Defender 90 / 110 / 130. Manual - part 125





CHASSIS

AND

BODY

Fitting locking button

Fitting regulator

5 .   Secure  the  locking  button  assembly

to

the  door

with the two screws.

6 .

Connect  the operating rod to the latch mechanism

and secure with the spring clip.

7.

Reseal  the  weather  protection  sheet  and  fit  the

door

door pull, regulator handle, and bezels.

REMOVING

WINDOW REGULATOR

front

doors

To

remove

6.

Insert  the  regulator  operating  arms  into  the

channels.

7.

Fit  and  tighten  the  mounting  panel  lower  screws

and tighten  the upper screws.

8.

Position  the  holes  in  the  regulator  to  line-up  with

the holes in the mounting panel and secure with the
four screws.

9.

Temporally €it the regulator  handle and check that
the  glass  can  be  raised  and  lowered  without  tight

spots.

10.

Secure the weather protection sheet with adhesive.

11.  Fit the door trim,  regulator  handle,  door pull  and

bezels.

1.  Remove the door trim.

2.  Remove the weather protection sheet.

Temporarily fit the handle and position the window
half open and support with a length

of

timber.

Remove  the  two  lower  screws  securing  the

doors

mounting panel  t o  the  door and  slacken  the  three
upper screws.

5.

Remove  the  four  screws  retaining  the  window

regulator  to  the  mounting  panel  and  slide  the

1.  Remove  the  door  pull,  regulator  handle,  bezels

operating  arms from  the  channels  attached  to the
glass  and  mounting  panel  and  remove  the

2.  Peel back sufficient

of

the weather protection sheet

regulator.

3.  Release  the spring clip  and disconnect the control

4.

Release the control rod from the plastic clip in  the

REMOVE  REMOTE  CONTROL  LEVER

front

To

remove

and door trim.

to gain access to the remote lever.

rod from the latch mechanism.

mounting panel.

continued

15

5.

Remove  the  two  screws  securing  the  remote

3.  Disconnect  the  operating  rod  from  the  handle

control lever  to  the  mounting  panel  and withdraw
the lever and control rod.

mechanism.

4.

Disconnect the rod from the locking barrel lever.

CHASSIS AND BODY

Fitting remote control lever

6.  Feed  the  control  rod  into  position  and  loosely

secure the lever to the mounting panel with the two
screws.

7.  Connect  the  control  rod  to  the  latch  mechanism

and secure with the spring clip.

8.  Tighten the control lever retaining screws.
9.  Secure  the  control  rod  to  the  plastic  clip  in  the

10.  Secure the weather protection sheet with adhesive.
11.  Fit  the door trim, regulator handle,  door pull  and

mounting panel.

bezels.

REMOVING  EXTERIOR  DOOR  HANDLE

front

doors

To remove

1.  Remove  the  regulator  handle,

door  pull,  bezels

and door trim.

2.

To

gain  access  to the  handle  mechanism,  remove

the  mounting  panel  and  support  t h e   glass  with
timber.

5.

Remove the  two screws  and  withdraw  the  handle

assembly

Fitting the handle

6.  Fit  the  handle  to  the  door  ensuring  that  the  two

bezels  are  in  position

flat  faces  ’towards the

door, and secure with the two screws.

7.

Connect the rod to the handle operating  lever and

secure with the spring clip.

8.

Connect  the  rod  to  the  locking  barrel  lever  and
retain  with the spring clip.

8.  Carry-out  the instructions for fitting  the  mounting

panel and door trim and fittings.

16

C

HASSIS AND B

O

DY

REMOVE THE  DOOR  LATCH  ASSEMBLY

front

doors

76

To remove

1.  Carry out the  instructions  tc remove the mounting

2.  Disconnect  the  control  rod  from  the  handle

3.  Disconnect the control  rod  from  the locking  lever

4.  Disconnect  the locking button control rod from the

panel and support the glass with timber.

operating lever.

on the handle.

latch mechanism.

5 .

Remove  the  two  screws  and  remove  the  handle

assembly from the door. See exterior door handle.

6.

Remove  the  two  self-tapping screws  retaining  the
lower end

of  the window glass runner.

ST  977

7.

Remove  the  three  screws  securing  the  latch

assembly to the door.

8.

Whilst  taking care not  to damage the runner,  ease
it  away  from  the  latch  and  manoeuvre  the  latch
assembly from the door:

Fitting

latch assembly

9.

Carefully

ease

the

window

runner  away,

sufficiently  to  enable  the  latch  to  be  located  into
position.

10.  Secure the latch to the door with the three screws.
11.  Secure  the  window  runner  with  the  two  screws

ensuring  that  the  packing  strip  is  in  position  and
that  the  screw  heads  are  below  the  bottom  of  the
runner to prevent damage to t h e  glass.

12.  Fit  the  handle  with  the  two  screws, ensuring  that

the bezels are in position.

13.  Connect  the  control  rod  to  the  handle  operating

lever and secure with the spring clip.

14.  Connect  the  control  rod  to  the  locking  lever  and

retain  with the spring clip.

15.

Connect the locking button control rod

to the latch

lever and secure with the spring clip.

16.

Carry-out  the  instructions  t o   fit  the  mounting

panel.

17.

Fit  the door trim, regulator handle, door pull, and

bezels.

17

76

REMOVING GLASS

front doors

C

HASSIS A

ND

BODY

To remove

1.  Carry-out  the  instructions  to  remove  the

2.  Remove the window regulator.
3.  Push the glass up to the top

of

its travel and support

with a suitable length

of  timber.

4.  Remove  the  two

self  tapping  screws  securing  the

window  glass runner on  the  latch  side

of  the door

and the single screw from the hinge side.

mounting panel.

I '

5.  Taking  care  not  to damage  the  paint  work,  prise

6.

Remove the timber support and lower the glass to

the exterior waist weatherstrip from the door.

the bottom of  the door.

7.

Ease the runner from the glass at the hinge side

of

the door, lift the glass over the bottom  edge

of  the

door and withdraw.

Fitting

glass

8.

Insert  the  glass  into  the  runners  at  an  angle  as

illustrated.

9.

Whilst  lifting  the  glass,  position  it  squarely  in  the
runners  and  raise  it  to  the  top

of  its  travel  and

insert the timber support.

10.  Secure the hinge side runner  with  the single screw

ensuring that the packing strip is in position.

continued
