PANEL REPAIRS
REPAIRS 77-2-35
Repair
1. Remove existing panel(s), prepare panel joint
faces and install new panel(s) in accordance
with Panel Replacement Procedure. Punch or
drill holes in new panel for plug welding as
shown.
Refit
1. Fit insulation pad to engine bulkhead.
2. Fit front door aperture seal.
3. Position front carpet and fit tread plate to front
door aperture.
4. Fit wiring to 'A' post.
5. Driver's side: Fit steering column support
bracket.
6. Fit fascia.
+
INTERIOR TRIM COMPONENTS,
REPAIRS, Fascia.
7. RH side: Fit CD autochanger.
+
IN CAR ENTERTAINMENT,
REPAIRS, CD autochanger.
8. Fit RH or LH front seat.
+
SEATS, REPAIRS, Seat - front.
9. Fit sunroof drain tube.
10. Connect multiplug to speaker (if fitted) and fit
finisher to 'A' post.
11. Diesel models: Fit ECM.
+
ENGINE MANAGEMENT SYSTEM -
Td5, REPAIRS, Engine control module
(ECM).
12. Fit windscreen.
+
SCREENS, REPAIRS, Windscreen.
13. Fit sill finisher.
14. Fit front door.
+
DOORS, REPAIRS, Door - front.
15. Fit front wing.
+
EXTERIOR FITTINGS, REPAIRS,
Wing - front - up to 03MY.
16. Fit bonnet.
17. Connect leads/multiplug to alternator.
18. Connect battery leads, negative lead last.
M77 1751
