Frelander 2. Manual - part 682





7

Quick start

R

Quick start

QUICK START

Remote control

1. Lock button.

 Press once to lock the vehicle and arm the
alarm. Press twice within three seconds to
double lock the vehicle. Press and hold to
close the door windows (Global closing).

2. Unlock button.

 Press once to disarm the alarm, unlock
the driver's door and unlock the luggage
compartment. Press again to unlock the
passenger doors. Press and hold to open
the door windows (Global opening).

3. Approach lighting button.

 Press once to switch the headlamps,
position lamps, and license plate lamps on
for a short period. Press again to switch
off.  See APPROACH LAMPS (page 76).

4. Tailgate release.

 Press to release the tailgate.

5. Panic alarm.

 Press twice in three seconds, or press and
hold for two seconds, to activate the panic
alarm. After five seconds, press and hold
the button again to cancel the alarm.

6. Press the release tab on the remote control

to release the emergency key blade.

7. Pull the keyring attachment to remove the

key blade.

Further information is available within the main
body of the handbook. See USING THE
REMOTE CONTROL (page 41).

6

3

1

E83183

2

7

4

5

Single point entry

 This is a security feature that unlocks only the
driver’s door, fuel filler flap, and tailgate. It
can be disabled on individual remote controls
by unlocking the vehicle then simultaneously
pressing and holding the lock and unlock
buttons for three seconds. The vehicle will
lock and then unlock in the currently selected
mode and the hazard warning lights will flash
twice to confirm the change.

You can now unlock all doors with a single
press. Repeating the procedure will re-enable
Single point entry.

8

Quick start

L

Engine starting

The START STOP ENGINE button 2 is only
operational when a recognised remote control
is inserted into the starter control unit 1
(buttons facing upwards).

When inserted, the remote control will latch
into the starter control unit. To remove, press
the remote control to unlatch and release.

Ignition only
• Press and hold the START STOP ENGINE

button for a short period, to switch on the
ignition.

• Pressing the button again will switch off

the ignition.

Engine start/stop
• For automatic transmission vehicles, with

the gear selector in P (park) or N (neutral)
and the brake pedal depressed, press and
release the START STOP ENGINE button to
start the engine.

• For manual transmission vehicles, depress

the clutch pedal and press and release the
START STOP ENGINE button to start the
engine.

• Press the button again to stop the engine

and switch off the ignition.

1

EXT

C

23

EXT

F

72

EXT

C

21

EXT

C

23

EXT

F

72

EXT

C

21

1

1

2

2

E83184

2

Remote control unit removal

Press the remote control to unlatch and
release from the starter control unit. Remove
by gripping the sides of the remote control.

9

Quick start

R

Master lock and unlock switches

1. Press and hold to unlock all doors and

tailgate.

2. Press and hold to lock all doors and

tailgate.

Press both 1 and 2 to release the tailgate.

Tailgate

With the vehicle unlocked, press the release
switch on the underside of the exterior handle
and pull to open.

Bonnet

Opening

Pull the bonnet release lever 1.

Lift the bonnet safety catch lever 2, and raise
the bonnet.

Closing

Lower the bonnet until the safety catch
engages. Using both hands, press the bonnet
down until the catches click.

Check that both catches 3 are engaged by
trying to lift the front edge of the bonnet.

1

2

E83185

E83186

1

2

3

E83187
