EMISSION CONTROL - V8
REPAIRS 17-2-55
Filter - fuel leak detection pump - up to
03MY
$% 17.45.42
Remove
1. Remove bolt securing air filter to mounting
bracket and collect nut.
2. Remove clip securing hose to air filter.
3. Release hose from air filter.
4. Remove air filter.
Refit
1. Connect hose to air filter and secure with clip.
2. Position air filter to mounting bracket and
secure with nut and bolt.
Filter - fuel leak detection pump - from
03MY
$% 17.45.42
Remove
1. Remove Allen bolt securing fuel leak detection
pump filter to the mounting bracket.
2. Remove and discard clip securing fuel pipe to
the fuel leak detection pump filter and
disconnect the pipe.
CAUTION: Always fit plugs to open
connections to prevent contamination.
3. Remove the fuel leak detection pump filter.
Refit
1. Connect fuel pipe to the fuel leak detection
pump and secure with a new clip.
2. Position fuel leak detection pump filter to
mounting bracket, fit Allen bolt and tighten to 3
Nm (2.2 lbf.ft).
17M 0224
