Frelander 2. Manual - part 683

10

Quick start

L

Power operated seat adjustment

1. Backrest adjustment switch.

2. Seat forward/backwards and cushion

height control switch.

3. Lower backrest lumbar support handwheel

(non-memory seats).

4. Lower backrest lumbar support switch

(driver's side memory seat only).

Wherever possible the seats should be
adjusted with the engine running. In addition,
the seats have an active period that is initiated
when the driver’s door is opened and closed or
the remote control is removed from the
docking port.

Driving position memory

Once you have adjusted the power operated
driver's seat and exterior mirrors for your ideal
driving position, the vehicle can memorise
these settings for future use.

To operate the windows and door mirrors, the
remote control must be in the docking port and
the ignition on.

1. Press the memory store button to activate

the memory function.

2. Press one of the preset buttons within five

seconds to memorise the current settings.
MEMORY STORED will be displayed on the
message centre accompanied by an
audible chime to confirm the settings have
been memorised.

E83188

1

2

3

4

Operating note

A seat position will only be memorised during
the five second active period.

Any existing settings will be over-written
when programming a memory position.

E83189

1

2

11

Quick start

R

Manual seat adjustment

1. Forward/backward adjustment.

2. Height adjustment.

3. Backrest adjustment.

4. Lumbar adjustment.

Windows and Door mirrors

To operate the windows and door mirrors, the
remote control must be in the docking port and
the ignition on.

Windows
• To open a window, press and hold the

respective switch.

• To close the window, pull and hold the

switch.

Window movement can be stopped at any time
by releasing the switch.

The windows have a one touch facility that
allows them to be fully opened or closed with a
single operation of the switch. Press or pull the
switch and release. Movement can be stopped
by briefly pressing the switch again.

Press switch 2 to inhibit the operation of the
rear window switches.

Door mirror adjustment

To adjust the mirrors, press the L (Left) or R
(Right) button to select the appropriate mirror.
Move the control knob 1 in any direction to
adjust the position of the mirror glass.

Power fold mirrors

The mirrors can be electrically folded towards
the door for better clearance/protection.

Press the L and R buttons simultaneously to
fold/unfold the mirrors.

The mirrors may also fold automatically when
the vehicle is locked, and unfold when the
vehicle is unlocked.

Reverse automatic mirror dip

When reverse gear is selected, the door
mirrors will dip.

The dip position of the door mirrors can be
personalised. See ELECTRIC EXTERIOR
MIRRORS (page 95).

This feature can be disabled or enabled by a
Land Rover Dealer/Authorised Repairer.

3

2

1

E83190

4

1

2

E83191

Resonance with lowered windows

If a resonance/booming sound occurs when a
window is open, lowering an adjacent window
about 25 mm (1 inch) will eliminate the
condition.

12

Quick start

L

Steering column adjustment

1. Move the lever located under the steering

wheel fully downward.

2. Adjust the height and reach of the steering

wheel to the desired position.

3. Move the lever fully up to lock the position

of the wheel.

Steering column lock

The vehicle has an electronic steering column
lock that is deactivated when the remote
control is inserted in the docking port.

Overhead console

Courtesy lamps

The front and rear courtesy lamps will operate
in conjunction with the vehicle being
unlocked/locked or when a door is opened.

The courtesy lamps can be manually switched
on or off by the lamp switch (arrowed in the
illustration). When the switch is in the centre
position, the lamps operate in automatic mode.

Panoramic sunroof

To tilt the sunroof:

1. Press and release the front of the switch 2

to open the sunroof to the tilt position.

To open the sunroof:

1. Press and release the rear of the switch 1

to fully open the sunroof.

To close the sunroof:

1. From the fully open position, press and

release the front of the switch 2.

2. From the tilted position, press and hold the

rear of the switch 1.

If the sunroof is moving, it can be stopped by
pressing the switch again.

E83192

E83193

1

2

13

Quick start

R

Seat belts and Child restraints

A warning indicator on the
instrument pack will illuminate to
alert you that the driver's or front

passenger's seat belt is unbuckled.

Child seats

It is important to remember that the child's
weight, rather than age, determines the type of
seat that is required. See CHILD SEATS
(page 64).

Passenger airbag deactivation

If it becomes necessary to fit a child restraint
on the front passenger seat, the passenger
airbag must be deactivated.

To deactivate the airbag, open the front
passenger door and use the starter key to turn
the PASS AIRBAG switch (located on the end of
the facia) to the OFF position.

With the airbag deactivated, the status
indicator, located on the overhead console, will
illuminate whenever the ignition is on.

Operating note

The sunroof can only be operated with the
ignition on.

Recommended child seat

Land Rover strongly recommend the use of
ISOFIX child seats.

ISOFIX child seats can only be fitted in the
rear outer seating positions.

WARNING

Do not use a child restraint on a seat
protected by an operational airbag in

front of it. There is a risk of death or serious
injury when the airbag deploys.

Operating note

When an adult is seated in the front passenger
seat, ensure the PASS AIRBAG switch is
turned to the ON position.

E83194
