information read by the manufacturer approved diagnostic system).

• NOTE: When performing voltage or resistance tests, always use a digital multimeter (DMM) accurate to 3 decimal places,
and with an up-to-date calibration certificate. When testing resistance, always take the resistance of the DMM leads into
account.

• NOTE: Check and rectify basic faults before beginning diagnostic routines involving pinpoint tests.

• NOTE: If DTCs are recorded and, after performing the pinpoint tests, the fault is not present, an intermittent concern
may be the cause. Always check for loose connections and corroded terminals.

DTC

Description

Possible Cause

Action

B100A11 Fuel Pump Authorisation

- circuit short to ground

Fuel pump authorisation
circuit - short to ground

Refer to electrical circuit diagrams and check fuel pump
authorisation circuit for short to ground

B100A15 Fuel Pump Authorisation

- circuit short to power
or open

Fuel pump authorisation
circuit - short to power,
open circuit

Refer to electrical circuit diagrams and check fuel pump
authorisation circuit for short to power, open circuit

B102408 Transponder - Bus

signal/Message Failures

Transponder - Bus
signal/message failures

Carry out the pinpoint tests associated to this DTC using
the manufacturer approved diagnostic system

B102451 Start Control Unit - not

programmed

Start control unit - not
configured

Re-configure the start control unit using the
manufacturer approved diagnostic system

B102481 Start Control unit -

invalid serial data
received

Invalid serial data
received

Carry out the pinpoint tests associated to this DTC using
the manufacturer approved diagnostic system

B102487 Start control unit -

missing message

Missing message

Carry out the pinpoint tests associated to this DTC using
the manufacturer approved diagnostic system

B102496 Start control unit -

component internal
failure

Internal failure

Install a new start control unit.
REFER to:

Start Control Unit

 (303-06B Starting System -

TD4 2.2L Diesel, Removal and Installation).

B102581 Transponder - invalid

serial data

Invalid serial data
received

Carry out the pinpoint tests associated to this DTC using
the manufacturer approved diagnostic system

B102608 Steering Column Lock -

Bus Signal/Message
Failures

Steering column lock -
Bus signal/message
failures

Carry out the pinpoint tests associated to this DTC using
the manufacturer approved diagnostic system

B102651 Steering Column Lock -

not programmed

Steering column lock -
not configured

Re-configure the steering column lock using the
manufacturer approved diagnostic system

B102652 Steering Column Lock -

not activated

Request to enable the
steering column lock
supply not approved

• NOTE: If the vehicle is parked in circumstances where
a continuous torque acts on the column (on partial lock,
or tire against a curb) it could prevent the lock from
disengaging. The driver may need to rock the steering
wheel to allow the column lock to disengage.

Clear DTC and test system with steering straight. If the
DTC does not re occur advise the customer of the above
note. If the DTC does reoccur - Check LIN circuit
between steering column lock and CJB

B102671 Steering Column Lock -

actuator stuck

Should be set if the SCL
is unable to reach
locked and OK position

Carry out the pinpoint tests associated to this DTC using
the manufacturer approved diagnostic system

B102682 Steering Column Lock

Steering column lock
incorrectly programmed

Install a new steering column lock

B102692 Steering Column Lock -

performance or incorrect
operation

Micro switch/sensor
fault

Carry out the pinpoint tests associated to this DTC using
the manufacturer approved diagnostic system

B102694 Steering Column Lock -

unexpected operation

Status messages are
received from the SCL
when SCL should be
turned off

Carry out the pinpoint tests associated to this DTC using
the manufacturer approved diagnostic system

B102696 Steering Column Lock -

component internal
failure

Internal failure

Install a new steering column lock, refer to the new
module/component installation note at the top of the
DTC Index

B108A23 Start button - signal

stuck low

SW1 and SW 2
constantly active

Carry out the pinpoint tests associated to this DTC using
the manufacturer approved diagnostic system

B108B23 Start Button Circuit "A"

- signal stuck low

SW1 constantly active
for long time while
button press detected
at SW2

Carry out the pinpoint tests associated to this DTC using
the manufacturer approved diagnostic system

B108B24 Start button circuit "A" -

signal stuck high

SW1 never active while
button press detected
at SW2

Carry out the pinpoint tests associated to this DTC using
the manufacturer approved diagnostic system

DTC

Description

Possible Cause

Action

B108C23 Start button circuit "B" -

signal stuck low

SW2 constantly active
for long time while
button press detected
at SW1

Carry out the pinpoint tests associated to this DTC using
the manufacturer approved diagnostic system

B108C24 Start button circuit "B" -

signal stuck high

SW2 never active while
button press detected
at SW1

Carry out the pinpoint tests associated to this DTC using
the manufacturer approved diagnostic system

B108D24 Start button circuit "C"

signal stuck high

SW3 never active while
button press detected
at SW1

Carry out the pinpoint tests associated to this DTC using
the manufacturer approved diagnostic system

B10D794 PATS Key - unexpected

operation

No response from
transponder in key

Replace key

C1A4121 Clutch Pedal Sensor -

signal amplitude <
minimum

signal<3% of
supply(5V)

Carry out the pinpoint tests associated to this DTC using
the manufacturer approved diagnostic system

C1A4122 Clutch Pedal Sensor -

signal amplitude >
maximum

signal>=97% of
supply(5V)

Carry out the pinpoint tests associated to this DTC using
the manufacturer approved diagnostic system

P051300 Incorrect immobilizer

key

Security key invalid

Program the keys using the approved diagnostic system.

P061511 Starter relay circuit

Starter relay control
circuit: short circuit to
ground
Starter relay control
circuit: open circuit
Starter relay failure

Check the starter relay and circuits. Refer to the
electrical guides. Install a new relay as necessary.

P061512 Starter relay circuit

Starter relay control
circuit: short circuit to
power
Starter relay failure

Check the starter relay and circuits. Refer to the
electrical guides. Install a new relay as necessary.

P061513 Starter relay circuit

Starter relay control
circuit: open circuit
Starter relay failure

Check the starter relay and circuits. Refer to the
electrical guides. Install a new relay as necessary.

P061711 Starter Relay Circuit

High

Starter motor relay
control circuit, high side
- short to ground

Carry out the pinpoint tests associated with this DTC
using the manufacturer approved diagnostic system

P061712 Starter Relay Circuit

High

Starter motor relay
control circuit, high side
- short to power

Carry out the pinpoint tests associated with this DTC
using the manufacturer approved diagnostic system

P085086 Park/Neutral switch

input circuit

Signal invalid

Carry out a complete vehicle read for related DTCs.
Rectify as necessary.

P0A0F68 Engine failed to start

Long cranking time

No action necessary. Code for information only.

P125983 Immobilizer to PCM

Signal Error

Checksum error

• NOTE: If the vehicle starts, ignore this DTC

Check the CAN network between the ECM, ABS module
and CJB. Carry out CAN network integrity tests using the
manufacturer approved diagnostic system

P125984 Immobilizer to PCM

Signal Error

Signal below allowable
range

• NOTE: If the vehicle starts, ignore this DTC

Check the CAN network between the ECM and ABS
module. Carry out CAN network integrity tests using the
manufacturer approved diagnostic system

P125985 Immobilizer to PCM

Signal Error

Signal above allowable
range

• NOTE: If the vehicle starts, ignore this DTC

Run the ECM renew procedure using the manufacturer
approved diagnostic system. If DTC remains, suspect
ECM. Refer to the new module/component installation
note at the top of the DTC Index

P125986 Immobilizer to PCM

Signal Error

Signal invalid

• NOTE: If the vehicle starts, ignore this DTC

Run the ECM renew procedure using the manufacturer
approved diagnostic system. If DTC remains, suspect
ECM. Refer to the new module/component installation
note at the top of the DTC Index

P125987 Immobilizer to PCM

Signal Error

Missing message

• NOTE: If the vehicle starts, ignore this DTC

Check the CAN network between the ECM and CJB. Carry
out CAN network integrity tests using the manufacturer
approved diagnostic system

U010000 Lost Communication

W ith ECM/PCM 'A'

Lost communication
with ECM

Carry out the associated network test for this DTC using
the manufacturer approved diagnostic system

DTC

Description

Possible Cause

Action

U010100 Lost Communication

with TCM

Lost communication
with TCM

Carry out the associated network test for this DTC using
the manufacturer approved diagnostic system

U015500 Lost Communication

W ith Instrument Panel
Cluster (IPC) Control
Module

Lost communication
with instrument cluster

Carry out the associated network test for this DTC using
the manufacturer approved diagnostic system

U021400 Lost Communication

W ith Remote Function
Actuation

Lost communication
with Remote Keyless
Entry module

Carry out the associated network test for this DTC using
the manufacturer approved diagnostic system

U023600 Lost Communication

W ith Column Lock
Module

Lost communication
with steering column
lock module

Carry out the associated network test for this DTC using
the manufacturer approved diagnostic system

U051500 Invalid data received

from remote function
actuation

Invalid data received
from keyless entry
module

Check keyless entry module for DTCs and refer to DTC
Index. Carry out the pinpoint tests associated to this
DTC using the manufacturer approved diagnostic system

Starting System - I6 3.2L Petrol - Starter Motor

Removal and Installation

Removal

1.

CAUTION: After switching of the ignition, wait for 2 minutes

before disconnecting the battery. Failure to wait for 2 minutes will
damage the navigation computer.

Disconnect the battery ground cable.

Refer to:

Specifications

 (414-00 Battery and Charging System -

General Information, Specifications).

1.

2.

WARNING: Do not work on or under a vehicle supported only

by a jack. Always support the vehicle on safety stands.

Raise and support the vehicle.

2.

Remove the engine undershield.

Refer to:

Engine Undershield

 (501-02 Front End Body Panels,

Removal and Installation).

3.

4.

Installation

1.

CAUTION: Make sure that the mating faces are clean and

free of corrosion and foreign material.

Install the starter motor and tighten the bolts.

Torque: 45 Nm

1.

Connect the cable and lead to the starter motor solenoid and tighten
the nuts.

Torque: 10 Nm

2.

Install the engine undershield.

Refer to:

Engine Undershield

 (501-02 Front End Body Panels,

Removal and Installation).

3.















Content   ..  268  269  270  271   ..
