ELECTRICAL

43

REPAIR

ANTI-THEFT ALARM ECU (96 MODELS)

Service repair no - 86.55.85

Remove

1. Remove 4 studs securing fascia left hand

closing panel.

2. Remove closing panel.

3. Disconnect 2 multiplugs from ECU.
4. Remove nut securing ECU/relay bracket.
5. Lower bracket.
6. Remove 2 nuts securing ECU to bracket.
7. Remove ECU.

NOTE: A new ECU must be initialised
using TestBook.

Refit

8. Reverse removal procedure.

HANDSET (96 MODELS)

If vehicle does not respond to handset immediately, it
may have lost synchronisation. To re-synchronise,
press either button, 4 times in quick succession. If
handset still fails to respond, check batteries, refer to
Owner’s handbook. If batteries are okay, it may be
necessary to use emergency key access, refer to
Owner’s handbook.

NOTE: New handsets must be initialised
using TestBook.

PASSIVE COIL (96 MODELS)

Service repair no - 86.77.35

Remove

1. Remove steering column shroud.

See

STEERING, Repair, Steering column shroud

2. Release multiplug from harness clip and

disconnect.

3. Release passive coil from starter switch.
4. Remove bulb holder/starter switch shroud.
5. Remove coil.

Refit

6. Fit coil, ensuring switch illumination bulb harness

passes through large cut-out.

7. Secure coil with cable tie.
8. Position bulb holder/starter switch shroud and

locate bulb.

9. Locate bulb holder/starter switch shroud,

ensuring cut-out in shroud aligns with lug on
starter switch.

10. Connect multiplug and secure to clip.
11. Fit column shroud.

86

ELECTRICAL

44

REPAIR

BONNET SWITCH

Service repair no - 86.55.89

Remove

1. Remove 2 bolts securing sounder, move

sounder aside.

2. Locate and disconnect bonnet switch multiplug.
3. Release and remove switch.

Refit

4. Reverse removal procedure.

ULTRASONIC SENSOR

Service repair no - 86.77.32

Remove

1. Release sensor from switch panel.
2. Disconnect multiplug and remove sensor.

Refit

3. Reverse removal procedure.

ANTI-THEFT ALARM INDICATOR LIGHT (96
MODELS)

Service repair no - 86.45.61

See Instrument illumination and warning light

bulbs

ENGINE IMMOBILISATION WARNING LIGHT (96
MODELS)

Service repair no - 86.45.61

See Instrument illumination and warning light

bulbs

ELECTRICAL

45

REPAIR

SOUNDER (96 MODELS)

Service repair no - 86.55.87

Remove

NOTE: Failure to follow steps 1 and 2 will
result in sounder being activated.

1. Turn starter switch ’ON’ then ’OFF’.

2. WITHIN 15 SECONDS, depress release clip on

multiplug and detach from sounder.

3. Remove 2 securing bolts and remove sounder

complete with bracket.

Refit

4. Reverse removal procedure.

NOTE: If sounder is accidentally activated,
it can be silenced, provided it is
reconnected, by turning starter switch to

position II.

SWITCH - ELECTRIC SEAT

Service repair no - 86.75.03

Remove

1. Release switch panel from centre console.
2. Disconnect 2 switch multiplugs
3. Remove switch panel.

Refit

4. Reverse removal procedure.

86

ELECTRICAL

46

REPAIR

STARTER MOTOR - 4.0 V8

Service repair no - 86.60.01

Remove

1. Disconnect battery negative lead.
2. Raise vehicle on ramp.
3. Remove heated oxygen sensor from RH front

exhaust pipe.

See EMISSION CONTROL,

Repair, Heated Oxygen Sensor (HO2S) - 4.0
V8

4. Mark front propeller shaft and drive flanges for

assembly reference.

5. Remove 4 nuts and bolts securing propeller

shaft flange.

NOTE: Raise 1 front road wheel and rotate
propeller shaft to gain access to all
fixings.

6. Tie propeller shaft aside.
7. Position starter motor heat shield above motor.

See Starter Motor Heat Shield - 4.0 V8

8. Disconnect Lucar from solenoid.
9. Remove nut securing feed wires to starter

solenoid and disconnect from terminal.
