handle located on

the left-hand side of the vehicle.

2. Lift the bonnet safety catch lever located

below the centre point of the words LAND
ROVER, and raise the bonnet.

Closing the bonnet

1. Lower the bonnet until the safety catch

engages. Using both hands, press the
bonnet down until the catches click.

2. Check that both catches are fully engaged

by attempting to lift the front edge of the
bonnet. This should be free from all
movement.

WARNING

Do not drive with the bonnet retained by
the safety catch alone.

E83613

161

Maintenance

R

ENGINE COMPARTMENT OVERVIEW

1. Engine oil filler caps (Black)

2. Engine oil dipsticks (Yellow)

3. Brake fluid reservoir cap (Black)

4. Coolant reservoir cap (Black)

5. Washer fluid reservoir cap (Blue)

6. Power steering fluid reservoir cap
(Black)

3

4

5

6

2

1

3

1

2

E83614

E83860

E83861

E83862

E83863

E83864

E83865
