Frelander 2. Manual - part 33





DTC

Description

Possible Cause

Action

B0080-1A Driver Seatbelt Load Limiter

Deployment Control - Circuit
resistance below threshold

Driver's safety belt
retractor circuit resistance
below threshold

Refer to electrical circuit diagrams and
check driver's safety belt retractor circuit
for short circuit between both lines to
ignitor

B0080-95 Driver Seatbelt Load Limiter

Deployment Control -
Incorrect assembly

Driver’s safety belt
retractor incorrect
assembly

Check driver’s safety belt retractor
installed correctly
Using the manufacturer approved
diagnostic system check and up-date the
car configuration file as required

B0082-11 Passenger Seatbelt Load

Limiter Deployment Control -
Circuit short to ground

Passenger's safety belt
retractor circuit short
circuit to ground

Refer to the electrical circuit diagrams
and check passenger's safety belt
retractor circuit for short circuit to ground

B0082-12 Passenger Seatbelt Load

Limiter Deployment Control -
Circuit short to battery

Passenger's safety belt
retractor circuit short
circuit to power

Refer to the electrical circuit diagrams
and check passenger's safety belt
retractor circuit for short circuit to power

B0082-13 Passenger Seatbelt Load

Limiter Deployment Control -
Circuit open

Passenger's safety belt
retractor circuit open
circuit

Refer to the electrical circuit diagrams
and check passenger's safety belt
retractor circuit for open circuit

B0082-19 Passenger Seatbelt Load

Limiter Deployment Control -
Circuit current above
threshold

Passenger's safety belt
retractor circuit current
above threshold

Refer to electrical circuit diagrams and
check passenger’s safety belt retractor
circuit for swapped pins or cross coupling
between two firing lines

B0082-1A Passenger Seatbelt Load

Limiter Deployment Control -
Circuit resistance below
threshold

Passenger's safety belt
retractor circuit resistance
below threshold

Refer to electrical circuit diagrams and
check passenger's safety belt retractor
circuit for short circuit between both lines
to ignitor

B0082-95 Passenger Seatbelt Load

Limiter Deployment Control -
Incorrect assembly

Passenger’s safety belt
retractor incorrect
assembly

Check passenger’s safety belt retractor
installed correctly
Using the manufacturer approved
diagnostic system check and up-date the
car configuration file as required

B00B5-11 Driver Seat Track Position

Restraints Sensor - Circuit
short to ground

Driver's seat position
sensor circuit short circuit
to ground

Refer to the electrical circuit diagrams
and check driver's seat position sensor
circuit for short circuit to ground

B00B5-12 Driver Seat Track Position

Restraints Sensor - Circuit
short to battery

Driver's seat position
sensor circuit short circuit
to power

Refer to the electrical circuit diagrams
and check driver's seat position sensor
circuit for short circuit to power

B00B5-13 Driver Seat Track Position

Restraints Sensor - Circuit
open

Driver's seat position
sensor circuit open circuit

Refer to the electrical circuit diagrams
and check driver's seat position sensor
circuit for open circuit

B00B5-19 Driver Seat Track Position

Restraints Sensor - Circuit
current above threshold

Driver's seat position
sensor circuit current
above threshold

Refer to electrical circuit diagrams and
check driver’s seat position sensor circuit
for swapped pins or cross coupling
between two firing lines

B00B5-1E Driver Seat Track Position

Restraints Sensor - Circuit
resistance out of range

Driver's seat position
sensor circuit resistance
out of range

Refer to the electrical circuit diagrams
and check driver's seat position sensor for
resistance out of range

B00B5-95 Driver Seat Track Position

Restraints Sensor - Incorrect
assembly

Driver’s seat position
sensor incorrect assembly

Check driver’s seat position sensor
installed correctly
Using the manufacturer approved
diagnostic system check and up-date the
car configuration file as required

B00D2-68 Restraint System Malfunction

Indicator 1 - Event
information

Restraint system events
information

Refer to electrical circuit diagrams and
check for instrument cluster internal fault
Refer to the warranty policy and
procedures manual, or determine if any
prior approval programme is in operation,
prior to the installation of a new module/
component

B00D2-95 Restraint System Malfunction

Indicator 1 - Incorrect
assembly

Restraint system incorrect
assembly

Using the manufacturer approved
diagnostic system check and install latest
relevant level of software to the
restraints control module
Using the manufacturer approved
diagnostic system check and up-date the
car configuration file as required

DTC

Description

Possible Cause

Action

B00D5-12 Restraint System Passenger

Disable Indicator - Circuit
short to battery

Passenger's airbag
disable lamp circuit short
circuit to power

Refer to the electrical circuit diagrams
and check passenger's airbag disable
lamp circuit for short circuit to power

B00D5-14 Restraint System Passenger

Disable Indicator - Circuit
short to ground or open

Passenger's airbag
disable lamp circuit short
circuit to ground, open
circuit, high resistance

Refer to the electrical circuit diagrams
and check passenger's airbag disable
lamp circuit for short circuit to ground,
open circuit, high resistance

B00D5-95 Restraint System Passenger

Disable Indicator - Incorrect
assembly

Passenger’s airbag
disable lamp incorrect
assembly

Check passenger’s airbag disable lamp
installed correctly
Using the manufacturer approved
diagnostic system check and up-date the
car configuration file as required

B00DF-24 Passenger Restraints Disable

Switch - Signal stuck high

Passenger's restraints
disable switch stuck or
internal failure

Refer to the electrical circuit diagrams
and check passenger's restraints disable
switch

B00DF-55 Passenger Restraints Disable

Switch - Not configured

Passenger's restraints
disable switch not
configured

Refer to the electrical circuit diagrams
and check passenger's restraints disable
switch

B00DF-64 Passenger Restraints Disable

Switch - Signal plausibility
failure

Passenger's restraints
disable switch
configuration error

Refer to the electrical circuit diagrams
and check passenger's restraints disable
switch

B10FD-11 Drivers Side Peripheral

Acceleration Sensor - Circuit
short to ground

Driver's front side impact
sensor circuit short circuit
to ground

Refer to the electrical circuit diagrams
and check driver's front side impact
sensor circuit for short circuit to ground

B10FD-12 Drivers Side Peripheral

Acceleration Sensor - Circuit
short to battery

Driver's front side impact
sensor circuit short circuit
to power

Refer to the electrical circuit diagrams
and check driver's front side impact
sensor circuit for short circuit to power

B10FD-19 Drivers Side Peripheral

Acceleration Sensor - Circuit
current above threshold

Driver's front side impact
sensor circuit current
above threshold

Refer to electrical circuit diagrams and
check driver’s front side impact sensor
circuit for swapped pins or cross coupling
between two firing lines

B10FD-4A Drivers Side Peripheral

Acceleration Sensor -
Incorrect component installed

Driver's front side impact
sensor incorrect
component installed

Restraints control module detected a
miss-match between the hardware fitted
and what is expected
Check correct driver’s front side impact
sensor installed

B10FD-87 Drivers Side Peripheral

Acceleration Sensor - Missing
message

Driver's front side impact
sensor circuit open circuit
Driver's front side impact
sensor internal fault

Refer to electrical circuit diagrams and
check driver's front side impact sensor
circuit for communication fault

B10FD-95 Drivers Side Peripheral

Acceleration Sensor -
Incorrect assembly

Driver’s front side impact
sensor incorrect assembly

Check driver’s front side impact sensor
installed correctly
Using the manufacturer approved
diagnostic system check and up-date the
car configuration file as required

B10FD-96 Drivers Side Peripheral

Acceleration Sensor -
Component internal failure

Driver's front side impact
sensor internal fault

Refer to electrical circuit diagrams and
check driver's front side impact sensor

B10FE-11 Passenger Side Peripheral

Acceleration Sensor - Circuit
short to ground

Passenger's front side
impact sensor circuit
short circuit to ground

Refer to the electrical circuit diagrams
and check passenger's front side impact
sensor circuit for short circuit to ground

B10FE-12 Passenger Side Peripheral

Acceleration Sensor - Circuit
short to battery

Passenger's front side
impact sensor circuit
short circuit to power

Refer to the electrical circuit diagrams
and check passenger's front side impact
sensor circuit for short circuit to power

B10FE-19 Passenger Side Peripheral

Acceleration Sensor - Circuit
current above threshold

Passenger's front side
impact sensor circuit
current above threshold

Refer to electrical circuit diagrams and
check passenger’s front side impact
sensor circuit for swapped pins or cross
coupling between two firing lines

B10FE-4A Passenger Side Peripheral

Acceleration Sensor -
Incorrect component installed

Passenger's front side
impact sensor incorrect
component installed

Restraints control module detected a
miss-match between the hardware fitted
and what is expected
Check correct passenger’s front side
impact sensor installed

B10FE-87 Passenger Side Peripheral

Acceleration Sensor - Missing
message

Passenger's front side
impact sensor circuit open
circuit
Passenger's front side
impact sensor internal

Refer to electrical circuit diagrams and
check passenger's front side impact
sensor circuit for communication fault

DTC

Description

Possible Cause

Action

fault

B10FE-95 Passenger Side Peripheral

Acceleration Sensor -
Incorrect assembly

Passenger’s front side
impact sensor incorrect
assembly

Check passenger’s front side impact
sensor installed correctly
Using the manufacturer approved
diagnostic system check and up-date the
car configuration file as required

B10FE-96 Passenger Side Peripheral

Acceleration Sensor -
Component internal failure

Passenger's front side
impact sensor internal
fault

Refer to electrical circuit diagrams and
check passenger's front side impact
sensor

B1126-11 Drivers Side-Side Airbag

Deployment Control - Circuit
short to ground

Driver's side air bag
circuit short circuit to
ground

Refer to the electrical circuit diagrams
and check driver's side air bag circuit for
short circuit to ground

B1126-12 Drivers Side-Side Airbag

Deployment Control - Circuit
short to battery

Driver's side air bag
circuit short circuit to
power

Refer to the electrical circuit diagrams
and check driver's side air bag circuit for
short circuit to power

B1126-13 Drivers Side-Side Airbag

Deployment Control - Circuit
open

Driver's side air bag
circuit open circuit

Refer to the electrical circuit diagrams
and check driver's side air bag circuit for
open circuit

B1126-19 Drivers Side-Side Airbag

Deployment Control - Circuit
current above threshold

Driver's side air bag
circuit current above
threshold

Refer to electrical circuit diagrams and
check driver’s side air bag circuit for
swapped pins or cross coupling between
two firing lines

B1126-1A Drivers Side-Side Airbag

Deployment Control - Circuit
resistance below threshold

Driver's side air bag
circuit resistance below
threshold

Refer to electrical circuit diagrams and
driver's side air bag circuit for short circuit
between both lines to air bag

B1126-95 Drivers Side-Side Airbag

Deployment Control -
Incorrect assembly

Driver’s side air bag
incorrect assembly

Check driver’s side air bag installed
correctly
Using the manufacturer approved
diagnostic system check and up-date the
car configuration file as required

B1127-11 Passengers Side-Side Airbag

Deployment Control - Circuit
short to ground

Passenger's side air bag
circuit short circuit to
ground

Refer to the electrical circuit diagrams
and check passenger's side air bag circuit
for short circuit to ground

B1127-12 Passengers Side-Side Airbag

Deployment Control - Circuit
short to battery

Passenger's side air bag
circuit short circuit to
power

Refer to the electrical circuit diagrams
and check passenger's side air bag circuit
for short circuit to power

B1127-13 Passengers Side-Side Airbag

Deployment Control - Circuit
open

Passenger's side air bag
circuit open circuit

Refer to the electrical circuit diagrams
and check passenger's side air bag circuit
for open circuit

B1127-19 Passengers Side-Side Airbag

Deployment Control - Circuit
current above threshold

Passenger's side air bag
circuit current above
threshold

Refer to electrical circuit diagrams and
check passenger’s side air bag circuit for
swapped pins or cross coupling between
two firing lines

B1127-1A Passengers Side-Side Airbag

Deployment Control - Circuit
resistance below threshold

Passenger's side air bag
circuit resistance below
threshold

Refer to electrical circuit diagrams and
passenger's side air bag circuit for short
circuit between both lines to side air bag

B1127-95 Passengers Side-Side Airbag

Deployment Control -
Incorrect assembly

Passenger’s side air bag
incorrect assembly

Check passenger’s side air bag installed
correctly
Using the manufacturer approved
diagnostic system check and up-date the
car configuration file as required

B1128-11 Drivers Side-Side Inflatable

Curtain Deployment Control -
Circuit short to ground

Driver's side curtain air
bag circuit short circuit to
ground

Refer to the electrical circuit diagrams
and check driver's side curtain air bag
circuit for short circuit to ground

B1128-12 Drivers Side-Side Inflatable

Curtain Deployment Control -
Circuit short to battery

Driver's side curtain air
bag circuit short circuit to
power

Refer to the electrical circuit diagrams
and check driver's side curtain air bag
circuit for short circuit to power

B1128-13 Drivers Side-Side Inflatable

Curtain Deployment Control -
Circuit open

Driver's side curtain air
bag circuit open circuit

Refer to the electrical circuit diagrams
and check driver's side curtain air bag
circuit for open circuit

B1128-19 Drivers Side-Side Inflatable

Curtain Deployment Control -
Circuit current above
threshold

Driver's side curtain air
bag circuit current above
threshold

Refer to electrical circuit diagrams and
driver’s side curtain air bag circuit for
swapped pins or cross coupling between
two firing lines

DTC

Description

Possible Cause

Action

B1128-1A Drivers Side-Side Inflatable

Curtain Deployment Control -
Circuit resistance below
threshold

Driver's side curtain air
bag circuit resistance
below threshold

Refer to electrical circuit diagrams and
driver's side curtain air bag circuit for
short circuit between both lines to side
curtain air bag

B1128-95 Drivers Side-Side Inflatable

Curtain Deployment Control -
Incorrect assembly

Driver’s side curtain air
bag incorrect assembly

Check driver’s side curtain air bag
installed correctly
Using the manufacturer approved
diagnostic system check and up-date the
car configuration file as required

B1129-11 Passengers Side-Side

Inflatable Curtain
Deployment Control - Circuit
short to ground

Passenger's side curtain
air bag circuit short circuit
to ground

Refer to the electrical circuit diagrams
and check passenger's side curtain air
bag circuit for short circuit to ground

B1129-12 Passengers Side-Side

Inflatable Curtain
Deployment Control - Circuit
short to battery

Passenger's side curtain
air bag circuit short circuit
to power

Refer to the electrical circuit diagrams
and check passenger's side curtain air
bag circuit for short circuit to power

B1129-13 Passengers Side-Side

Inflatable Curtain
Deployment Control - Circuit
open

Passenger's side curtain
air bag circuit open circuit

Refer to the electrical circuit diagrams
and check passenger's side curtain air
bag circuit for open circuit

B1129-19 Passengers Side-Side

Inflatable Curtain
Deployment Control - Circuit
current above threshold

Passenger's side curtain
air bag circuit current
above threshold

Refer to electrical circuit diagrams and
check passenger’s side curtain air bag
circuit for swapped pins or cross coupling
between two firing lines

B1129-1A Passengers Side-Side

Inflatable Curtain
Deployment Control - Circuit
resistance below threshold

Passenger's side curtain
air bag circuit resistance
below threshold

Refer to electrical circuit diagrams and
passenger's side curtain air bag circuit for
short circuit between both lines to side
curtain air bag

B1129-95 Passengers Side-Side

Inflatable Curtain
Deployment Control -
Incorrect assembly

Passenger’s side curtain
air bag incorrect assembly

Check passenger’s side curtain air bag
installed correctly
Using the manufacturer approved
diagnostic system check and up-date the
car configuration file as required

B1193-68 Crash Event Storage Full and

Locked - Event information

Restraints control module
crash event storage area
full and locked

Read out the event data recorder and
then refer to the warranty policy and
procedures manual, or determine if any
prior approval programme is in operation,
prior to the installation of a new module

B1194-11 Driver Side Frontal

Acceleration Sensor - Circuit
short to ground

Driver's side front impact
sensor circuit short circuit
to ground

Refer to the electrical circuit diagrams
and check driver's side front impact
sensor circuit for short circuit to ground

B1194-12 Driver Side Frontal

Acceleration Sensor - Circuit
short to battery

Driver's side front impact
sensor circuit short circuit
to power

Refer to the electrical circuit diagrams
and check driver's side front impact
sensor circuit for short circuit to power

B1194-19 Driver Side Frontal

Acceleration Sensor - Circuit
current above threshold

Driver's side front impact
sensor circuit current
above threshold

Refer to electrical circuit diagrams and
driver’s side front impact sensor circuit for
swapped pins or cross coupling between
two firing lines

B1194-4A Driver Side Frontal

Acceleration Sensor -
Incorrect component installed

Driver's side front impact
sensor incorrect
component installed

Restraints control module detected a
miss-match between the hardware fitted
and what is expected
Check correct driver’s side front impact
sensor installed

B1194-87 Driver Side Frontal

Acceleration Sensor - Missing
message

Driver's side front impact
sensor circuit open circuit
Driver's side front impact
sensor internal fault

Refer to electrical circuit diagrams and
driver's side front impact sensor for
communication fault

B1194-95 Driver Side Frontal

Acceleration Sensor -
Incorrect assembly

Driver’s side front impact
sensor incorrect assembly

Check driver’s side front impact sensor
installed correctly
Using the manufacturer approved
diagnostic system check and up-date the
car configuration file as required

B1194-96 Driver Side Frontal

Acceleration Sensor -
Component internal failure

Driver's side front impact
sensor internal fault

Refer to electrical circuit diagrams and
check driver's side front impact sensor

B1195-11 Passenger Side Frontal

Acceleration Sensor - Circuit
short to ground

Passenger's side front
impact sensor circuit
short circuit to ground

Refer to the electrical circuit diagrams
and check passenger's side front impact
sensor circuit for short circuit to ground















Content   ..  31  32  33  34   ..
