TRANSMISSION

Remove  the  seven  bolts  and  withdraw  the

front cover and  gasket.

layshaft  front  bearing  spacer  and

shims.

14.

Lift-out the layshaft  assembly.
Remove  the  mainshaft assembly.

14

9.

Remove  t h e   gearbox  case  and  stand  from  the

vice.

Remove  t h e

from the case.

11.

Remove  t h e   seven  bolts  that  secure  the  two
halves

of  the case  together.

Rest  the

case

o n   the  bench  with  the  reverse

gear

idler

side  downwards.

13.

Carefully  separate  the  case  by  tapping  with  a
hide  mallet  alternately  at  the

f o u r

break  t h e   seal.

13

TRANSMISSION

16.  Remove  t h e   reverse  lever  pivot  bolt  from  the

17.  Remove  t h e   reverse  lever  and  spacer from  the

outside of

the  casing.

idler  gear and

case.

18.

To

remove  the  reverse  gear  idler  shaft,  place

the  case  o n   a  block

of  timber  and  with

assistance,  hold  t h e

case  firmly  and. drive-out

the  shaft  using  impulse  extractor  18G  284  and

adaptor

LST  284-1.

19.  Remove  the  reverse

idler

gear.  and  thrust

washer.

INSPECTION A N D  OVERHAUL.

Main gearbox

Note: The  following  instructions  1

to

are  only

necessary

if

the  gear  casings,

plugs

or

dowels are  being  renewed.

Remove  the  drain  plug.

2.

Remove  the

plug.

3 .

Remove  the  interlock  cross  drilling

plug

4.  Remove  the

six

hollow  dowels.

Front  cover.

1.

Place  the  front cover  o n   a  block

of  timber  and

drift-out  the  oil  seal.

2.

Clean  the  cover  and  check

for

damage  o r

burrs.

3 .

Lubricate  the  outer diameter

of  a  new  seal  and

using  a  suitable  tube,  drift-in  the  seal,  lip  side

trailing,  squarely  into  t h e   cover.

Continued

;.-

-

-



TRANSMISSION

Bias  spring housing  and lower gear

1.  Secure  the  housing  in  a  vice  and  remove  t h e

lower  gear  lever  and  nylon  cup.

3 .   Check the rubber  dust cover for damage.

4.

Clean  the  housing,  adjusting  screws  and  bias

5.

Clean  and  examine  the  bias  springs.

6.  Refit  the  bias  spring  screws,  two  turns  only  at

bias  spring adjusting screws.

Check f o r  wear  and  damage.

spring bores.

this stage.

Gearbox  fifth  gear extension housing.

Remove  the  rear

oil

seal  from  the  extension

housing  using  a  suitable  drift.

2.

If

necessary,  renew  the  extension  housing

dowels.

3.

Clean  t h e

the

exterior  and  interior  and  the

mating  faces.

Using

service

tool  LST  102  fit  a  new  seal  t o

the  extension  housing.

Top

cover

I .

Clean

top

2.

Remove  the  t o p  filler plug,  clean,  apply  sealant

3 .

Clean  t h e   gear  lever  housing  and  check  for

and  exterior surfaces.

and  refit.

cracks  and  wear.

15

Bell  housing.

TRANSMISSION

1.

Remove  the  clip  retaining  the  thrust  bearing
carrier  t o   the  clutch  operating  lever

fork

if

still

in  position.

Note:  t h e   clip  is  fitted  during  assembly  t o

prevent  the  bearing  sliding  forward  when

t h e   gearbox  is  being  fitted

to

t h e   engine

and  it  may  b e c o m e   dislodged  in  service

without  detriment.

2.

Withdraw  the  thrust  bearing  and  carrier
assembly from  the sleeve.

3.

Remove  the  bolt  and  spring  washer  securing

t h e  operating lever  pivot  clip  t o  the

lever.

4.

Remove  the  operating

lever

and  pivot  slotted

washer.

5.

Remove the  operating  lever pivot.

6 .   Unscrew  the  single-  bolt  and  remove  the

bearing  sleeve from  the  bell  housing.

Input  shaft

1.

Remove  t h e   fourth gear  baulk  ring  and  needle

roller

bearing.

7.  If

necessary,  remove  the  bearing  sleeve

8.

Clean  the  bell  housing  exterior  and  interior'

9.

Apply  grease

to

t h e   lever  pivot  and  inner

10.

Reassemble  the

bell

housing  in  t h e   reverse

dowels.

and  mating  faces.

diameter

of

bearing  carrier.

order

of

dismantling.

2 .

Remove t h e  circlip  and  selective  thrust  washer.

3.  Remove  the snap ring  from  the  bearing.

16
