STEERING REPAIRS 57-29 12. RH drive models with ACE: Position ACE control arms to access steering box bolts. 13. With assistance remove 4 securing bolts and remove steering box. 14. Remove centralising bolt from steering box. Refit 1. Fit centralising bolt to steering box. and tighten to 90 Nm (66 lbf.ft). 3. RH drive models with ACE: Ensure washer is in place on lower ball joint of anti-roll bar link, 4. Position drag link, fit nut and tighten to 80 Nm (59 lbf.ft). 5. Position Panhard rod, fit bolt and nut and tighten to 230 Nm (170 lbf.ft). 6. Clean PAS pipe ends and 'O' ring recess. PAS fluid. 8. Fit 'O' rings to PAS pipes and position pipes in steering box. Fit PAS pipe bracket and tighten 9. RHD models: Fit oil filter and housing: l Clean oil filter housing and engine mating l Lubricate new 'O' ring with clean engine oil l Position oil filter housing and tighten bolts to 10. Ensure steering wheel is centralised. Fit universal joint between steering box and 11. Remove centralising bolt from steering box. (103 lbf.ft).. 13. Remove stand(s) and lower vehicle. 16. Centralise steering linkage |
