IDENTIFICATION NUMBERS

05-1

IDENTIFICATION NUMBERS

Vehicle Identification Number

Location
The Vehicle Identification Number (VIN) plate is
stamped on a plate attached to the bonnet locking
platform. The VIN is also stamped in the following
locations:

l

On a plate behind the LH lower corner of the
windscreen.

l

On the chassis RH longitudinal behind the rear
wheel.

Bonnet locking platform VIN

Windscreen VIN

Chassis VIN

VIN plate content

The VIN plate contains the following information.

a Vehicle Identification Number (VIN)

b Gross vehicle weight

c Gross train weight

d Maximum front axle load

e Maximum rear axle load

f Paint code

g Trim code

IDENTIFICATION NUMBERS

05-2

Vehicle identification number - except NAS and
Canada
Example: SALLTGM87WA600172

Vehicle identification number - NAS and Canada
Example: SALTY124OWA600180

Paint and trim colour codes
Paint code (F): a 3 digit code identifying the original
paint colour is stamped on the VIN plate. Refer to
Parts Catalogue for full list of colour codes.

Trim code (G): a code identifying the original trim
type and colour is stamped on the VIN plate. Refer to
the relevant Parts Catalogue for coding details

SAL

Manufacturer's identifier (Land Rover UK)

LT

Marque/Model

LT = Discovery

G

Class

A = Japan

G = 100 inch

M

Body Style

B = 5 door models

8

Engine

1 = 4.0 V8 LC Cat

2 = 4.0 V8 HC Cat

3 = 4.0 LC Non Cat

8 = TD5 engine EGR/Cat

9 = TD5 engine EGR/ Non Cat

7

Transmission and Steering

3 = RHD automatic gearbox

4 = LHD automatic gearbox

7 = RHD manual gearbox

8 = LHD manual gearbox

W

Model Year

W = 1998 Model year

X = 1999 Model year
Y = 2000 Model year
1 = 2001 Model year
2 = 2002 Model year
3 = 2003 Model year

A

Assembly plant

A = Solihull

F = KD build

6 figures= Serial number

SAL

Manufacturer's identifier (Land Rover UK)

T

Marque/Model

T = Discovery

Y

Class

Y = 100 inch USA/Canada

N = 100 inch California

1

Body Style

1 = 4 door Station Wagon

2

Engine

2 = 4.0 V8 HC Cat

4

Transmission and Steering

4 = LHD automatic gearbox

O

Check digit

W

Model Year

W = 1998 Model year
X = 1999 Model year
Y = 2000 Model year
1 = 2001 Model year
2 = 2002 Model year
3 = 2003 Model year

A

Assembly plant

A = Solihull

6 figures= Serial number

IDENTIFICATION NUMBERS

05-3

Identification Number Locations

Engine number

V8 Engine

Td5 Engine

Stamped on the LH side of the cylinder block below
the exhaust manifold

Manual gearbox number

Stamped on the RH side of the gearbox casing,
adjacent to the oil drain plug.

Automatic gearbox number

Stamped on a plate attached to the LH side of the
gearbox casing adjacent to the selector mechanism.

IDENTIFICATION NUMBERS

05-4

Transfer box number

Stamped on the rear of the transfer box casing above
the bottom cover plate.

Front axle number

Stamped on the rear face of the axle tube on the LH
side.

Rear axle number

Stamped on the front face of the axle tube on the LH
side.

Body number

Stamped on a label attached to the LH inner wing,
behind the headlamp.
