ELECTRICAL

E

QUI

P

ME

NT

LAMPS

Assemble

and refit

13.

Fit  the rim  seating to the headlamp shell with  the

two trimmer screws and coil spring.

14.

Fit the rubber

to

the headlamp shell.

15.  Conncct

to

the bullet connectors.

16.  Fit  the headlamp shell into the front wing  locating

the trimmer screws into the two holes in  the wing.
Ensure that

assembly is located,

as illustrated,

with  one  trimmer  screw at  the  12 o’clock position
and the other

90” t o

Icft.

17.

Secure the shell assembly

to the wing with the four

screws.

18.  Offer-up  the  light  o r

unit  t o   the  rim

seating and connect the electrical plug.

19.  Secure the assembly with the rim and three screws.

20.  Fit the plastic bezel with the six screws.
21.  Connect  the  battery  and  check  that  the  lamps

function.
Check

main  beam  setting  using

setting

equipment.  Should  this not be  available the  beam

can  be  temporarily

and  adjusted

in

following way:-

23.  Position  the vehicle on level ground  with  the tyres

correctly inflated,  approximately four meters from
a wall or screen, marked

as illustrated.

24.  The beam centres ‘A’ are measured horizontally on

the  vehicle  and  the  dimension

‘B’ vertically  from

the ground.

25.  Switch-on the main beam  and adjust

necessary with

screws.

15.

13

..

49

ELECTRICAL EQUIPMENT-

LAMPS

SIDE, TAIL AND FLASHER LAMPS

Renew bulbs and lamps

1.  Disconnect the battery.

2.  Remove  the  two  screws  and  fibre  washers  and

withdraw  the  lens  and  collect  the  two  rubber
washers inside the lens.

3.  Push the bulb inwards, twist and withdraw.
4.  Remove  the  three  screws  and  withdraw  the  lamp

holder  complete.  Disconnect  the  electrical  leads
from the  bullet  connectors inside  the vehicle  wing

for  the  front  lamps.  For  rear  lamps  remove  the
cover inside the body for access to the connectors.

5 .

If  necessary remove t h e  rubber bulb holder cover.

REAR NUMBER PLATE LAMP

Remove and renew bulbs

1.  Disconnect the battery and remove the single screw

2.  A t  this stage the bulbs only can be renewed.
3.

Disconnect the electrical leads.

4.  Remove the cover from inside the vehicle body.

5.

Remove  the  two  nuts  and  washers  securing  the

6.  Remove the bulb holder complete with  rubber seal

securing t h e  lamp cover and lens.

lamp to the vehicle body.

and mounting block.

Refitting lamp and bulbs

6.  Fit the rubber cover to the lamp holder.
7.  Ensure  that  the  drain  gap  in  the  cover  is  at  the

8.  Connect  the  electrical  leads  to  the  bullet

9.  Fit the lamp to the vehicle, observing instruction  7,

bottom.

connectors.

and secure with the three screws.

10.  Fit the bulb of the same wattage, if renewed.
11. Fit  the

lens  ensuring  that  the  rubber  and  fibre

washers  are  corrcctly  positioned.  Evenly  tighten
the  two  screws.  Overtightening  could  crack  the
lens.

Refitting lamp and bulbs

7.  Assemble  the  bulb  holder  and  rubber  seal  to  the

mounting  block,  connect  the  leads  and  fit

to

the

vehicle body with the two screws and nuts.

8.  Fit the bulbs.

9.

Fit  the  lens  and  lamp  cover  and  secure  with  the

single  screw.  Connect  the  battery  and  test  the
lamp.

50

ELECTRICAL EQUIPMENT -

LAMPS

Renew the bulbs

1.  Disconnect

battery.

2.  Remove two screws and withdraw the warning light

module from the front of  the instrument panel.

3 .   Pull  off  the  plug  connector  to

give  access  to

warning light bulbs.

4.  Twist the bulb holder and pull it from its socket.

5 .

Pull the bulb from the holder.

6.

Fit  a  new  bulb  and  refit  the  holder  and  plug

connector.

7.

Refit the module.

8.

Connect the battery.

. . .

ST

INSTRUMENT ILLUMINATION

Renew

bulbs

1. Disconnect the battery.

2.  Remove  the  four  screws  rctaining  the  instrument

3 .   Ease forward the panel to gain access to the bulbs.

panel.

If  necessary,  disconnect  the  drive  cable  from  the
back

of  the speedometer.

4.

Twist the bulb holder and pull it from its socket.

5.

Pull the bulb from its holder.

6.

Fit a new bulb and refit the holder.

7.  Replace the instrument panel.
8.  Connect the battery.

ST

51

86

OVERHAUL WIPER

MOTOR

ELECTRICAL

EQUI

P

MENT

-

WIPER

MOTOR

DISMANTLE

1.  Removc

wiper  motor  and  drive  from  the

2.  Remove t h e  wiper motor gearbox cover.
3.  Remove  the  circlip  and  plain  washer  securing the

4.  Withdraw t h e  connecting rod.

5 .

Withdraw the flat washer.

6.

Remove  the  circlip  and  washer  securing the  shaft

7.

Clean  any  burrs  from  the gear shaft and  withdraw

8.  Withdraw the dished washer.
9.  Add  alignment  marks  to the yoke  and gearbox  for

vehicle.

connecting rod.

and gear.

the gear.

reassembly.

10.  Remove the yoke securing bolts.
11.  Withdraw

yoke and armature.

12.  Remove the brush gear assembly.
13.  Remove the limit switch.

16.  Test  the  armature  for  insulation  and  open-

or

short-circuits.  Use  a  110 V

15 W  test  lamp.  Fit  a

new armature

if faulty.

17.  Examine  the  gear  wheel  for  damage

excessive

wear.

ASSEMBLE

Use  Ragosine

Grease  to  lubricate  the  gear

wheel teeth, armature shaft worm gear, connecting

rod

and pin, cable rack and wheelbox gear wheels.
Use  Shell  Turbo  41  oil  sparingly  to  lubricate  the
bearing  bushes,  armature  shaft  bearing  journals,  gear
wheel  shaft  and  wheelbox  spindles.  Thoroughly  soak
the felt washer

in the yoke bearing with oil.

18.

Fit the limit switch.

19.

Fit

the brush gear assembly.

INSPECTION AND TEST

14.  Check  the  brushes  for excessive

if  they  are

worn  to

4,8

in)  in  length,  fit  a

brush gear asscmbly.

15.  Using  a  push  type  gauge,  check  that  the  brush

spring pressure is

to

( 5

to

when

bottom of  the brush  is  level with  the bottom  of  the
slot in the brush box. Fit a new brush gear assembly
if

the springs are not satisfactory.

1.

Flexible drive

6.

G e a r  shaft retaining washer and circlip

7.  Drivegcar
8.  Dished washer
9.  Alignment marks - yoke to body

10.  Yoke securing bolts

Armature and yoke

12.  Brush gear assembly
13.  Limit switch

52
