20.

Secure  the  rear  of

the  tank  with  the  two  captive

bolts, plain washer and nyloc nut.

21.  Connect the fuel feed pipe.
22.  Connect the spill return pipe.
23.  Connect  the  fuel  filter  hose  and  breather  pipe  to

24.  Fit the left-hand lashing eye.
25.

Fit

the anti-roll bar.

26.

Fit

the drop plate support bars-

if fitted.

27.  Connect the fuel gauge unit leads.
28.  Reconnect  battery,  and  check  operation  of  pump

the tank.

and change-over solenoid

if

fitted.

REMOVE SIDE TANK

FUEL PUMP

1.

2.
3.

4.

5 .
6 .

7.

Cover the pump aperture in the tank to prevent the

ingress of foreign matter.

CAUTION:  On  some  early  models  a  modification
was  carried  out  to  the  fuel  pump  to  prevent  the
possibility

of  the  contacts  earthing.  These  pumps

can  be  recognised  by

a  black  plastic  tie  clip  as

illustrated.  See  fuel  system  description.  If  the  fuel
tank only is being renewed and the original pump is
being  re-fitted,  ensure  that  the  tie  clip

is  correctly

positioned.

Refitting

8.

Insert  the  pump  and  new  sealing  washer  into  the

tank

so that the outlet pipe is directed towards the

left-hand  side

of  the  vehicle  and  the  electrical

connections to the right.

9.

Secure  the  pump  with  the  five  screws  tightening

evenly.

10.  Fit  the supply pipe  to the pump outlet and  tighten

the

clip.

the

wire

to

the  positive

terminal  and  the  black  wire  to  the  negative
terminal.

12.  Connect  the  batteries,  switch  on  ignition  and

operate the tank selection switch,

if it

is a twin tank

installation and check that the pump operates.

Move  the  vehicle

to

a  well  ventilated  area,

13.  Switch  off  ignition,  fit  the  seal  base

and

extinguish  all  naked  lights  and  disconnect  the

carpet and refit the seat cushion.

vehicle batteries.

Remove the right-hand

front seat cushion.

Move the carpet aside, where  fitted  and

and

remove the seat base cover.
Disconnect

the two Lucars from the fuel pump.

Disconnect  the fuel outlet pipe from the pump.
Remove the five retaining screws and withdraw the

pump and sealing ring.

..

33

DIESEL

FUEL SYSTEM

FUEL

INJECTORS

CHECKING

NOZZLE ASSEMBLIES

WARNING:

Do

not  allow  the fuel  spray  to  contact the

person  otherwise  injury  may  result

from  skin

penetration.

When  an  injection nozzle  is considcrcd to be t h e  cause
of  irregular  running  and  loss  of  power,  a  quick  check
may  be

by  loosening the fuel  feed pipe union  nut

on  each  nozzle  in  turn,  whilst  the  engine  is  idling  at
approximately

1,000

If  the injection nozzle assembly being checked has been
operating properly, there  will  be  a distinct  reduction

i n

engine speed accompanied  by obvious roughness, but a
faulty injection nozzle may  make little or

no

difference

to the engine note when its fuel feed pipe is loosened.

Spray check

1.  Remove  the  fuel  spill  gallery  pipe  complete  from

the injection nozzles.

2.  Disconnect

the

fuel  feed  pipe  (injection  pump  to

nozzle) from  the  nozzle  to  bc

and  from  the

injection pump.

3.

Rcleasc

t h e

fixings  and  withdraw  the  suspected

injection  nozzle  assembly;  reconnect

t h e

pipe  and

nozzle assembly to t h e  injection  pump in a position
whereby fuel ejection may be observed.

4.

5 .

6.

7.

8.

Loosen  the union  nuts securing the remaining fuel

pipes to injection  nozzles.

Whilst  the  starter  turns  the  engine  over,  observe
the manner in which fuel issues from t h e  nozzle

compare

spray  form  with  the  correct  form  as

illustrated.
Very  little  fuel  should  issue

from  the  main  spray

hole  with  the  engine  turning over  at  starter
but  a  fine  spray

to  that  illustrated

should be ejected from the auxiliary spray
If  the ejected fuel is more

in the form of a liquid jet

or issues from the main pintle hole, then the  nozzle
and  holder  assembly  should  be  removed  for
overhaul and a replacement  unit fitted.

Refit the injectors and tighten

union  nuts.

Connect

t h e

spill gallery pipe with the bolt and two

washers.

PRIME FUEL SYSTEM

Procedure following fuel filter or sedimentor service

When  models  fitted  with  a  sedimentor  have  had
water  drained  only  from  the  sedimentor  bowl,  no
priming  is  necessary

as

t h e

water  is  replaced  by  fuel

automatically syphoned  from

tank. However, if  the

sedimcntor has been dismantled and

has entered the

body,

or  where

the

fuel  filter  element  has  been

replaced  and  the  filter  bowl  cleaned,  then  the  system
must be primed  as follows:

NOTE:  The  above illustration shows the  D.P.A.  pump

to

the 3.25 iitre diesei engine.

34

DIESEL

FUEL SYSTEM

.....

1.  D o  not  attempt to start the engine hoping to draw

. .

...

the  fuel  through

in  this  way,  othcrwisc  the  full

priming procedure will be necessary.

2.  Slacken  the bleed  pipe banjo bolt

on the top of  the

main fuel filter.

....

..

.I.

...

3.  Operate the hand priming lever on  the mechanical

pump, until fuel free from bubbles emerges.
Always  ensure  that  fuel  pump  lever  is  on  the
bottom  of the operating cam when  priming the fuel

system,  otherwise  maximum  movement  of  the
priming lever cannot be achieved.

4.  Tighten the bleed  pipe  banjo bolt  whilst  the

is

still emerging.

5 .

Operate  the  hand  priming  lever  once  or twice  to

clear  t h e   last  bubbles  of  air  into  the  filter  bleed
pipe.

6.  Start engine in normal way and check for leaks.

Procedure when fuel system has been drained

7.  Carry out instructions  1 to inclusive.

I . .

...

8.  Release air

v e n t

screw on distributor body.

..

...

..

Illustration  A

- 2.25 litre D.P.A. pump

Illustration

- 2.5 litre D.P.S. pump

.....

9.  Operate  t h e   fuel  pump  hand  priming  lever  until

fuel free

of  air

Rctighten the air vent screw.

11.

To ensure that all air is exhausted from the pump

i t

may  also  be

to

slacken  air vent  screw  in

the

distributor

control

cover

and

repeat

instructions

9  and  10.  2.25  litre  engine  D.P.A.

pump

only.

12.  Start

engine  in  the  normal  way  and  check  for

leaks.

Procedure when distributor pump has been drained

13.  Carry out instructions

8 to 12 inclusive.

FUEL INJECTION PUMP

Altitude compensation

When  Diesel  engines are operated  at high  altitude

it

is

recognised  that  the  reduced  air  density  causes  a
reduction  i n   the  weight  of  air  drawn  into  the  engine

cylinders,  which  results

combustion  of

the injected  fuel at full throttle,

this is

in

proportion  to the reduction

in air density.

compensate  for

variations  and  to  avoid

excessive  fuel  consumption,  accompanied  by  excessive
exhaust  smoke,  the  amount  of  fuel  delivered

to  the

cylinders  must  be  reduced  to suit  the conditions under
which  the  engine  is  required  to  operate.

For  every

330 metres

feet)  above

990 metres

(3000

feet)

the fuel delivery must be reduced by

3%.

Adjustments

to

the  D.P.S. pump,  however,  must  only

be carried-out by  an authorised C.A.V. Dealer.

DIESEL FUEL

SYSTEM

OVERHAUL

Service tools:
271483 or

or

12.  Clean the three

oil feed passages in the nozzle body

,,:

with a wire or drill

of

1,5

(0.062

in) diameter.

--

13.  Remove  the  carbon  from  the  annular  recess  with

the

tool illustrated.

FUEL INJECTORS

Injector nozzle testing and setting kit

Adaptor Pintaux Injector

Diesel tune

278182 or

or

Diesel tune

102

Injector nozzle flushing tool

Injector nozzle cleaning kit

278181

or

605002 or

or

DISMANTLE

1.  Remove the injectors from the engine.

2.  Disconnect

the injectors from the fuel spill rail.

3.  Remove the combined locknut and end cap.
4.

Withdraw the sealing washer.

---

5.  Unscrew the pressure adjusting screw.

7.  Withdraw the valve spindle.
8.  Unscrew the cap nut.
9.  Withdraw the nozzle valve and body.

6.

Withdraw  the pressure spring.

ST

1107M

14.  Remove the carbon  from  the valve  seat, using  the

appropriate tool with a rotary motion.

15.  Select  the appropriate  size  probe from  t h e  pocket

of  cleaning  kit  and  secure  it  in  the  pintle  hole
cleaner.

Insert the probe into the bore

of  nozzle valve body

and allow the end to extend through  the main fuel
outlet,  then  turn  in  a  rotary  manner  to  remove

carbon.

ST

Cleaning and inspecting

10.  Soak the component parts

of

the assembly

in Shell

Calibration Fluid to loosen carbon deposits, but do
not  allow  parts

of  any  one  assembly  to  be

interchanged with those

of another.

11.  Brush  away  all  external  carbon  deposits  from

component parts with a brass wire brush and return
them  to  the  fluid  bath.  Particular  care  must  be
exercised  when  cleaning  the  pintle  and  seat  of
nozzle  valve  to  avoid  scratching or  scoring,  which

could result

in

spray distortion.

15

ST

continued

36
