MAINTENANCE

ADJUST

DUCELLIER  DISTRIBUTOR

4-cylinder

Petrol engine

Service

tool:

1861308

Check and Adjust Dwell Angle

NOTE:

The  following  six  instructions  can  only  be

carried  out  using  engine  diagnostic  equipment  and

special

1.  Start the engine, disconnect the vacuum  pipe from

the  vacuum  unit  and  with  the  engine idling  check
the  dwell  angle

see  data.  If  adjustment  is

required  stop  the  engine,  remove  the  distributor
cap,  rotor  arm  and  dust  cover,  slacken  the  fixed
contact retaining screw and using the eccentric-post
end  of  the  special  tool,  as  illustrated,  make  an
appropriate  adjustment.  Tighten  the  retaining

screw,  reassemble  the  distributor  and  recheck  the

dwell angle.

Check and adjust dwell variation

NOTE:  A dwell variation outside the accepted tolerance

see data

can  be  caused  by  a  mechanical  fault  or

wear  within  the  distributor.

This

may  be  checked  as

follows:

2.  Disconnect  the  vacuum  advance,  start  the  engine

and  increase  the  speed to

2000

A  variation

outside  the  tolerance  given  in  data  indicates  that
the distributor has a mechanical  fault which cannot

be rectified by adjustment.

7.

reconnect

vacuum  pipe,  start  the  engine  and  increase  the
engine  speed  to

2,000

and  release  the

throttle. Check the dwell variation and

if  necessary

adjust  by  tuming  the  eccentric

‘D’

post  with  the

special tool  (female

‘D’ end). Setting the dwell for

variation  may  alter  the basic  setting and

this

must be rechecked at idle speed.

16

Check vacuum advance

NOTE:

the  vacuum  unit  has  been  removed

or  the

distributor  dismantled,  the  vacuum  advance  must  be
checked and if necessary adjusted.

4.  Disconnect the vacuum pipe and connect a vacuum

pump to the unit.

5.

Start and  run  the engine at idle speed  and using  a
timing  light,  slowly  increase  the  vacuum  and  note
the  point  at  which  vacuum  advance  starts  and

compare the figure with that given in data.

6.

Adjustment  of  the  serrated  cam, with  the  special
tool,  one  tooth  at  a  time,  will  alter  the  point  at

which vacuum advance starts.

MAINTENANCE

RENEW  LUCAS  CONTACT  BREAKER  SLIDING
CONTACTS

4-cylinder petrol engine

The  contact  set  should  be  renewed  every  40.000

(25,000

miles).

Remove the old contacts

1.  Remove the distributor cap.

2.  Remove the rotor arm.

Remove the retaining screw and lift the contact set

4.  Press  the  contact  set  spring  and  release  the

complete from the plate.

terminal plate and leads from the spring.

Fit

new contacts

5 .

6.

7.

8.

9.

10.

Clean  the  points  with  petrol  to  remove  the
protective coating.
Press  the  contact  spring  and  fit  the  terminal  plate

with the black lead uppermost.
Fit  the  contact  set  to  the  moving  plate,  ensuring
that  the peg,  underneath the contact  pivot, locates
in the hole in the moving plate.
The sliding contact actuating fork  must  also locate

over the fixed peg.
Loosely  secure the  assembly with  the

plain

and spring washer.
Check that the contact  leaf spring locates properly
in the insulation shoe.

Adjust gap

11.

13.

14.

Rotate  the  crankshaft  until  the  contact  heel

on

the highest point

of  a cam.

Adjust  the  gap  by  inserting  a  screwdriver  blade
between  the

shaped notch and pip and twist the

screwdriver.
Insert  a

to

(0.014 to

0.016

in) feeler

gauge between the points and adjust to a sliding fit
and tighten the retaining screw.
Fit the rotor arm.

RENEW DISTRIBUTOR CONTACT SET

engine

Fixed contact type

2.
3.

4.

5 .
6.

and remove the distributor cap.

Withdraw the rotor arm.
Remove the contact breaker spring anchor nut and

lift off:
(a)  the top-half

of  insulation bush

(b)  the low tension  lead (black)
(c)  the capacitor lead (orange)
Remove the contact breaker retaining screw, plain

and  spring  washer  and  remove  contact  set
assembly.
Remove the complete insulation bush.
Fit  the contact  breaker set  ensuring that  the

post protruding from below  the contact set locates
through the hole in  the cover plate into the hole in
the end of  the vacuum  unit actuating lever, secure
with the screw, plain and spring washers.

continued

17

MAINTENANCE

7.

Assemble  the  contact  breaker  spring  insulating
bushes  and  electrical  leads,  as  illustrated,

in

the

following sequence:
(a)  lower bush

(b)  spring
(c)

tension lead

(d)  capacitor lead
(e)  top bush

and secure with the anchor spring nut.

cam lubrication pad.

8.

Apply  a  few  drops of  engine oil  to  the  distributor

Sliding contact type

Adjust points -both types

9.

Turn  the  engine  in  the  direction  of  rotation  until
the  contacts  are  fully  open  or  the  heel  of  the

contact set is on the highest  point of  the cam.

10.  Using  a  feeler gauge  and  the  dwell  angle  adjuster

on

the  side

of  the  distributor,  set  the  points  to  a

nominal gap of

to

(0.014 to

0.016

in).

11.

At

earliest  opportunity  check  and  adjust  the

dwell  angle

see  data

using

turning

equipment.
Fit the rotor arm  and  distributor  cap ensuring that
the

H.T.

pick-up brush moves freely.

1.  Release the clips and remove the distributor cap.

2.  Remove the rotor arm from the cam spindle.
3.  Remove  the  retaining  screw  and  washers  and  lift

the  complete  contact  breaker  assembly  from
moveable plate.

4.  Remove  t h e   nut  and  plastic  bushes  from  the

terminal post to release the leads and spring.

5.

Discard the old contact breaker assembly.

6.

Clean  the  new  points  with  petrol  to  remove  the

7.

Connect  the  leads  to  the  terminal  post  in  the

protective coating.

following sequence:

(b)

red lead tab

(c)  contact breaker spring eye
(d)  black lead tab

(e)  upper plastic bush
(f)  retaining nut.

the two pegs locate in the holes.

(a)  lower plastic bush

8.

Fit the contact set to the moving plate ensuring that

MAINTENANCE

CLEAN

AND

LUBRICATE

V8

ENGINE

DISTRIBUTOR

Fixed contact type

1.  Remove distributor cap.

2.  Remove rotor arm.
3.  Lightly smear the cam with clean engine oil.

Add a few drops of thin machine oil to lubricate the

5.

Wipe  the inside  and outside of  the distributor cap

6.

Ensure  that  the  carbon  brush  works  freely  in  its

7.  Refit rotor arm and distributor cap

cam bearing and distributor shaft.

with a soft dry cloth.

holder.

Sliding contact type

1.  Remove distributor cap.

2.  Remove rotor arm.
3.  Lightly smear the cam with clean engine oil.

4.  Add a few drops of  thin machine oil to lubricate the

cam bearing and distributor shaft.

5 .   Wipe the inside  and outside

of

the distributor cap

with a soft dry cloth.

6 .

Ensure  that  the  carbon  brush  works  freely

in

its

holder.

7.  Lubricate the actuator ramps  and  contact breaker

heel ribs with Shell Retinax or equivalent grease.

8.

Grease the underside

of

the heel actuator.

CLEAN

AND

LUBRICATE

DUCELLIER

DISTRIBUTOR

1.  Remove the distributor cover and lift

off

the rotor

arm and anti-dust shield.

2.  Inspect the contact breaker points; if  burnt or

they should be renewed.

3.

Very  lightly  smear  the  cam  with  grease

Shell

Retinax.

4.  Lubricate  the  pressure  pad  with  grease

Shell

Retinax.

5.  Add a few drops

of

oil to the felt pad in the top

of

the cam spindle.

6.

the  engine  until  the  distributor  centrifugal

weight  pivot  post  is visible  through  the cut-out  in
the  base  plate  and lubricate the pivot  post  with  a
drop

of

oil. Repeat for the opposite pivot post.

7.  Carefully  wipe  away  all  surplus  lubricant;  and

ensure  that  the  contact  breaker  points  are  clean
and dry.

8.

Fit the anti-dust shield.

9.  Refit the rotor  arm, engage the slot in the spindle

and push down firmly.

10.

Wipe clean with dry nap-free  cloth, the inside and

outside

of  the  distributor  cover,  particularly

between  the  electrodes,  and  fit  the  distributor
cover.

9.  Apply grease to the fixed pin and actuator fork.

CLEAN

ENGINE  ELECTRONIC  IGNITION

DISTRIBUTOR

10.  Refit rotor arm and distributor cap.

80.000

(48,000

miles)

Remove  the  distributor  cap  and  rotor  arm  and  wipe
inside with a nap-free cloth.

DO NOT DISTURB

the  clear  plastic  insulating cover

which protects the magnetic pick-up module.
