Frelander 2. Manual - part 707

Climate control

106

L

Calibration

If the battery is disconnected, or the power
supply is interrupted, whilst the sunroof is
partially open it will need to be recalibrated.

Once the battery is reconnected, or the power
supply is restored, recalibrate the sunroof as
follows :-

1. Switch the ignition on.

2. Press the front of the sunroof switch, and

hold for twenty seconds.

3. After twenty seconds the sunroof will

begin to move. Keep the front of the switch
pressed until the sunroof has fully opened,
then closed.

4. Once the open/close cycle has completed

and the sunroof has stopped moving,
release the switch.

The sunroof can now be operated as normal.

Sunroof blinds

When opening the sunroof blinds, hold the
catch firmly, then press the catch release
button and allow the sunroof blind to open
smoothly.

E83689

107

Convenience features

R

Convenience features

SUN VISORS

CLOCK

The clock is set through the audio system.

Setting the clock - Premium audio

1. Switch on the audio system, by pressing

the volume rotary control.

2. Press the MENU button to access the

function menu.

E82085

Premium
6CD

E82914

100.7

1

1 2 3 4

6

CD 1

Track

   1

00:01



  1:51

P

PTY

1

E82981

Convenience features

108

L

3. Rotate the control to select Clock and

press to confirm selection.

4. Use the rotary control to adjust the Time

Mode (12 or 24 hr), press to confirm
selection.

5. Use the rotary control to adjust the hour

displayed, press to confirm selection.

6. Use the rotary control to adjust the

minutes displayed, press to confirm
selection.

7. Press the EXIT button to cancel and to

return to the menu.

Setting the clock - Standard audio

1. Switch on the audio system, by pressing

the volume rotary control.

2. Press the MENU button to access the

function menu.

3. Rotate the control to select Clock and

press to confirm selection.

4. Rotate the control to select Set and press

to confirm selection.

5. Use the rotary control to adjust the hour

and press to confirm selection.

EXIT

SELECT

CD settings..

Clock..

CANCEL

SET

Time Mode

12hr

CANCEL

SET

Time Set

PM

1

:39

CANCEL

SET

Time Set

PM   1:

39

E83267

Clock

Cancel

Set

Clock

OK

06

:15

Set

PM

Clock

OK

09:

15

Set

AM

E83965

Clock

1 2 / 2 4

Set

109

Convenience features

R

6. Use the rotary control to adjust the

minutes and press to confirm selection.

7. Once the time has been set, OK will be

highlighted. Press the rotary control to
accept the settings.

Set 12/24 hour display

1. With the audio unit switched on, press the

MENU button to access the function menu.

2. Rotate the control to select Clock and

press to confirm selection.

3. Rotate the control to select 12/24 and

press to confirm selection.

4. Use the rotary control to select 12hr or

24hr and press to confirm selection.

CIGAR LIGHTER

With the ignition on, and/or the engine running,
press in the centre of the cigar lighter. When
the cigar lighter element has reached the
correct temperature it will partially eject and
can be withdrawn for use.

After use push the lighter back into the first
position.

ASHTRAY

To empty the ashtrays fully open the lid, then
pull the ashtray upwards to remove.

E83603

WARNING

Do not use the ashtrays for disposing
of waste paper, or other combustible
items. The resulting fire may cause

death or serious injury.

E83604
