Frelander 2. Manual - part 618





Safety Belt System - Front Safety Belt Buckle

Removal and Installation

Removal

• NOTE: Removal steps in this procedure may contain installation details.

Disconnect the battery ground cable.

Refer to:

Specifications

 (414-00 Battery and Charging System -

General Information, Specifications).

1.

Make the SRS system safe.

Refer to: Supplemental Restraint System (SRS) Depowering and
Repowering (501-20, General Procedures).

2.

Remove the front seat.

Refer to:

Front Seat

 (501-10 Seating, Removal and Installation).

3.

4.

Torque: 40 Nm

5.

Installation

To install, reverse the removal procedure.

1.

Safety Belt System - Rear Safety Belt Buckle

Removal and Installation

Removal

• NOTE: Removal steps in this procedure may contain installation details.

Torque: 55 Nm

1.

Installation

To install, reverse the removal procedure.

1.

Supplemental Restraint System -

Torque Specifications

Description

Nm

lb-ft

B-pillar side impact sensor Torx screws

10

7

C-pillar side impact sensor Torx bolts

10

7

Driver lower air bag module

6

4

Front impact severity sensor Torx bolts

10

7

Passenger air bag module bracket Torx screws

7

5

Passenger air bag module nuts

10

7

Restraints control module (RCM) Torx screws

10

7

Side air bag module nuts

10

7

Side air curtain module Torx screws

10

7
