AIR CONDITIONING -

L.H.

R.H.

STEERING

C H A R G I N G  AND TESTING E Q U I P M E N T

Connecting the gauge set

NOTE  1:  There  are  two  methods  of  connecting  the
charging  and  testing  equipment,  depending  on  the
operation  to be  carried out.  The method  described  for
‘evacuating

or  charging  with  liquid  refrigerant’  also

applies  to  ‘pressure  test’  and  ‘compressor  oil  level
check’ operations.

NOTE  2:  Various  types

of  charge and  test  equipment

are available depending  upon the manufacturer chosen
by  the  user.  The  equipment  illustrated  may  differ
slightly in layout to that possessed by the user,  however,
it  is  recommended  that  the  user  adheres  to  the
appropriate manufacturer’s  instructions  for the charge
and

test

equipment used in their workshop.

-NOTE:  The  boxed  instructions  in  the  following

procedure  refer  to  compressors  with  STEM  type
valves.

All

other instructions  refer  to

SCHRADER

type valves.

Fitting

1. Ensure  that  all  the  valves  on  the  charging  and

testing equipment are closed. Control valves

on the

particular  equipment  selected are numbered  1 to 4
as  illustrated.

The  sequence  may  vary  on  other

proprietary  equipment.

2.  Mount a

(25 Ib) drum of  refrigerant upside

down  on  the  support  at

the  rear  of  the  charging

equipment, and secure with the strap.

ST

6.  Place  the  vehicle  in  a  ventilated  area  away  from

open  flames  and  heat  sources.  Stop  the  engine,
open and secure the bonnet.

7.  Check  that  both  service  valves  are  fully  opcn

(turned anti-clockwise).

8.  Put on the safety goggles.
9.  Remove  the  caps  from  the  gauge  connections  on

the service ports.

10.  Coat the threads and flares with refrigerant oil.
11.  Connect the low pressure charging

line

(blue)

valve No. 1 to the comprcssor suction service

port.

12.  Connect the high  pressure charging

from

valve  No.  2  to  the  compressor  discharge  scrvicc
port.

13.  Using  the  service  wrench,  turn  the  suction

service  valve  stem  ‘clockwise’  counting  the

number

of  turns necessary to close the valve.

ST

ST

1412

3.  Connect the hose from  the bottom  of  the charging

cylinder to the refrigerant drum valve.
Connect  the  hose  between  the  bottom

of

the

charging cylinder  and the refrigerant control valve

5.

Connect the hose between the vacuum pump valve

14.

After  the  valve  is  fully  closed,  turn  the  stem

out  (anti-clockwise)  half  the  number

of

turns

counted,  this should  position  t h e  valve  seat

in

the mid (test) position.

11

(No. 4).

and the vacuum control valve (No.

3).

A

IR CONDITIONING -

L

.

H.

R

.H. STEERING

WARNING:  Open  connections  slowly,  keeping  the

Turn the stem on  the discharge valve clockwise
until

the  pressure  rises  on  the  discharge

pressure  gauge.  If  the  system  is  to  be
evacuated,  the  discharge  service  valve  seat

16.  The  charging  and  testing  equipment  is  now

connected  and  ready  for  proceeding  with  the
required operation.

Close  the  compressor  discharge  service  port
(turn anti-clockwise).

Removing

17.  If the engine has been operated,

it

must be stopped

prior  to  disconnecting  the  charging  and  testing
eq  i

en

18.

Close both  service ports  (turn fully anti-clockwise)
until

fully closed.

19.

Close  all  valves  on  t h e   charging  and  testing

equipment.

20.

Disconnect  the  charging  lines  from  the  service

ports.

21.  Refit  the  blanking  caps  to  t h e   compressor  valve

stems and service ports, and to the charging lines.
Close the bonnet.

AIR

CONDITIONING

SYSTEM

OPERATIONS

Depressurising

NOTE:  The  air  conditioning  refrigeration  system
contains

12’

under  pressure,  and  before

any  component

is

disconnected or removed,  the system

be discharged of all pressure.

12

evaporates

so  rapidly  at  normal

atmospheric pressures and temperatures that it tends to
freeze anything it contacts.  Extreme care must be taken
to  prevent  any  liquid  refrigerant  from  contacting  the
skin  and  especially  the  eyes.  Should  any  liquid
refrigerant  get  into the eyes,  use  a  few  drops of  sterile

oil  to  wash  them  out  and  then  wash  the  eyes

with

a  weak  solution  of  boric  acid.  Seek  medical

attention

even  though  the initial  irritation

has ceased

first aid treatment.  Always wear safety

goggles

refrigerant

1.  Place  the  vehicle  in  a  ventilated  area  away  from

2.  Stop the engine.

3.  Open and secure the bonnet.
4.

Remove  the  caps  from

compressor  service

5 .   Check that both compressor service valves are fully

6.  Close  all  valves  on  t h e   charging  and  testing

7.  Put on safety goggles.
8.  Connect the high pressure charging line (red) from

valve

No.  2  to  the  compressor  discharge  service

port.

9.  Run the (blue) hose

to

an open tapped container of

approximately one  litre  capacity.  Attach  the  hose
to the container  so that  it  will  not  blow  out of  the

container.  The  purpose

of  the  container  is  to

collect any

oil

carried by the refrigerant.

open flames and heat sources.

ports.

opened (turned anti-clockwise).

equipment.

10.  Open  the  compressor  discharge  service port  a

quarter

of  a turn.

11.  Open valve

No. 2 fully.

12.

Slowly  open

t h e

valve  No.

turn  to  allow  the

refrigerant  to  escape,

if

necessary,  adjust  the

refrigerant  flow  so  that  the  oil  captured  in

container is not blown out of

container.

11

ST

13.  Measure  the  amount  of  oil  discharged  from  the

system

so  that  an  equal amount  of  new  oil  can

returned  to  the  system  during  the  charging
operation. Discard the old

oil.

14.  When  the  gauge  pressure  is  below

50  psi,  slowly

open the valve No. 1 to maintain refrigerant flow.

When  the  pressure  has  been  reduced,  and  t h e

system  has  been  completely  discharged,  close  the
valves

Nos.

and

on

the  charging  and  testing

equipment.

AIR CONDITIONING

L.H.

R.H. STEERING

2.  Adjust  both  service  valve  seats  to  the  mid

(Test) position.

NOTE:  If

it

is  necessary

to  disconnect  the  compressor

hoses,  the compressor  should  be  sealed  by  fully  closing
the  relevant  service  valve  (turn  fully  clockwise).  It  is

essential

to  ensure  that  both  service  valves  are  open

before  operating  the  compressor.  Similarly  any  other
component of the refrigeration system should be capped
immediately when disconnected.

18.  Open the refrigeration  drum valve.
19.  Open the valve at the base

of  the charging cylinder

and  allow  approximately

(0.5 Ib)  of

refrigerant to enter

t h e

cylinder.

20.  Close the refrigeration  drum valve and the valve at

the base

of

the charging cylinder.

21.  Open  the  refrigerant  control  valve  (valve

No.

4)

and  flush

out  the  high  and  low  pressure  lines  by

opening  valves

Nos.  1 and  2  momentarily  until  a

white stream of refrigerant  is observed.

ST

22.

Close  all

on

t h e

charging  and  testing

23.  The air conditioning system

is now depressurised.

equipment, and fit the blanking caps.

Evacuating

Whenever

has

atmosphere

it

is necessary that the system be evacuated

to  remove  all  air  and  moisture.  I t   is

also  an  essential

preliminary  operation  to  charging  the  system  with
Refrigerant  12. The evacuate operation also provides a
check  for leaks due

faulty connections.

1. Depressurise  the  air  conditioning  system  as

previously described, then

t h e

gauge set as

detailed under 'Charging and Testing Equipment'.

3.  Open  the  low and  high  pressure valves  Nos.  and

2.

4.

Start the vacuum  pump and

vacuum

pump valve is open.

5.  Slowly open the vacuum control valve

No. 3. If the

vacuum  is  applied  to

system

too  quickly,  the

residual oil may bc drawn out.

ST

6.

In evacuating the system

i t

is necessary

to lower

pressure

so  that  the  boiling  point  of  water  in  the

system  is  lower  than

the

surrounding  air

At

an ambient temperature of

it

is  necessary to lower

t h e

system  pressure

to

29.5

in  Hg vacuum

to

bring  the  boiling  point  of

water

to

22°C  (72°F).  Atmospheric

(and

vacuum  gauge  readings)  decrease

as  altitude

increases  by

25

( I

in)

per

300

m  (1000 ft).  The  following  chart  provides

guide  to  the  various  gauge  readings

at

altitudes,

for the same 10

(0.4 in)

Hg absolute

pressure.

Altitude,

f t

Vacuum

Reading

in

Hg

29.5

750

1,000

300

28.5

725

2,000

600

27.4

695

3,000

26.4

670

4,000

1200

25.4

645

24.5

6,000

1800

23.5

596

7,000

2100

22.6

574

8,000

2400

554

9,000

2700

20.9

10,000

3000

20.1

510

13

7.  The  low  side  gauge  should  indicate  a  vacuum  of

660

(26 in) Hg within five minutes.

8.  Whilst  the  system

is  evacuating,  fill  the  charging

cylinder by opening the refrigerant  drum

9.

the valve  at the base of  the charging cylinder

and  fill  the  cylinder  with  1,0

(2.2 Ib)

of

refrigerant.  Liquid  refrigerant  will  be  observed
rising in

sight glass.

10.  As  the

stops  filling  the  cylinder,  opcn

the  valve

t h e

top  of  t h e   cylinder  (behind  the

control  panel)  intermittently,  to  relieve  the  head
pressure  and  allow  the  refrigerant  to  continue
filling the cylinder.

11.

When  the  refrigerant  reaches  the  desired  level

in

sight glass, close  both  the  valve  at  the

of

the  cylinder  and  the  valve  at

bottom

of  the

refrigerant tank.

12.

Ensure  the  top  cylinder  valve  is  fully  closed.  If
bubbling  is  present

in  the  sight  glass,  reopen  t h e

cylinder  base  valve  momentarily  to  equalise  the
drum and cylinder pressures.

13.

If  660

(26 in)  Hg  of  vacuum  is  not  achieved

within

minutes,  it  signifies  either  the  system

has  a  leak  or

vacuum  pump  is  dcfcctive.

Initially  check

vacuum  pump,  if

pump

proves  to  be  functioning properly  then  investigate
for a leak in

air conditioning system.

14.

Close

vacuum control valve No. 3.

15.  Stop  t h e  vacuum  pump  and  allow  the  vacuum  to

hold  for fifteen minutes, then check that there is no
pressure  rise  (a

loss  of  vacuum)  evident  on  the

compound gauge. Any pressure rise denotes a leak
which  must  be rectified  before

further.

Refer

to

the  heading  titled  ‘Leak  Detection’ later

in

this section.

16.  With

system  satisfactorily  evacuated,  the

system is ready for charging with refrigerant.

A

IR

CONDITIONING -

L

.

H.

R

.

H

ST

EERING

ST

Sweeping

NOTE: This operation is in addition to evacuating,  and
is to remove moisture from systems that have been open

to  atmosphere for

a  long  period,  or  that  are known to

contain excessive moisture.

1.  Fit  a  new  liquid

as  detailed

the heading
Ensure  that  a  full  drum  of  refrigerant  is  fitted  on

the charging and testing equipment.

3.

Fit  the  charging  and  testing  equipment  as

previously  described  for  evacuating  and  evacuate
the  air  conditioning  system,  allowing

to

to  1 Ib)

of  refrigerant  to  enter  the

charging cylinder.

4.  Close  all  valves  on  the  charging  and  testing

equipment.

5 .

Disconnect  the  intake  hose  from

vacuum

ST

6.  Connect

intake hose to

valve  at the  top of

the

charging cylinder.

7.  Open the valve at the top of  the charging cylinder.
8.  Put on safety goggles,
9.  Crack open  the hose connection at valve No. 3 and

allow  some  refrigerant  to  purge

t h e

hose,  then

close the connection.

10.  Open the high pressure valve (No. 2).
11.

Slowly  open  valve

No.  3, which

is  now  connected

to the top valve of the charging cylinder, and allow
gas to flow into the system  until  the reading on  the
compound  gauge  remains  steady.  Between
and

to 1

of refrigerant will

the

system.

12.

Allow  the  dry  refrigerant  introduced  into  the

system to remain for 10 minutes.

14















Content   ..  129  130  131  132   ..
