Defender 90 / 110 / 130. Manual - part 153





Battery condition  indicator

2.

Cigar lighter illumination

3.

Oil temperature  indicator

4.  Water temperature  indicator

5.  Fuel indicator illumination
6.  Speedometer illumination
7.  Door switches (when fitted)

8.

Rear fog

9.  Reverse lamp

illumination

illumination

illumination

IO.  Number plate lamp

L H  tail lamp

12.

LH side lamp

13.

tail lamp

14.

side lamp

15.

L H  headlamp main beam

16.

headlamp main beam

17.

LH headlamp dip beam

18.

headlamp dip beam

19.  Interior lamp (when fitted)

20.  Interior lamp switch
21.

Horn

22.  Stoplamp
23.  LH side repeater
24.

L H  front indicator

25.

LH

rear indicator

26.

side repeater

27.

front indicator

28.

rear indicator

29.  Front fog feed
30.  Rear fog switch

Reverse lamp switch

32.  Washer pump
33.

washer pump connection

34.

L H  washer pump connection

35.  Steering column switches

36.

'Trailer warning light

37.  Side light warning light

KEY TO COMPOSITE CIRCUIT DIAGRAM

38.

Rear fog warning light

39.

Main beam warning light

40.  Spare
41.  Low fuel warning light
42.  Locked 4WD warning light
43.

Spare

44.  Cold start warning light
45.  Locked 4WD switch
46.  Spare
47.  Oil warning light
48.  Ignition warning light

49.  Brakes warning light
50.  Park brake warning light
51.  Spare
52.  Direction  indicator warning light

53.

Spare

54.  Seat belt warning light

Wiper motor

56.  Norwegian daytime running lights

57.  German fuel shut off  and Norway

58.  Oil pressure switch
59.  Pressure differential warning

actuator switch

60.  Park brake switch (when fitted)
61.  Seat belt switch (when fitted)
62.  Fuses
63.  Clock (when fitted)
64.  Stop lamp switch
65.  Brake check relay
66.  Heater connections
67.  Flasher unit
68.  Ignition light resistor
69.  Light switch
70.  Auxiliary

Hazard unit

72.  Starter solenoid
73.  Cigar lighter (when fitted)

a) Australia
b) Rest

of

World

connection

connections

Key to cable colours

74.  Start relay

75.  Spares
76.  Auxiliary instrument illumination
77.  Spare auxiliary  instrument
78.  Spare
79.  Starter inhibitor switch (auto only)
80.  Fuel pump (petrol only)
81.  Connector

Diesel

82.  Connector - common
83.  Connector-

petrol

84.  Fuel indicator
85.  Water temperature indicator
86.  Oil temperature indicator
87.  Alternator
88.

Petrol ignition switch

89.  Diesel ignition switch
90.  Feed snap connector
91.  Feed snap connector
92.  Ignition snap connector
93.  Starter snap connector
94.  Auxiliary snap connector
95.  Heater snap connector
96.  Fuel shut-off snap connector
97.  Battery
98.  Battery condition  indicator

Radio (when fitted)

(when fitted)

100.  Tank unit - for twin tanks system
101.  Water temp transmitter
102.

Oil temperature transmitter (when fitted)

103.  Glow plugs (Diesel only)
104.

Fuel shut off solenoid

105.  (4 cylinder petrol only) coil

Distributor (4 cylinder petrol only)

107.

2 CE unit

only

108.  Distributor-
109.  Choke switch (petrol only)
110.  Air conditioning feed (when fitted)

BBlack  GGreen

LLight

Brown  OOrange

R  Red

White

Yellow

The last letter of

colour code denotes the tracer colour

Connectors via plug and socket

Snap connectors

Permanent in-line connections

Earth connections via cables

Earth connections via fixing

bolts

ELECTRICAL EQUIPMENT-

CIRCUIT DIAGRAMS

DIM-DIP CIRCUIT

UNITED KINGDOM ONLY

BATTERY

15

IGNITION

HEAD  SWITCH

FOQ

RELAY

in-line connections lettered

A ,

B,

D, E and F connect into the corresponding

connections i n

main

composite circuit diagram.

74

ELECTRICAL EQUIPMENT-

CIRCUIT DIAGRAMS

ws

- -  -

BS

CIRCUIT DIAGRAM - TWIN TANK - TWIN PUMPS

ws

G B

G B

BS

Low fuel warning light

2.  Fuelgauge
3.

Relay 28RA low level warning

Relay 28RA Fuel gauge

5 .   Relay 28RA Fuel pumps
6.  Rear tank

unit

7.  Side t a n k  unit

12

75

WG

10

86

ELECTRICAL EQUIPMENT-

CIRCUIT

DIAGRAMS

KEY

TO TERMINATIONS

RA

(normally closed position)

2.  4

way moulded connecting tube

3.  6

way moulded connecting tube

4.

Pin and socket connector

5.  Clinch connections
6.  Earth connections via cables
7.

Fuse

8.

Bulb connections

CIGAR LIGHTER

POWER WASH SYSTEM

Power wash timer

2.

Ignition feed

3 .

Screen wash pump

4.

Screen wash switch

5.  Dipswitch
6.  Power wash pump

1 .

Ignition feed

2.

Side light circuit

4.

Cigar

5.  Australia Only (dotted line)
6.  Standard Circuit (solid line)

76
