TRANSMISSI

O

8.

Fit  the

selector jaw  t o   the  rail  and

align t o  accept t h e  retaining

roll

pin.

9.

Using  a  suitable  drift,  tap-in  the

roll

pin  t o

secure the jaw  and  rail.

10.

Repeat  instruction

for

the  third/

fourth

selector rail  and  jaw.

11.

Push  the  fifth  gear  selector  rail  through  the

gearbox  and  the  reverse  cross-over

lever.

12.

Fit

the  fifth  gear  selector  jaw  t o   the  rail  and

align

to

accept  the  roll  pin.

13.

Locate  the  selector  rail  into  the  fifth  gear

selector

fork

and

secure

with  the

pin,

washer  and  split  pin.

14.

Secure  the  jaw  t o   t h e   fifth  gear  selector  rail

with  t h e

roll

pin.

15.  Push

the  reverse  selector  rail  through  the

gearbox  and

reverse

cross-over  lever  but  d o

not  tighten  the  lever

clamp

bolt  at  this  stage.

Continued

29

TRANSMISSION

16.

Fit  t h e   jaw  t o   t h e   reverse  selector  rail,  align

t h e   holes,  and  secure with  the  roll  pin  using  a
suitable  drift.  The  pin  must

be

inserted

so

that

it

is

flush  with  t h e   underside

of

t h e   jaw  t o

ensure  that t h e  jaw  is  adequately retained.

17.

Fit  the  reverse  gate  spring  t o   the  selector  rail

and  knock-over  lever.

18.

Fit  the detent  balls  and  springs.

Selector

fork

adjustment.

Fit  the t o p

cover

gasket.

2.  Secure  the  detent  spring  retaining  tool  and

spacers  (manufactured  tool)  t o   t h e   gearbox
with  two  8 x

bolts  and  plain  washers.

9.

Repeat  instructions  4  t o   8  t o   adjust  the

selector fork and  rail.

Reverse  cross-over lever adjustment.

The  purpose

of

the  following  adjustment

is

t o

ensure  that  when  first  gear  is  selected  the  outer
member  of  the  first/  second  synchromesh  unit  is
not  also  engaged with  the reverse  idler  gear.

3.

Tighten  the  bolts  t o   compress  the  detent

springs  until  t h e   retaining  plate  contacts  t h e
two spacers.

4.

Ensure  that  the

selector  rail  and

synchromesh

sleeve

are

in

the  neutral

position.  Tighten  t h e   clamp  bolt  sufficiently

to

eliminate  any

rock

in

the  selector  fork  and

move the selector

fork

rearwards.

5.  Scribe  a  pencil  line

on

the  rail  at  the  rear  of

the fork  yoke.

6.

Move  the

fork

forwards,  t o   the  original

position  and  scribe  another  line  at  the  rear

of

the yoke.

7.

Now

scribe  a  line  midway  between  the

two

lines  on the selector shaft.

8.

Move  the  selector

fork

rearwards

so

that  t h e

yoke  coincides  with  the  centre  line  and
tighten  the clamp  bolt.

1.

Move  t h e   reverse  idler  gear  thrust  washer  fully
forward.

2.

Fit  t h e   manufactured  gauge  t o   the  reverse
idler  gear  shaft

so

that  it

is

between  the  idler

gear and thrust  washer.

3.

Move  the  reverse  gear

selector

rail  rearwards

to

engage reverse  gear.

4.

Move  the  cross-over  lever  rearwards  t o   lightly
nip  t h e   gauge  between  the  reverse  gear  and
thrust washer.

5.

Tighten  the  reverse

cross-over

lever

clamp  bolt

and  return  t h e   selector  rail  t o   the  neutral
position  and  remove  the gauge.

6.

Move t h e

selector rail  rearwards t o

select

first  gear.

---

Continued

30

TRANSMISSION

7.

Check  that  a  minimum  clearance

of

exists  between  t h e   front

face  of

t h e   reverse

idler

gear a n d  t h e  rear  face

of

t h e  reverse  gear

o n   t h e

synchromesh  sleeve.

If

the

clearance

is

insufficient,  adjust  t h e   cross-over

lever again.

8.

Return  the

selector  rail  back  t o

neutral.

9.

Remove  t h e   d e t e n t   spring  retaining  tool  and

spacers

Gearbox

top

cover.

Fit  the t o p   cover gasket.

2.

Fit  t h e   t o p

cover

locating  it  over  the  detent

springs.

3.

Position  t h e   breather  pipe,  locate  retaining
clips  and  secure  t h e   t o p   cover  with  t h e   eight
bolts  and  spring washers.

4.

Fit

t h e   breather

pipe

banjo  union  and  fibre

washers.

5.

Fit  the  reverse  light  switch.

6 .

Place  clean  rag  in

top

cover  gear  lever

aperature

to

prevent  the entry

of  dirt.

lower gear  lever

and bias  spring

housing

1.

Remove  the rag  from  gearbox  t o p  cover.

2.

Lubricate  and  fit  t h e   gear lever  ball  lower yoke

3.

Fit  a  new gasket  t o  t h e  housing.

4.

Fit  t h e  rubber grommet.

5.

Apply  grease

to

the  bias  springs.

6.

Fit  the  shims  and  bias  springs,  followed

by

the

7.

Secure  with  the  four  set  screws  and  spring

and  nylon  cup.

spring  housing.

washers.

31

TRANSMISSION

Bell

housing.

Fit  a  new

bell

housing  gasket.

2.  Locate  the  bell  housing  squarely  o n   the

dowels  and  secure  t o  t h e  gearbox with  t h e

six

bolts  and  spring washers.

Gearbox  extension  housing.

Remove  the  gearbox  assembly  from  the  vice
and  detach  the stand.

2.

The  special  nut  retaining  the  fifth  gear  t o   the

layshaft  must  be  secured  by  carefully  forming
the  collar  of the  nut  into  the  layshaft  slots,

as

illustrated.

CAUTION:

round  nose  tool  must  be  used

for

this  operation  to  avoid  splitting  the

of

the

nut.

Also,

the

layshaft  fifth  gear  should  be

supported  by  a  block

of  timber  whilst  the  nut  is

being  deformed  to  prevent  damage

to  the

adjacent bearing.

3.

Support

the  underside

of

the  gearbox  with  a

block

of

timber.

4.

Lubricate  t h e   oil  seal  protection  sleeve  LST
102

and  insert  it  into  the  oil  seal  from  inside

the extension  housing.

5.

Fit  a  new gasket  t o  t h e  extension  housing.

6 .

Carefully slide t h e   extension  housing,  with  t h e

seal  protection  sleeve  in  position,  over  t h e
mainshaft and  locate o n  t h e  dowels.

7.

Withdraw the

oil

seal  protection  sleeve.

8.

Secure  the  extension  housing  with  the  eight
bolts,  spring  washers  and  single  nut.  The
illustration  below  shows  t h e   correct  length  of
bolt

for

each  of  t h e  eight  locations.

ST

32
