Defender 90 / 110 / 130. Manual - part 61





DIESEL FUEL SYSTEM

16.

Carbon  may  be  removed  from  the  nozzle  valve

cone by inserting the valve into the tool  illustrated
and then  rotating it alternately in  a clockwise then

anti-clockwise  manner  whilst  pressing

the  valve

inward.

If

the  nozzle  is  blued  or the  seating  has

dull  circumferential ring indicating pitting or wear,
the  nozzle  body  and valve should  be  returned  to a
CAV Service Agent and replacement  parts fitted.

Do

not  attempt

to

lap  the  nozzle  valve  to  body.

This  process  requires  special  equipment  and
training.

17.  Clean the auxiliary spray hole using the special tool

fitted  with  probing  wire

in)

diameter.

NOTE:  Allow

(0.062 in)  only  to  extend

from the chuck  and thus minimise the possibility of
the wire  bending or breaking while probing.  Great
care must be  taken to prevent breakage

of  the wire

inthehole.

ST

18.  Examine

pressure

of  nozzle  body  and

nozzle  holder  to  ascertain  their  freedom  from
scoring  and  scratches.  These  surfaces  must  be

perfectly smooth.

19.  With the flushing tool secured to the nozzle testing

outfit, fit  the nozzle  body  (spray holes uppermost)
to  the  flushing  tool  and  pump  test  oil  through

vigorously.  This  flushing  process  is  necessary  for
the removal of  any tiny carbon

which may

have become lodged

in  the body after scraping and

probing.

ST

Assemble

Fit  the  nozzle  valve  to  nozzle  and  check  for

freedom of movement.

21.  Immerse  the  nozzle  body  and  valve

in

the  fluid

bath and assemble whilst submerged.

22.  Wash  the remaining components and assemble the

injector  in  the  sequence  illustrated  during  the
dismantling.

23.  Set  the  injection  nozzle  assembly  in  accordance

with  the following test procedure.

Bench test injector nozzle and holder assembly

24.

To

check a  nozzle  assembly  and to ensure that

it

is

functioning correctly, a setting outfit, as illustrated,
is  essential.  A  bench  covered  with  linoleum

or

non-ferrous  sheet  metal

is  most  suitable  for

mounting

the  outfit; such  a  surface  facilitates  the

cleanliness  essential  when  checking  nozzle  parts.
Between  the  bench  and  setting outfit,  a  tray,  also

prevent  spilt  fuel  spreading. Small  containers  may
be  attached  to the  bench  to isolate the component
parts

of  each  assembly.  These  parts  are  carefully

mated  by

t h e

manufacturers  and  must

not

be

interchanged.  Lastly,  a  small  bath  with  a  cover,
containing  Shell  Calibration  Fluid  for  washing
components, should be kept conveniently near.

37

be

positioned  to

DIESEL FUEL SYSTEM

25.

The  efficient  operation

of  the  injection  nozzle

assembly is dependent

on

four main  conditions,

as

follows:

The nozzle valve must open at

Ats.

The rate of  back  leakage must be within

150

to

100 Ats.

Seat  tightness  must  be  sufficient  to  prevent
leakage.
Spray  form  must  compare favourably  with  the
illustrations.

26.  Pressure  setting,  back  leakage  and  seat  tightness

tests may be made by coupling the injection  nozzle
and  holder  assembly  direct

to  the  pressure  feed

pipe  on  the  setting outfit,  but  an  adaptor  must  be
fitted  between  the  pipe  and  injection  nozzle  and
holder  assembly  when  testing  spray  form.  This
adaptor, see  instruction  38, increases  the  pressure
of  fuel  to  the injection  nozzle  and holder assembly

sufficiently for the main  and auxiliary spray form to
6e determined.

Test procedure

WARNING: The injection nozzle must not be allowed to
point towards the operator when spraying and the hands

must never be  allowed to contact  the spray which has a
force that can penetrate the flesh.

27.  Remove  the  cap  from  the  setting  outfit  container

and fill with

0,8 litre (1.5 pints) of  Shell Calibration

Fluid.

28.  Air  vent  the  system  by  removing  the  vent  screw,

allow

oil  to  flow  freely  for  a  few  seconds  and

replace

the

screw whilst the flow continues.

29.  Operate  the  pump  handle  until  fluid  flows  from

pipe.

30.  Connect  the  injector  and  holder  assembly  to  the

pressure  feed  pipe  with  the  nozzle  pointing
downwards.  The  length  and  bore  of  this  pipe  is
important

and  replacement  pipes  must  be

approximately  75

(2.8 in)  between  the  union

nuts and of  3

in) bore.

31.  Close  the  check  valve

to

keep

pressure  gauge

out  of  circuit  and  smartly  operate  the  hand  lever
several times

to expel all air from the system.

Leak-back test

32.  Adjustment  is  made  by  removing  the  combined

end  cap  and  locknut  from  the  nozzle  holder,  and
turning  the  adjusting  screw  clockwise  to  increase
and  anti-clockwise  to  decrease  the  opening
pressure.

33.  Fit  assembled  injector  to  nozzle  setting  outfit  and

adjust  to  open  at

160

to  170  atmospheres  then

pump

up

to

just below this figure, release handle to

allow  the  needle  of  gauge  to  fall  naturally.  Time
the  pressure  drop from

150 atmospheres  down  to

100 atmospheres.

34.  This  should  be

not  less  than

seconds  for  the

original  nozzle  and not less than

seconds if

a new

one is  to be  fitted, and  not  more  than  36 seconds
for either with

oil  temperature

to 21°C

(50" to

70°F).

38

35.  Check  externally the top and bottom  of  nozzle cap

nut  and  pressure  pipe  union  nuts  for  signs  of oil
leakage.  If  leakage  occurs  at  the  nozzle  cap  nut,

remove  the  nut  and  examine

the

pressure  faces of

nozzle  holders  and  nozzle  body  (see  item  18)  for
presence  of  foreign  matter  or  surface  scoring,
before tightening further.
A  leak-proof  nozzle  assembly  with  an  excessive

rate of pressure drop indicates a worn nozzle valve;
the  nozzle  valve  and  nozzle  body  should  be
renewed.

32

30

35

29

ST 1 1

127M

Pressure setting

36.  The  selected  operational

of  the

nozzle  valve  is  135 atmosphcrcs.  Readjust  to  this
setting in

t h e

manner described

in

32.

Seat tightness

37.  Wipe  the  bottom  face

of  the  injection  nozzle  dry

and  raise  the  pressure  in  the  system  to

125

atmospheres.  A  slight  dampness  on

bottom

face is permissible,  but  blob formation

dripping

indicates  a  badly  seating  valve  in  which  case  the
assembly  should  be  dismantled  for  further
examination.

Spray form

38.  Fuel delivery to the injection nozzle assembly when

testing spray form must be characteristically similar
to fuel delivery  under  normal operating conditions
and

to

effect  these  conditions  an  adaptor  (CAV

must  be  fitted  between  the  injection

nozzle assembly and the pressure pipe.

continued

DIESEL

FUEL

SYSTEM

I

.



39.  The  adaptor  differs  mainly  in  the  cap  nut  and

nozzle  valve  from  the  ordinary  type  of  injection
nozzle  and holder assembly as fitted to the engine;
the nozzle valve has

no

pintle.

40.  The  cap  nut  is  extended,  bored  and  threaded

receive nozzles for testing.
Connect the adaptor assembly to the pressure pipe.

42.  Remove  the  end  cap  and  adjust  the  opening

pressure

of  the nozzle valve to

220 atmospheres.

43.  Screw  the injection  nozzle  and  holder  assembly  to

be tested,

into the adaptor.

44.  With  the  check  valve  closed,  operate  the  handle

smartly to expel air from  the system. The auxiliary
spray form  may  be tested  at 60 strokes per minute
and  the  main  spray  at  140.  Spray  development
from  starting  to  running  speeds  is  illustrated,  this
illustration  should  be  referred  to  and  compared

with the spray form

of

nozzles under test.

Spray  formation  should  be  well  formed  and  free
from  splits or distortion. slight  centre 'core'  can
be  disregarded.  Observe  the  main  spray  through
360 degrees to ensure a uniform spray.

I

'



ST

45.  When  satisfactory,  fit  the  combined  locknut  and

end cap, connect  the  injectors to the  fuel  spill rail

and fit them to the engine.

FITTING FUEL

INJECTORS

The  steel  sealing  washer  fitted  below  the  injector
nozzle is to ensure that combustion does

not  take

around  the  nozzle  body  and  cause

it

to  overheat.

washer  which  has  been  used  more  than  once,  or

an

incorrectly  fitted  washer  may  cause  the  nozzle  to
overheat and result

in that cylinder misfiring.

1 .   Ensure  that  the  new  washers  are  separated  from

each other and are clean.

2.  Use  a  length  of  thin  welding  wire  to  guide

washer  only  into  each  port  with  the  domed  side
toward the injector

as illustrated.  Ensure that only

one washer is fitted

to

each port.

continued

39

DIESEL

FUEL SYSTEM

3 .

Lightly  grease  the copper washer  into position

on

each injector before fitting to the cylinder head.

4.  Fit  the  injector  and  evenly  tighten  the  retaining

nuts

to the correct torque to

(4 to

6  Ibs ft).

Uneven

or

overtightening

of

the injector nuts could

distort the nozzle and cause misfiring when  normal
running temperature is reached.

5 .

Reconnect  the  injector  pipes  but  d o   not

overtighten

union nuts.

THROTTLE PEDAL ADJUSTMENT

Petrol and Diesel four cylinder engines

1.

After  renewing  the  throttle  cable,

any

slack

in  the  cable  by  adjustment  of  the  cable

adjuster at the engine end.

2.  Depress  the  throttle  pedal,  by  hand,

the  full

extent  of  the  carburetter,  DPA

or  DPS  pump

linkage, and adjust

pedal stop screw to take up

all  clearance  between  the  screw and  scuttle  panel.
Make  sure  that

n o   strain  is  placed  upon  the

carburetter or pump linkage.

HAND THROTTLE

where fitted

Petrol and Diesel four cylinder engines

Adjust

1.  Slacken the lock nut on the cable adjuster and

the adjuster to remove all slack  from the cable and
tighten the locknut.

NOTE:  The  first  illustration  petrol  engine  and
second illustration Diesel engine.
A . )
Foot pedal cable adjuster

B.)

Hand throttle cable adjuster
