Defender 90 / 110 / 130. Manual - part 42





2.50

LITRE

DIESEL ENGINE

FIT CYLINDER

FEED

FIT

HEATER PLUGS

..

...

...

. .

. .

1.  Connect  the  oil  feed  pipe,  for  lubrication

of

the

2.  Secure  with  the  two  banjo  bolts  and  four  join!

1.  Clean  and test  the heater plugs as described

in  the

maintenance  Section.  Fit  the  heater

plugs

and

tighten  to the correct torque.

Do not over tighten.

2.  Fit  the  leads,  washers  and

nuts  as  illustrated,

ensuring  that

cable  eyelet  is  fitted  vertically

downwards  to  prevent  heat  from  cylinder  head
damaging the cable insulation.

rocker shaft assembly,

to

cylinder head

washers.

FIT FUEL LIFT

PUMP

1.  If  the fuel lift was separated from the side cover, fit

the pump to t h e  cover first using a new joint washer
between  the  pump  flange  and  rear  cover,  evenly

tighten the retaining nuts.

2.  Place  a  new  cover  plate  joint  washer  in  position

and fit the cover and pump assembly to the cylinder
block.

3.

Ensure that  the  pump actuating lever rides on  top

of t h e  camshaft.

4.

Secure

t h e

cover,  evenly  tightening  the  retaining

bolts.

FIT OIL FILTER AND ADAPTOR

1.

Using  a  new  joint  washer  fit

oil  filter adaptor.

Ensure  that  the  retaining  bolts  pass  through  the
two small round holes in the joint washer.

2.  Tightcn  the  two  retaining  bolts  evenly  to  the

correct torque.

3 .

Smear a little clean

oil on the rubber washer

of

new filter, then  screw the filter on clockwise

until  the rubber  sealing  ring touches the  machined

Do

not  overtighten.  See Maintenance  Operations,

section

10.

continued

87

2.50

LITRE DIESEL ENGINE

RENEW

TEMPERATURE THERMOSTAT

Used when an oil cooler is fitted.

1.

Remove  the  two  bolts  and  carefully withdraw  the

2.

Remove

t h e

ring.

3.

Withdraw the thermostat.

4.  Remove the washer.
5 .   Remove the spring.
6.  Clean the adaptor housing with lint-free cloth.
7.  Fit the spring and washer.
8.  Fit a new thermostat with  the pin  uppermost.
9.  Fit  the  extension  housing  using  a  new

ring.

Ensure t h a t

the

pin  protruding from

thermostat

locates

in

the hole

in

extension housing.

thermostat extension  housing.

10.  Secure the housing

with

the two bolts and washers.

FIT VACUUM PUMP

1.  Place  a  new  joint  washer  on  the  cylinder  block

2.

Fit

the

D.P.S.

pump control bracket.

3.

Insert  the  vacuum  pump drive  shaft

into the skew

gear  coupling  ensuring  that  the  shaft  engages
properly  over  the  cross  pins  in  the  coupling.  The
hose connection  should be  towards the front of  the
engine.

4.  Secure  the  pump  and  control  bracket  to  the

cylinder block  with  the three socket headed screws.

face.

5 .   Connect  the

D.P.S.  pump  control  rod  to  the

control bracket lever.

88

LITRE

DIESEL ENGINE

FIT THE FUEL INJECTORS

AND

PIPES

Fit the injectors

The  steel  sealing  washer  fitted  below  the  injector

is

to ensure that combustion does not  take place

around  the  nozzle  body  and  cause

it

to  overheat.

washer  which  has  been  used  more  than  once,  o r   an
incorrectly  fitted  washer  may  cause  the  nozzle  to
overheat and result in that cylinder misfiring.

1.  Ensure  that  the  new  washers  are  separated  from

each other and are clean.

2.  Use  a  length  of  thin  welding  wire  to  guide  one

washer  only  into  each  port  with  the  domed  side
toward the injector  as illustrated. Ensure that only
one washer is fitted to each port.

3 .   Lightly  grcasc the  copper  washer  into  position  o n

each injector before fitting to the cylinder head.

4.

Fit  the  injector  and  evenly  tighten  the  retaining
nuts

to

the

correct

torque.

Uneven

or

overtightening of the injector nuts could distort the

nozzle  and  cause  misfiring  when  normal  running
temperature is reached.

Fit

the injector pipes

2.

Fit  t h e

pipes  to  the  injectors  and

D.P.S.

pump.  Counting  from  the  front

of  the  engine

connect the pipes as follows:
A .

To number 1 injector.

To number

2 injector.

C.

To number

injector.

To

injector.

Do

not overtighten the union  nuts.

FIT THE STARTER MOTOR

1.  Fit  the  starter  motor  to  the  flywheel  housing  and

secure with:
a)

one stud and

n u t

b) one single bolt
c) one nut and bolt.
Evenly tighten to the correct torque.

continued

89

2.50 LITRE DIESEL ENGINE

FIT THE

AIR INTAKE AND EXHAUST MANIFOLDS

1.  Using  a  new

fit

the  manifolds  and  secure

with  the retaining nuts and clamps. Evenly  tighten

to

the specified torque

2.

Connect the breather hose to the oil filler cap.

ST

1550

Turbo-charged engines

3.

Fit a new gasket

the cylinder head.

4.  Fit

air  intake  manifold  and  evenly  lighten  the

bolts

to the correct torque.

2.  Secure  the  rear  of  the  motor  t o  the  bracket  with

two bolts and tighten to the correct torque.

5.

Fit  the exhaust  manifold  and secure  with  the  four

socket headed bolts and clamps.

90
