Keys and remote controls

Single and double locking

The vehicle can be locked in two ways.

Single locking

Single locking secures the vehicle and prevents
the doors being opened from outside of the
vehicle. The doors can be unlocked and opened
from inside the vehicle.

Double locking

Double locking secures the vehicle and
prevents the doors being opened from inside
or outside of the vehicle. The doors can not be
unlocked or opened from inside the vehicle.

This provides additional security if the vehicle
is left unattended. The vehicle cannot be
opened by breaking a window and operating
the door locks from inside the vehicle.

Locking

Press briefly to single lock the
vehicle, and partially activate the
alarm. The hazard warning lamps

will flash to indicate that the vehicle is locked.
A second press within three seconds will
double lock the vehicle and fully arm the alarm.
The hazard warning lamps will flash again to
indicate the enhanced lock/alarm state.

Note: The fuel filler flap can only be opened
when the vehicle is unlocked.

Global closing

Press and hold the lock button for three
seconds to single lock the vehicle, fully arm the
alarm, and close all of the windows.

Note: For safety reasons, the sunroof does not
close automatically. It should be closed in the
normal way before exiting the vehicle.

Automatic relocking

If a door, or the tailgate, are not opened within
one minute of unlocking the vehicle, doors will
lock again automatically.

Approach lighting

When approaching the vehicle
during darkness press to switch on
the approach illumination. Press

again to turn the approach lamps off.

The approach illumination period
set at the factory is thirty seconds.
This can be configured by a Land

Rover Dealer/Authorised Repairer to provide
illumination lasting between Zero and 120
seconds.

WARNING

Never double lock the vehicle with
people, children, or pets inside. In the

event of an emergency they would be unable to
escape, and the emergency services would be
unable to release them quickly.

WARNING

Ensure that no children, pets, or
obstructions are in any open aperture

before operating global closing. Safety
mechanisms are in place to prevent serious
injury, however, injuries can still occur.

Keys and remote controls

Tailgate

Press briefly to release the tailgate.

Emergency alarm

Press and hold for three seconds, or
press twice within three seconds, to
activate the horn and the hazard

lamps.

Once active for more than five seconds the
alarm can be cancelled by pressing the button
and holding for three seconds, or pressing
twice within three seconds.

Note: The horn and hazard lamps will switch
off automatically after two minutes and forty
five seconds.

Remote battery

The remote control batteries are recharged
when the remote is docked and the engine is
running. For this reason it is recommended
that each remote is used periodically. This will
ensure that the batteries are kept charged and
ready for use.

Locks

LOCKING AND UNLOCKING

Drive-away locking

The vehicle can be configured by a
Land Rover Dealer/Authorised
Repairer to lock automatically

when in motion. Contact your
Dealer/Authorised Repairer for further
information.

Locking and unlocking from inside the
vehicle

Door buttons and levers

1. The front doors can be unlocked using the

door buttons, or unlocked and opened
using the lever.

2. The rear doors are unlocked using the door

buttons. If the doors are locked, operating
the lever will have no effect.

Note: For information on operating the child
safety locks. See CHILD SAFETY LOCKS
(page 69).

Facia buttons

To lock or unlock the vehicle press the
respective button on the facia. This will lock, or
unlock, all doors and the tailgate.

Note: Pressing and holding both buttons
simultaneously for three seconds will release
the tailgate.

Mis-lock

If one of the doors, the bonnet, or the tailgate
are not shut fully the horn will emit a single
tone. The vehicle will not fully lock until the
door, bonnet, and tailgate are fully closed.

WARNING

Never double lock the vehicle with
people, children or pets inside. In the
event of an emergency they would be

unable to escape, and the emergency services
would be unable to release them quickly.

E83971

E81085

Alarm

ARMING THE ALARM

The engine is automatically
immobilised when the remote
control is removed from the starter

control unit. The alarm system is automatically
armed when the remote lock button is pressed.
The hazard lamps will flash to indicate that the
alarm is armed.

Full alarm

To set full alarm protection ensure that all the
windows and the sunroof are closed. Then
press the lock button twice within three
seconds. The hazard warning lights will flash
twice to confirm the alarm state.

Once fully armed the alarm will sound if :-
• the bonnet, tailgate, or a door are opened.
• movement is detected within the vehicle

interior.

• a window, front or rear windscreen, or

sunroof glass are broken.

• the vehicle is raised or tilted.
• the vehicle battery is disconnected.
• an attempt is made to disconnect the alarm

siren.

Note: If the alarm is armed and a window or the
sunroof are left open the alarm will sound due
to movement of air currents.

Partial alarm

To set partial alarm protection, briefly press the
lock button once. The hazard warning lights
will flash once to confirm the alarm state.

Once partially armed the alarm will sound if :-
• the bonnet, tailgate, or a door are opened.
• the vehicle battery is disconnected.
• an attempt is made to disconnect the alarm

siren.

Note: This setting should be used in
circumstances such as travelling on a ferry,
when pets are to be left in the vehicle, when a
window must be left open etc

Alarm indicator

The alarm status is displayed by the indicator.
• Indicator off - alarm disarmed.
• Indicator flashes once per second - alarm

is armed and engine immobilised.

• Indicator flashes rapidly - the alarm has

been triggered.

Note: The alarm status indicator will flash
rapidly when the alarm has been disarmed, but
the remote has not been docked.

E81141
