DEFENDER

ENGINE

CAMSHAFT

Service  Repair No.

12.13.02.

Remove and  refit

1.

Remove the  bonnet and  disconnect  the
battery.

2.  Disconnect  the radiator  bottom  hose and allow

the coolant  t o  drain  and  reconnect the hose.

3.

Remove  the radiator  top coolant  hose,

4.  Remove the fan and viscous  coupling

assembly,

see operation  26.25.1

9.

instructions

4  t o  7.

5.  Remove the fan  cowl.
6.  Remove  the radiator,  s e e  operation  26.40.01.

7.

Remove the air  cleaner,

see

operation

instructions

t o

5 and

t o

19.1

0.01.

instructions

t o  5.

instruction  5 t o  9.

bracket,

see operation

instructions

t o  9.

where fitted, and t h e  mounting bracket
together with  the platform secured by  four
socket headed  bolts.  Note that t h e  hoses  must
not  be removed from the  compressor but  it
should

be carefully secured  t o  o n e  side.

Remove the alternator,

see operation

9.  Remove the power  assisted  steering p u m p

10.  Remove  the air conditioning  compressor,

...

11.

Remove the exhaust  and inlet  manifolds, s e e

operation 30.15.01  instructions 4  t o  15.

12.  Remove the cylinder  head,  s e e  operation

instructions  6

to

and

t o

13.  Now follow the  instructions  in  ENGINE

OVERHAUL

section  12.

SEE

INDEX:-

Operations with  engine  installed  in  vehicle

Refitting

14.

16.

19.

Follow the instructions  for fitting  the camshaft

and assembly

of

the engine u p  t o  the fitting

of

the

rocker cover, crankshaft damper and

pulley.
Fit  the inlet  and exhaust manifolds

see

operation  30.15.01  instructions 1 6  t o  24  and
27.
Fit  the power assisted steering  pump bracket
and  secure and  the four bolts.
Fit  the power steering pump t o  the bracket

with  the single pivot  bolt  and clamp bolts.

Leave the bolts slack  at this  stage.
Fit  the alternator t o  t h e  common  bracket,  see

operation

instructions 1 0  t o

15.

Where  applicable, fit  the air  conditioning
compressor and tension the drive  belt

as

follows:- Move the compressor clockwise
about the pivot  bolts

(do not use a  lever

against  the pump) until  the belt deflects  1 2

at  the

mid

point

of  the run

between  the compressor and crankshaft
pulleys

Tighten  the pivot  and  clamp  bolts.

the

is is

contact with  the belt  or

clear

of  the

belt  and tighten  the damper

bolts.

31

20.  Fit  and tension  the power steering pump drive

belt,

see operation

instruction  10.

Take  note

of  the

CAUTION

when  tensioning

the belt.

21.  Fit  the air

s e e  operation  19.10.01

instructions

1 2

t o  14.

22.  Fit  the radiator,

see operation  26.40.01

ENGINE

DEFENDER

POWER  STEERING  PUMP

Service  Repair

N o .

12.25.22

Remove a n d  refit

Disconnect  t h e  battery.

2.

Remove the air cleaner,  s e e  operation

19.1 0.01.

3.

Remove the alternator,  instructions  2  t o

operation  86.1 0.02.

4.  Remove the steering p u m p

two  adjustment

clamp bolts  and remove the drive  belt.

5.  Remove the single pivot  bolt.

\\

instructions 9 t o  15.

23.  Fit  the fan  cowl  in  position  but  d o  not secure

t o  the radiator.

retaining  bolts.

24.  Fit  the fan  and coupling  assembly, s e e

operation 26.25.19  instructions

to

11.

25.

Fill

the cooling system,

see operation  26.10.01

instructions 5 to

6 .

Move the pump aside

the two  hoses still

attached  t o  gain  access

to

t h e  bracket  f o u r

7.

Remove the single

long bolt  through  the

Remove t h e  single bolt  frpm t h e  front  into the

cylinder

block  into the  bracket.

cylinder block.

C o n t i n u e d

32

DEFENDER

ENGINE

9.

Remove the two  bolts  inside the bracket  into

the front cover and  remove  the bracket  and
triangle shaped packing  plate.

Refitting

10.

12.

13.

14.

16.

I

.



Fit  the bracket  t o  the cylinder block with  the

f o u r  bolts,  reversing  instructions

to

9.

Loosely  secure the pump  to  the bracket with
the three

bolts.

Fit  and tension  the drive belt.

CAUTION:-  Do not apply any pressure

against the pump casing when tensioning
the drive belt since it will  damage the
casing,  permanently, beyond  repair.

Tighten  the two  clamp bolts  and single pivot

bol.  The  belt  is  correctly tensioned when the
belt  can  be deflected  by thumb pressure  1 2

Fit  the alternator and  tension  the drive  belt,

see operation  86.10.02.
Fit  the air  cleaner.
Connect  the  battery,  run  the engine at  a fast
idle

for approximately three to  five minutes.

Stop the engine and check  the drive  belt
tensions.

CYLINDER  HEAD

Service Repair  No.

Remove  and refit

2.

3.

4.

5.

7.

8.

9.

10.

11.

12.

13.

14.

15.

16.

17.

Remove  the bonnet  and disconnect the
battery.
Drain  the coolant.

Remove  the radiator  t o p  hose.
Remove  the exhaust  and inlet  manifolds,

complete with  turbo charger

see operation

30.29.02.
Remove  the heater rail.
Remove  the thermostat t o  waterpump  hose.
Disconnect  the electrical  leads fromthe

thermostat  housing sensors.
Disconnect the harness from  the alternator.
Remove  the heater h o s e  from the cylinder
head.
Remove the axle  breather pipe  bracket  from

the rear

of  the cylinder  head.

Remove the fuel  pipes from the injectors and
injector pump.
Remove the spill return  pipes  from the
injectors.
Remove the injectors  and washers and  place  in
a clean,

container,

for

safe keeping.

Remove  the electrical  leads from  the  heater

Remove the heater plugs and store in  a safe

place.
Remove the hose from the  breather  valve.
Follow  the instructions  in  the

ENGINE

OVERHAUL

section  12.

SEE

INDEX:-

Operations with engine installed  in  vehicle.

plugs.

Continued

33

ENGINE

DEFENDER

Refitting

18.  Follow the  instructions in  ENGINE

OVERHAUL

from  "fitting cylinder  head"  and continue  until
the

rocker cover

is

fitted.

19.  Fit  the heater  plugs  and connect the electrical

leads.

Do not allow any part

of

the lead

or

insulation  t o  touch  t h e  cylinder head  when
fitted.

20.  Fit  the injectors

s e e  ENGINE

OVERHAUL.

21.  Fit  the spill  retum  pipes t o  the injectors.
22.  Fit  the supply pipes

to the injectors and  pump.

23.

Fit  the  hose t o  the breather valve.

24.  Fit  the axle  breather bracket.
25.  Fit  the  heater  hose

to cylinder head.

2 6 .

Connect the hamess t o  the altemator.

27.  Fit  the waterpump  t o  thermostat  hose.
28.  Connect the leads t o  the

sensors.

Fit  the inlet  and exhaust manifolds  and heater
rail.

30.

Fit  the radiator t o p  hose.

31.

Fill

the cooling system,  s e e  operation 26.10.01.

32.  Fit  the bonnet.

....

34
