Defender 90 / 110 / 130. Manual - part 31





2.25

LITRE

PETROL AND DIESEL CYLINDER HEAD

_-

94.  Using a new gasket

f i t

the rocker cover and secure

with

the  rubbers, cups and dome nuts. Tighten

to

the correct torque figure.

Do

not over-tighten.

A .

Petrol.

Diesel

107.  Refit

or  reconnect  the  items  disturbed  for

to

the cylinder head.

108.

Refill  the cooling  system  when  engine  is  refitted

to vehicle.

95.  Fit  the  inlet  and  exhaust manifolds complete with

carburetter (petrol engine).

Engine overhaul.

96.

Fit  the  air  intake  and  exhaust  manifolds  (diesel

enginc). See Engine overhaul.

97.

Fit the spark plugs (petrol engine).

98.  Fit the injectors- see Diesel fuel system.
99.  Fit

engine lifting

Fit the water temperature sensor.

Fit

the thermostat  housing assembly

101.

a  new  joint  washcr  secure

thermostat

housing to the by-pass housing.
Fit

two

adaptors.

103.  Inscrt the

into its housing.

joint washer on the

head.

105.  Using  n e w  joint washer f i t   the thermostat cover

and cowl mounting bracket.

Using

bolts

the  complete

assembly to the cylindcr  head.  Note  that  one bolt
is shorter and is fitted in-board.

43

2.5

LITRE PETROL ENGINE

2.5

LITRE PETROL ENGINE

SUPPLEMENT T O  THE

2.25

LITRE PETROL

ENGINE OVERHAUL PROCEDURES

This  S u p p l e m e n t   should  b e   used  in  conjunction  with  t h e

litre  petrol  engine  overhaul  procedures.

Details

of

the

differences between t h e

and

2.5

litre engines

are

listed below.

Some

of the new features

were, however, introduced o n  later

2.25

pctrol engines.

Capacity  increased

to  2495

by  lengthening  the

piston  stroke from 89

to

97

Crankshaft  and  main  bearings  same  as  the  2.5  litre
Diesel engine.

squirt hole in connecting rods deleted.

pistons with controlled expansion skirts.

Camshaft

as

2.5 litre Diesel engine.

Camshaft sprocket similar to 2.25  litre petrol engine,

but  with  a  single  keyway  positioned  to  alter  the
exhaust value peak from 109”

to

Inserts fitted

to exhaust valve seats

in

cylinder head.

New

timing chain tensioner assembly

Modified  oil  pump

with

gear  having

only  ten  teeth.

Bush deleted from idler gear and ball ommitted from
the pressure  relief valve.

The

ring  scal  between  t h e   flywheel  housing  and

cylinder  block  deleted.  Sealing  now  achieved  by  a
bead  of  sealant on  the  flywheel  housing mating  face
with the cylinder block.

Sump joint washer deleted and a liquid sealant,

RTV

102, now used.

The  Lucas  45  D4  sliding  contact  distributor  now
used.

44

2.5

LITRE PETROL ENGINE

REMOVE AND OVERHAUL OIL

PUMP

Dismantle oil pump

1.  Remove the sump.

2.  Bend  back  the  lock  washers  and  remove  the  two

bolts  securing  the

oil  pump

to  the  crankcase.

Withdraw

the oil  pump complete with  strainer and

oil pump drive shaft.

3.  Bend  back  the  lock  washer  and  release  the  nut

securing

the  strainer

to  the  oil  pump  body  and

remove the strainer and sealing ring.

4.  Remove  four bolts  and  washers  and  lift  off  the oil

pump cover and

lift

out t h e  driven and idler gears.

(a)  driven gear
(b)

gear

5 .

Remove  the  oil  pressure  relief  valve  plug  and

sealing  washer.  Withdraw  the  relief  valve  spring
and plunger.

Overhaul the oil pump

6.  Examine the gears for wear, scores and  pits.  If  the

gears  appear  serviceable  check  for  end-float  as
follows:

7.

Clean  the  pump  body  and  assemble

t h e

gears.

Place a straight edge across the pump body face, as
illustrated,  and  using  a  feeler gaugc,  measure  the

clearance  between  the  body  and  gears  and  the
backlash  between the

The correct clearances

are given

in Data.

8.

Gears  must

renewed

in  pairs.

worn,  but

serviceable  gear,  must

not  be  matched

with

a new

one.

9.  If necessary  renew idler gear spindle by  drilling-out

the  peened  over  end  of  the  spindle

so  that  the

spindle can  be withdrawn  from the pump  body.

To

ensure  squareness  when  fitting  the  new  spindle,
assembie

pump body

the

gears.

Fit  the  cover  and  secure  with  the  four  bolts.

Support  the  pump  body  and  peen  over  the  end  of
the  new  spindle. Remove  the cover  and  gears and
check security of  the spindle.

45

2.5

LITRE PETROL ENGINE

Assemble the oil pump

10.  Fit the idler gear to the spindle.
11.  Fit  the  driven  gear  with  plain  part

of  the  bore

uppermost.

See illustration after instruction

9.

12.  Smear

joint  face

of  the  body  with  jointing

compound  and  fit  the  cover  over  the  dowels  and
secure

the

lour bolts and spring washers.

13.  Hold  relief  valve  bore  vertically  and  insert

plunger  with  the  solid  end  first.

Fit  the  spring,

sealing washer and plug.

14.

Fit  the

oil  strainer  sealing  ring  to  the  pump  body

by  the  lock  washer and strainer. Tighten

the  strainer  retaining  nut

so  that  when  fitted  the

strainer  is  positioned  parallel  to  the  sump  baffle
plate. Secure the nut with the lock washer tab.

REMOVE  AND  OVERHAUL  THE  TIMING  CHAIN
SPROCKETS AND TENSIONER

1.  Remove the bolts and withdraw the timing cover.

2.  Before  removing  the  timing  chain  tensioner  check

dimension  'A',  which  with  a  new  chain  and
sprockets  should

be

(0.5

in)

approximately.  This will  give an indication

of  chain

wear. The dimension for a fully worn chain is 27
(1.06 in).

3.  Remove the three bolts  and whilst  holding the pad

inwards,  t o   prevent  it  falling  apart,  remove
tensioner asscmbly.

4.  Remove timing chain damper.

5.

Remove  the  camshaft  sprocket  retaining  bolt  and

washer.

6.  Withdraw  the  camshaft  sprocket  together  with  the

timing  chain  and  crankshaft  sprocket.  If  necessary
use special tool 507231.
