To

remove

4.

Raise-up  the  rear

of

t h e   panel  and  withdraw  it

rearwards  from the  sun

roof

exterior surround.

O p e n   t h e   roof  panel  t o   its  fullest  extent  by
pulling  t h e  latch  handle  down t o  t h e  first  o p e n
position.

5.

Remove  the  two  screws  and  withdraw  the

latch  finisher.

2.

Then  move  t h e   green  button  t o   t h e   right  and

push  the  panel  u p   as far  as the  latch  will  allow
t o  the fully o p e n  position.

3.

Move  t h e   red  button  upwards  and  o p e n   t h e
retaining  hasp.

6.

The

sun

roof  interior  finisher  is  secured  by

fourteen  dowels

to

the  sun  roof  outer  frame

retainer.

To

remove  the  finisher,  carefully  lever

the  finisher  away  from  t h e   retainer  using  a
screwdriver with  a  broad  blade.

Continued

B

ODY

7.

Remove  the  fifteen  screws  and  withdraw  the

outer frame retainer.

8.

Lift  t h e   sun

roof

external  frame  from  the

vehicle.

9.

If

necessary,  remove  the  adhesive-  backed

seal,

from

t h e   inner  e d g e   of  the  frame,  that

seals  it

to

t h e  vehicle  roof.

To

refit

If,  removed,  fit  the  two centralising  blocks  t o
the outer frame  and  secure with  adhesive.

10.

To

release

the

latch

from

the

glass

t h e

two

screws  and  withdraw

the  latch  and  backing  plate.

12.

Secure  a  new  seal  t o   t h e   outer  closing  e d g e

of

the  frame  avoiding  a  join  along  the  hinge

side.

Continued

I:

:.:

....

.,.

BODY

76

ST2

10

13.  Clean  t h e   area

of

contact  on  t h e   vehicle  roof

then  Lower  t h e   frame  into  position  o n   t h e

roof.

14.

From  inside  t h e   vehicle,  offer-up  t h e   retaining
frame  and  secure  t o  the  outer  frame  with  t h e
fifteen  screws.

15.

If

removed,  fit  t h e  latch

to

the glass  panel  with

t h e   backing  plate  and

two

instruction  10.

16.  Secure  the  interior  finisher  t o   the  retaining

frame with  t h e  fourteen  dowels.

17.

Fit

and  secure  the  latch  finisher  with  t h e   two

screws.

18.

Fit

the  glass  panel  and  latch  assembly  squarely

to

the outer frame.

19.  Lower  t h e   latch  o n

to

t h e   pivot  bar,  ensuring

that  t h e   bar  locates  in  its  cradle,  and  whilst
pushing  the  red  button  upwards,  close  t h e

latch  hasp  over  the  bar  until  it  locks  reversing
instruction  3.

To

check  the  operation  and

to

close

the

t h e   green  button  t o   the  right

whilst  pulling  t h e  latch  handle  downwards until

it  snaps into t h e  locked position.

IANDROVER

STATION  W A G O N .

Rear

side window trim.

To

remove

To

gain  access  t o   the  trim  lower  fixings

remove  the  rear  seat  and  squab  frame
complete.

2.

Remove  the  plastic  cover  and  the  seat  belt
anchorage bolt  from  the

post.

3.  Remove  t h e

lower

anchorage  bolt  for  the

same seat belt.

4.

Remove  the  seat  belt  aperature  finisher  from
t h e   trim  panel  and  remove  t h e   rear  quarter
light  trim  from  t h e

side

concerned.

76

BODY

5.

Using  a  screwdriver,  carefully  lever  the  trim
retaining  button  from  the

button

is

held  by  a  "fir-tree"  type  peg.

07.M

8.

The  top  e d g e

of

the  trim  is  held  t o   the  inner

cant  rail  by  three  spring

upwards,

with  the  hand,

as

illustrated,  t o   release  the

trim.

6 .

Remove  the  trim  lower  three  fixings.  The

forward  fixing

is

a  screw,

two

washers  and  a

nut.

7.

The  rear  and  centre fixings  are  a screw, washer

and  a  nut  welded  t o  a

the screw is

removed  the  plate  will  fall  into  the  boxed
section  of  the attachment  side  member.

Feed  t h e   seat  belt  through  the  aperature  and
remove t h e  trim  from  the vehicle.

Continued
