RESTRAINT SYSTEMS REPAIRS 75-13 REPAIRS Seat belt - front $% 76.73.13 Remove 1. Remove 'B' post lower trim casing. REPAIRS, Trim casing - lower - 'B' post. 2. Remove bolt securing seat belt to front seat. Refit 1. Fit seat belt upper anchorage and tighten nut to 32 Nm (24 lbf.ft). 2. Fit seat belt reel to 'B' post and tighten bolt to 50 Nm (37 lbf.ft). 3. Fit seat belt to front seat and tighten bolt to 32 Nm (24 lbf.ft). 4. Fit 'B' post lower trim casing. REPAIRS, Trim casing - lower - 'B' post. Seat belt - rear - centre $% 76.73.20 Remove 1. Carefully pull front carpet away from rear seat base to gain access to front mounting brackets 2. Remove 2 Torx bolts securing front mounting brackets of RH rear seats to floor. 3. Recline and fold RH rear seats. brackets of RH rear seats to floor. 5. Remove RH rear seats. |
