Frelander 2. Manual - part 689

34

Filling station information

L

Tyre pressures

Tyre pressure label

The correct tyre pressures are shown on a label
attached to the driver's door pillar.

Engine oil specification

LAND ROVER RECOMMENDS

Engine coolant specification

Top-up to the upper level indicator mark. Use
only a 50% mix of water and Texaco XLC
antifreeze. See ENGINE COOLANT CHECK
(page 163).

Model

Specification

Petrol engine

Use only 0W-30 engine

oil, meeting ACEA A5 or

B5 specification.

Diesel engine

Use only 5W-30 oil

meeting Ford 913-B

specification.

E83219

35

Introduction

R

Introduction

SYMBOLS GLOSSARY

Warnings

Cautions

Symbols

This recycling symbol identifies
those items that must be disposed
of safely in order to prevent

unnecessary damage to the environment.

This symbol identifies those
features that can be adjusted,
disabled or enabled by a Land

Rover Dealer/Authorised Repairer.

LABEL LOCATIONS

Warning labels attached to your
vehicle bearing this symbol mean:
Do not touch or adjust components
until you have read the relevant

instructions in the handbook.

Labels showing this symbol
indicate that the ignition system
utilises very high voltages. Do not
touch any ignition components

while the starter switch is turned on.

Warning labels

Labels are attached to your vehicle at several
positions. These are applied to draw your
attention to important subjects, e.g. tyre
pressures, tow bar use, airbags, roll-over risk,
engine compartment hazards, etc.

Additional information labels may also be
found at these locations.

WARNING

Safety warnings are included in this
handbook. These indicate either a
procedure which must be followed

precisely, or information that should be
considered with great care in order to avoid
the possibility of personal injury.

CAUTION

Cautions are included in this handbook.
These indicate either a procedure which
must be followed precisely, or

information that should be considered with
great care in order to avoid the possibility of
damage to your vehicle.

E83651

E83652

Introduction

36

L

1. Bonnet locking platform - Air

conditioning label

2. Top face of battery - Battery warning

symbols

3. End of facia (passenger side) - Passenger

airbag label

4. Sun visor - Airbag label, Vehicle handling

label

5. Base of right-hand B pillar - Tyre

pressure label, Airbag warning label

6. Left-hand B pillar - Airbag warning label,

Vehicle Identification Number label

7. Right-hand B pillar - Vehicle

Identification Number label (China)

8. Inner face of fuel filler flap - Fuel

specification label

It is important that you are familiar with these
subjects to ensure that your vehicle and its
features are used safely. Using the index at the
back of this handbook, refer to the relevant
topic for more information.

HEALTH AND SAFETY

E80235

6

4

3

2

1

5

4

3

8

7

WARNINGS

Your vehicle has a higher ground
clearance and hence, a higher centre of
gravity than ordinary passenger cars,

to enable the vehicle to perform in a wide
variety of off-road applications. An advantage
of the higher ground clearance is a better view
of the road allowing you to anticipate
problems.

The vehicle is not designed for
cornering at the same speed as
conventional passenger cars any more

than a low-slung sports car is designed to
perform satisfactorily under off-road
conditions. If at all possible, avoid sharp turns
or abrupt manoeuvres. As with other vehicles
of this type, failure to operate the vehicle
correctly may result in loss of control or
vehicle roll-over.

The vehicle should not be parked over
long dry grass or other combustible
material, particularly during dry

weather. As the heat generated by the exhaust
and emission control systems may be
sufficient to start a fire.

Before exiting the vehicle ensure that P
park is selected and the park brake
applied. When exiting the vehicle

ensure that the remote control is removed
from the vehicle.

37

Introduction

R

DATA RECORDING

Service data recording

Service data recorders in your vehicle are
capable of collecting and storing diagnostic
information about your vehicle. This potentially
includes information about the performance or
status of various systems and modules in the
vehicle such as engine, throttle, steering or
brakes.

In order to properly diagnose and service your
vehicle, Land Rover and service and repair
facilities may access vehicle diagnostic
information through a direct connection to
your vehicle.

Event data recording

Event data recorders are capable of collecting
and storing data during a crash or near-crash
event. The recorded information may assist in
the investigation of such an event. The
modules may record information about both
the vehicle and the occupants, potentially
including information such as:
• How various systems in your vehicle were

operating.

• Whether or not the driver and passenger

seat belts were buckled.

• How far, if at all, the driver was depressing

the accelerator and/or the brake pedal.

• How fast the vehicle was travelling.
• Where the driver was positioning the

steering wheel.

To access this information special equipment
must be connected directly to the recording
modules. Land Rover do not access event data
recorder information without obtaining
consent, unless pursuant to court order or
where required by law enforcement, other
government authorities or third parties acting
with lawful authority.

Other parties may seek to access the
information independently of Land Rover.

DISABILITY MODIFICATIONS

Occupants with disabilities which may require
modification of the vehicle must contact a Land
Rover Dealer/Authorised Repairer before any
modifications are made.

PARTS AND ACCESSORIES

WARNINGS

The fitting of non-approved parts and
accessories, or the carrying out of
non-approved alterations or

conversions, may be dangerous and could
affect the safety of the vehicle and occupants
and also invalidate the terms and conditions of
the vehicle warranty.

Land Rover will not accept any liability
for death, personal injury or damage to
property which may occur as a direct

result of fitment of non-approved accessories
or the carrying out of non-approved
conversions to Land Rover vehicles.

Land Rover strongly advise against
making any modifications to the
suspension or steering system. This

could seriously affect the handling and
stability of the vehicle leading to loss of control
or roll-over.
