Parking aid

126

Parking aid

PRINCIPLE OF OPERATION

Park Distance Control (PDC) provides the
driver with information on most obstructions,
and their distance from the vehicle, when
manoeuvring. PDC does this by using four
ultrasonic sensors on each bumper.

1. When objects are detected at this range the

PDC will emit a pulse tone which increases
in frequency as the vehicle gets closer to
the object.

2. When objects are sensed within this range,

approximately 30 centimetres (12 inches)
the tone becomes continuous.

E79871

127

Parking aid

USING THE PARKING AID

PDC activation

Front PDC is activated by pressing the PDC
button a short confirmation tone will be heard,
and the tell-tale will illuminate. The front
sensors will remain active as long as the
vehicle's speed does not exceed 16 km/h (10
mph).

If reverse gear is selected, front and rear
sensors are activated.

In vehicles fitted with automatic transmission,
selecting neutral from reverse will keep front
and rear sensors active.

Front PDC deactivation

The PDC system can be deactivated by
pressing the PDC switch.

Towing

The rear sensors are automatically disabled
when a trailer is connected.

Sensor care

The sensors should be kept clean to maintain
accuracy and performance.

System fault

If a system fault is detected, a long
high-pitched tone will sound, and the switch
indicator lamp will flash. Contact your Land
Rover Dealer/Authorised Repairer as soon as
possible.

WARNING

Parking aids may not detect moving
objects such as children and animals
until they are dangerously close.

Always use extreme caution when
manoeuvring.

CAUTIONS

Parking aids are for guidance only, and
are not intended to replace the driver's
visual checks for obstructions when

manoeuvring.

PDC sensors may not detect some
obstructions. Obstructions such as
narrow posts, small objects close to the

ground, and some objects with dark
non-reflective surfaces for example.

Systems which use the same frequency
band as the front PDC sensors may
cause irregular tones to be emitted.

E79872

CAUTION

When washing the vehicle do not aim
high pressure water jets directly at the
sensors. Do not use abrasive materials

or hard/sharp objects to clean the sensors.
Only use approved vehicle shampoo.

Driving hints

128

Driving hints

GENERAL DRIVING POINTS

Battery charging - red

Illuminates as a bulb check when
the ignition is turned on and
extinguishes once the engine is

running. If it remains on, or illuminates whilst
driving, a fault with the battery charging
system is indicated. Seek qualified assistance
urgently.

Low oil pressure - red

Illuminates as a bulb check when
the ignition is turned on and
extinguishes when the engine is

started. If the indicator remains on, flashes on
and off, or illuminates whilst driving, stop the
vehicle as soon as safety permits and switch
off the engine immediately. Seek qualified
assistance before driving. Always check the oil
level when this indicator illuminates.

REDUCED ENGINE PERFORMANCE

Engine management system (EMS) fault

Illuminates amber in the
instrument pack when the engine
management system detects a

serious fault - reduced performance may be
experienced. Avoid high speeds and consult
your Land Rover Dealer/Authorised Repairer as
soon as possible.

Check engine - petrol models only

Illuminates amber in the
instrument pack as a bulb and
system check when the starter

switch is turned on and extinguishes as soon
as the engine is started. Illumination at any
other time indicates that the emission
performance of the engine management
system is impaired - seek qualified assistance.
If the indicator flashes while driving,
immediately reduce engine power to avoid
catalytic converter damage.

RUNNING-IN

The engine, gearbox, tyres, and brakes need
time to bed-in. During the first 800 km (500
miles) it is essential that the vehicle is driven
with consideration for the running-in process.
During the running in period the following
advice should be followed.
• Limit the engine speed to a maximum of

3000 rpm, and the road speed to a
maximum of 110 km/h (68 mph).

• Do not use full accelerator pedal travel, and

use the gears to avoid over-revving or
labouring the engine.

• Do not use sport mode during the running

in period.

• Avoid rapid acceleration or heavy braking

wherever possible.

• Ensure that servicing is carried out on

time, and follow any advice regarding use
in arduous conditions.

Note: The advice given for running in will aid
fuel economy, and should be adopted as
general driving practice even after the running
in period.

129

Driving hints

ECONOMICAL DRIVING

There are two main factors which influence fuel
economy, the way the vehicle is driven, and
maintenance.

Driving tips for economy

• Avoid unnecessary journeys, especially

short stop-start trips.

• Accelerate smoothly and gently from a

stand still.

• Use the gears to avoid labouring, or

over-revving the engine.

• Allow time to brake gently and smoothly.
• Be aware of traffic and road conditions

ahead, and take action in time to avoid
hard braking or acceleration.

• When stationary apply the park brake, and

select neutral.

• Turn off the air conditioning when not

needed.

Maintenance and fuel economy

Regular servicing by a Land Rover
Dealer/Approved repairer, along with regular
checks by the driver are essential for vehicle
longevity and fuel economy.

The condition of the engine (oils, filters, spark
plugs, settings etc) tyre pressures, and wheel
alignment, will all have a bearing on fuel
economy. For this reason it is essential that the
vehicle is checked regularly by the driver, and
serviced by an approved Land Rover
Dealer/Authorised Repairer at the correct
intervals.

Note: If you are in any doubt about the
maintenance requirements, intervals, or
checks required, contact your Land Rover
Dealer/Authorised repairer for advice.
