ENGINE MANAGEMENT SYSTEM - TD5
REPAIRS 18-1-63
Switch - cruise control (set/resume)
$% 19.75.33
Remove
1. Remove the key from the starter switch.
Disconnect both battery leads, negative lead
first. Wait ten minutes before starting work.
2. Remove driver's airbag module.
3. Release remote control switches multiplug and
leads from steering wheel base.
4. Disconnect remote control switches multiplug
from harness.
5. Remove 2 screws securing remote control
switches to steering wheel base.
6. Release and remove remote control switches
from steering wheel.
Refit
1. Fit remote control switches to steering wheel
and secure with screws.
2. Connect remote control switches multiplug to
harness.
3. Secure leads and multiplug to base of steering
wheel.
4. Fit driver's airbag module.
Switch - clutch
$% 19.75.34
Remove
1. Disconnect the multiplug from the clutch switch.
2. Position a container below the clutch switch to
collect the fluid.
3. Unscrew and remove the clutch switch.
CAUTION: Always fit plugs to open
connections to prevent contamination.
Refit
1. Fit the clutch switch and tighten to 10 Nm (7
lbf.ft).
2. Connect the multiplug.
3. Bleed the clutch hydraulic system.
