Defender 90 / 110 / 130. Manual - part 56





FUEL S

YSTEM

19

17

PETROL FUEL SYSTEM

Fit throttle lever assembly

47.

Fit  the  return  spring  so  that  the  longest  leg  rests

against

the throttle adjusting screw housing.

48.  Fit  the  throttle  adjusting  lever  and  lost  motion

assembly and tension the return spring.

49.

Fit the throttle actuating lever.

50.  Fit the bush washer and lock washer.

Fit  and  tighten  the  special  nut  and  bend  the  lock
tabs over a

flat.

Fit jet and float assembly

52.  Fit the jet bearing, long end towards the float.
53.  Fit the jet bearing nut.
54.  Clean

renew  the  filter  and

fit

the  float  needle

seat.

55.  Fit the needle valve, spring loaded pin uppermost.
56.  Fit the float and secure with the pivot pin.
57.  Hold  the  carburetter

in

the  inverted  position  so

that the needle valve  is closed  by  the weight

of  the

float  only.  Check  using  a  straight  edge  that  t h e

point  o n  the  float,  arrowed  on  the  illustration,  is

t o

1.5

to

0.062 in) below  the  level of

the float chamber face? dimension ‘A’.

58.  Adjust  the  float  position  by  carefully  bending  the

brass  pad

until

the

correct dimension  is  achieved.

After adjustment, check  that  the float pivots freely
about the spindle.

56

18

continued

FUEL SYSTEM

59.

Assemble  the  jet

to  the  bi-metal  jet  lever  and

ensure  that  the

jet  head  moves  freely  in  t h e

cut-out.

60.

Fit  the jet and bi-metal jet lever to the carburetter

and  secure  with  the  spring  loaded  jet  retaining
screw.

...

61.  Fit the mixture adjustingscrew.

19

62.  Adjust  the  mixture screw  until  the jet  is  flush  with

the  carburetter  bridge,  then  turn  the  scrcw  a
further three and one half turns clockwise.

63.  Using  a  new  sealing  ring.

the  float  chamber

cover,  noting  that

it

can  only  be  fitted  one  way.

with  the four screws and spring washers  and

evenly tighten.

. ..  ,

Fit

piston and suction

chamber

Fit  the  needle,  spring  and  guide  assembly  to  the

piston  ensuring that  the  etched  arrow  head  on  the
needle locating guide is aligned  between  the piston
transfer holes, as illustrated.

65.

Secure and ensure that when

screw is  tightened

the guide

is

flush with  the piston  and that the scrcw

locates in

the guide slot.

66.

Fit  the  piston

to

the  carburetter  body  using  a

new screw. Tighten

scrcw and splay the end.

67.  Fit  a  new  suction  chamber  sealing  ring  to  the

groove in the carburetter body.

68.  T

prevent

piston  spring  being  'wound-up'

during  assembly,

fit

the  piston  and

suction  chamber  less

spring  to  the  body,  and

pencil  mark  the  relationship of

t h e

chamber  to the

body.  Remove  the  suction  chamber  and

fit

the

spring  to  the  piston.  Hold  the  suction  chamber
above t h e  spring and piston, align  the pencil  marks
and  lower the chamber

the spring and piston,

taking

not  to  rotate  the  suction  chamber.

Secure  the  chamber  to  the  body

with

the  three

tightening evenly and check  that  the piston

moves freely.

69.  Hold  the  piston  at  the  top of  its  stroke  and

fit

the

spring clip.

70.  Fit t h e  piston  damper.
71.  Using a n e w  joint washer,

fit

the air intake adaptor

and secure

with

two nuts and spring washers.

72.  Fit  the carburetters to

inlet  manifold  ensuring

that  the joint  washers,

and  insulator  are

fitted

in  the  sequence  illustrated.  The  insulator

must  be fitted  with  the  arrow

uppermost  and

pointing  inwards  towards  the  manifold.  Secure
with  the  four  nuts  and  spring washers  and  tighten
evenly

to the correct torque.

A .   Joint washer.

Deflector-teeth pointing inwards.

C .  Joint washer.

Insulator.

E.  Joint washer.

continued

PETROL FUEL SYSTEM

72

73.  Connect

linkages  and  top-up  the  carburetter

dampers

with

a recommended oil  to the  top of  the

hollow piston rod.

74.  Tune and adjust the carburetters.

TUNE AND ADJUST

SU HIF 44 CARBURETTERS

Special tools:

Carburetter balancer

605330 or

B89

Non-dispersive infra-red  exhaust gas anaiyscr

General Requirements Prior to Tuning Carburetters.

Accurate  engine  speed  is  essential  during  carburetter
tuning,

the  distributor  pick  up  air  gap  and

ignition  timing  must  be  checked  together  with  the
vacuum advance system.

Whenever possible  the  ambient air temperature  of  the
tuning environment should be between

to

26°C

(60"

to

80°F).  When  checking  engine  speed,  use  an

independent  and accurate tachometer.
Idling  adjustments  should  be  carried  out  on  a  fully

warmed  up engine,  that  is,  at  least

minutes after the

thermostat  has  opened.  This should  be  followed  by

run

of  one  minute  duration  at  an  engine  speed  of

approximately

2,500

before

further

adjustments or checks are carried  out. This cycle  may

20

be  repeated  as  often  as  required.

It  is  important  that

the  above

is  adhered  to,  otherwise  overheating

may  result  and  settings  may  be  incorrect.  The  piston
dampers  must  always  be  kept  topped-up  with  the
correct grade of oil.
Before  any  attempt  is  made

to

check  settings  a

thorough check should be carried out to ensure that the
throttle  linkage  between  the  pedal  and  carburetters is

free  and  has  n o   tendency  to  stick.  Ensure  that  the
choke control lever

is pushed fully down.

NOTE: References to left and right hand are as from the
drivers seat.

TAMPER -PROOFING

To comply with  E.C.E.  regulations  the  idle speed  and
mixture  adjusting  screws  must  be  tamper

proofed

following  any  adjustments.  A  red  blanking  plug;  Part

number

JZX  1258  must  be  fitted  into  the  mixture

and  a  red  cap;  Part  number

JZX  1197

fitted  over  the  idle  adjustment  screw  (throttle
adjustment screw).

continued

...
