STEERING

Sector shaft seal

55.  Fit the

oil seal, lipped side first.

56.

Fit

the extrustion washer.

57.

Fit the dirt seal, lipped side last.

58.  Fit

the circlip.

Fitting the valve and

worm assembly

59.

If

removed,  refit  the  original  shim

and

the inner bearing cap.  Only vaseline must be  used
as an aid

to assembling the bearings.

NOTE:  If  the  original  shims  are  not  available,  fit

of

(0.030 in) nominal thickness.

..

60.  Fit the inner cage and bearings assembly.
61.  Fit  the valve  and worm  assembly,  using seal saver

to protect the input shaft seal.

62.  Fit the outer cage and bearings assembly.
63.  Fit the outer bearing cup.

Renew  the

worm  adjuster sealing ring  and  loosely

screw the adjuster into  the casing.

Fit

the locknut,

but do not tighten.

65.  Turn in the worm adjuster until the end-float at the

input

is almost eliminated.

66.  Measure and record  the maximum  rolling  distance

of  the  valve  and  worm  assembly,  using  a  spring
balance  and  cord  coiled  around  the  torque  setting
tool

67.  Turn

in  the  worm  adjuster to  increase  the  figure

recorded  in  instruction

66

by  1,8 to  2,2

(4

to

5 Ib)  at

(1.250

in)  radius  to  settle  the

bearings, then back

off  the worm adjuster until

figure recorded  in instruction 66 is increased by

0,9

to  1,3

(2  to

only,  with  locknut  tight.  Use

worm  adjusting  socket

and

'C'

spanner

continued

25

ST

EER

I

N

Fitting the rack and piston

68.

Screw a suitable bolt into the piston head for use as

an assembly tool.

69.  Fit  the piston and  rack  assembly so that

piston

is

(2.5 in)  approximately  from  the  outer

end of the bore.

70.  Feed  in  the  sector  shaft

using  seal  saver  606604

aligning the  centre gear pitch

on the  rack  with  the

centre  gear  tooth  on the  sector  shaft.  Push  in  the
sector shaft, and, at the same time rotate the input
shaft about a small  arc to allow the sector roller to
engage

worm.

Fitting the rack adjuster

71.  Fit the sealing ring to the rack adjuster.
72.  Fit  the  rack  adjuster and  thrust  pad  to engage  the

rack. Back off a half

nylon  turn

on the adjuster.

73.  Loosely  fit  the nylon  pad  and  adjuster grub screw

assembly to engage the rack adjuster.

Fitting the sector shaft cover

74.  Fit the sealing ring to the cover.

75.  Screw  the  cover  assembly  fully

on

to

the  sector

shaft adjuster screw.

76.  Position the cover

on to the casing.

Tap home  the  cover.

If

necessary  back  off

on  the

sector  shaft

screw  to  allow

cover

t o

joint fully with the casing.

NOTE:  Before  tightening  the  fixings,  rotate  the
input  shaft  about

a  small  arc  to  ensure  that  the

sector roller is free to move in the valve worm.

78.  Fit  the  cover  fixings  and  tighten  to  the  correct

torque.

Fitting the cylinder cover

79.  Fit the square section seal to

cover.

80.  Remove the slave bolt and press the cover into the

cylinder  just  sufficient  to  clear  the  retainer  ring
groove.

26

STEERING

81.

Fit the retainer ring to the groove with  one end of
the  ring  positioned  12

(0.5

in)  approximately

from

the extractor hole.

....

Adjusting the sector shaft

82.

Set the worm  on centre by  rotating  the input  shaft

half  the total number

of  turns from either lock.

83.  Rotate  the  sector  shaft  adjusting  screw  anti-

clockwise  to  obtain  backlash  between  the  input
shaft and the sector shaft.

84.  Rotate  the  sector  shaft  adjusting  screw  clockwise

until the backlash is just eliminated.

85.  Measure  and  record  the  maximum

rolling

resistance at the input shaft, using a spring balance,
cord and torque tool

86.  Hold  still  the  sector  shaft  adjuster  screw  and

loosely fit a new locknut.

87.  Turn  in  the  sector  shaft  adjuster  screw  until  the

figure recorded

in

instruction

88

is increased  by

0,9

to 1,3

(2 to

Ib)

with the locknut tightened.

Adjusting the rack adjuster

88.  Turn  in  the  rack  adjuster  to  increase  the  figure

recorded in

90

by

to 1,3

(2 to

3 Ib). The final

figure may be less than but must not exceed
(16 Ib).

Lock  the  rack  adjuster

in  position  with  the  grub

screw.

Torque peak check

With  the  input  shaft  rotated  from  lock-to-lock,  the
rolling  resistance  torque  figures  should  be  greatest
across  the  centre  position

(1

approximately

position.

. .

from  full  lock)  and  equally  disposed  about  the  centre

The condition  depends on the value of  shimming fitted
between  the  valve  and  worm  assembly  inner  bearing
cup and the casing. The original shim washer value will

give  the  correct  torque  peak  position  unless  major
components have been replace.

NOTE:

During  the  following  ‘Procedure’,  the  stated

positioning and  direction

of  the  input  shaft  applies for

both  LH  and

boxes.  However,  the  procedures

for

shim  adjustment where  necessary,  differs  between  LH
and

steering  boxes  and

is  described  under  the

applicable LH stg. and

stg. headings.

Procedure

90.

With the input coupling shaft toward the operator,
turn the shaft fully anti-clockwise.

91.  Check  the  torque  figures  obtained  from  lock-to-

lock

using  a  spring  balance  cord  and  torque  tool

Adjustments

92.  Note  where  the  greatest  figures  are  recorded

relative  to  the  steering  position.  If  the  greatest
figures are not recorded across the centre of  travel

steering  straight-ahead  position),  adjust  as

follows:

LH  steering  models.

If  the  torque  peak  occurs

before  the  centre  position,  add  to  the  shim
washer  value;

if  the  torque  peak  occurs  after

the  centre  position,  subtract  from  the  shim
washer value.

steering  models.  If  the  torque  peak  occurs
before  the  centre  position,  subtract  from  the
shim  washer  value;

if  the  torque  occurs after

the  centre  position,  add  to  the  shim  washer
value.

Shim washers are available as follows:

and

(0.0015 in,

0.003 in, 0.005 in and 0.010 in).

NOTE:  Adjustment of

(0.003 in)  to  the  shim

value  will  move  the  torque  peak  area  by

turn

approximately on the shaft.

27

NOTE: Do not maintain this pressure for more than
30 seconds  in  any one minute  to  avoid overheating
the fluid and possibly damaging the seals.

STEERING

97.  Road test the vehicle.

KEY TO

LIGHTWEIGHT

POWER STEERING BOX

1.  Housing.

2.  Housing bushes.
3.  Seal.
4.  Back-up washer.

5 .

Back-up

6.  Circlip.
7.  Seal.
8.  Drop-arm.
9.  Tab washer.

10.  Sector shaft nut.
11.  Sector shaft and follower assembly.

12.  Seal.
13.  Bush.
14.  Cover plate.
15.  Self locking screws-4 off.
16.  Bleed screw.
17.  Locknut.
18.  Rotor seal.
19.  Seal washer.

20.  Circlip.
21.  Shims.
22.  Bearing track.
23.  Bearing case and balls.

24.  Circlip.
25.  Seal torsion bar.
26.  Rotor.
27.  Teflon rings

off.

28.  Stop-off rings.
29.  Worm.

30.

Bearing cage and balls.

31.  Bearing track.
32.  Seal.
33.  Worm adjusting screw.

Locknut.

35.  Piston.

36.

Piston

ring.

37.  Piston Teflon seal.
38.  Cylinder cover seal.
39.  Cylinder cover.
40.  Cylinder cover retainer.
41.  Screw.
42.  Rack adjusting screw.
43.  Rack adjusting screw seal.
44.
45.  Fluid line.
