Defender (1993+). Manual - part 6





TORQUE

WRENCH SETTINGS

REAR AXLE AND FINAL DRIVE

Nm

Crown wheel to differential case

..........................................

160

Rear cover to axle case

.......................................................

24

Ball joint mounting bracket to axle case

...............................

133

Drum to hub

.........................................................................

18

Rear brake assembly and stub axle rear to axle

..................

65

Universal Joint flange

to

propeller shaft

...............................

47

Hub driving member to hub

..................................................

65

PROPELLER SHAFTS

Coupling flange bolts

...........................................................

46

REAR SUSPENSION

Bottom link to chassis nut

....................................................

176

Bottom link to mounting rubber

............................................

64

Top link bracket to chassis

...................................................

47

Shock absorber bracket to chassis

......................................

64

Anti

roll bar bush to chassis nuts

.........................................

24

Upper link ball joint to axle castle nut

...................................

176

Anti roll bar ball joint castle nut

............................................

40

Bump stop rubber bracket nuts

............................................

32

Shock absorber upper attachment to bracket

......................

82

Shock absorber lower attachment nuts

................................

75

Tie bar to mounting arm nut

.................................................

81

Mounting arm to chassis nuts

..............................................

176

STEERING AND FRONT SUSPENSION

Tie bar to steering box nuts

.................................................

81

Panhard rod to mounting arm nut

........................................

88

Panhard rod

to

anchor bracket nut

......................................

88

Panhard rod mounting bracket to chassis bolts

...................

123

Drop arm to drag link castle nut

...........................................

81

Steering damper to drag link nut

..........................................

50

Drop arm to steering box nut

...............................................

176

Radius arm to axle nuts

.......................................................

176

Steering box to chassis nuts

.............................................

    81

Track rod clamp bolt nuts

.....................................................

14

Drag link clamp bolt nuts

......................................................

14

Steering wheel retaining nut

................................................

30

Road wheel nuts

..................................................................

108

Ball  joint  nuts

........................................................................

41

Radius arms to chassis nuts

................................................

176

Collapsible coupling nuts

.....................................................

25

REISSUED:

FEB

1993

TORQUE WRENCH SETTINGS

POWER ASSISTED STEERING

Nm

Mounting bracket to front cover

...........................................

25

Mounting plate

to

mounting bracket

.....................................

25

Pulley to P A S  pump

...........................................................

P.A.S pump

to

mounting bracket

.........................................

25

P.A.S box

16

mm thread

......................................................

20

P.A.S pump union

................................................................

20

Mounting bracket

to

cylinder block

.......................................

25

P.A.S box  14 mm thread

......................................................

15

P.A.S pump Jubilee clips

.....................................................

Brake caliper to swivel housing

............................................

100

Servo. primary port

..............................................................

13

Servo. secondary port

..........................................................

13

Jump hose

female

.............................................................

15

Wheel cylinders to back plate

..............................................

11

'G' valve

...............................................................................

10

'G' valve to bracket

..............................................................

13

Master cylinder

to

servo nuts

...............................................

14

Servo to bulkhead nuts

........................................................

14

BRAKES

Brake disc to hub

.................................................................

72

Brake pipe connections to:

ELECTRICAL EQUIPMENT

Alternator:

Shaft nut

.......................................................................

60

Through bolts

................................................................

Rectifier bolts

................................................................

3,5

Starter motor to engine bolts

................................................

44

Starter motor:

Through bolts

................................................................

10,8

Solenoid fixing stud nut

.................................................

Solenoid upper terminal nut

..........................................

Reverse light switch

.............................................................

24

Lucas

35

DM8 Electronic ignition distributor

Pick up bearing plate support pillars

....................................

1,2

Pick up barrel nuts

...............................................................

1,2

AIR

CONDITIONING

Adaptor plate

to front cover

..................................................

45

Compressor mounting bracket

to

adaptor plate

...................

45

Compressor to mounting bracket

.........................................

45

Adjusting link to mounting bracket & compressor

................

45

Belt damper

to front cover plate

...........................................

36

Pulley to Torsional Vibration damper

...................................

25

Mounting plates

to

compressor

............................................

25

REISSUED: FEB 1993

GENERAL FITTING INSTRUCTIONS

PRECAUTIONS AGAINST DAMAGE

PREPARATION

1.

Always  fit  covers  to  protect  wings  before

1.

Before removing a component, clean

it

and

its

commencing work  in engine compartment.

surrounding areas as thoroughly as  possible.

2.

Cover  seats  and  carpets,  wear  clean  overalls

2.

Blank

off

any

openings

exposed

by

and  wash  hands  or  wear  gloves  before

component  removal,  using  greaseproof  paper

working inside car.

and masking tape.

3.

Avoid  spilling  hydraulic fluid or  battery acid on

3.

Immediately  seal  fuel,  oil  or  hydraulic  lines

paint work.  Wash

off  with  water  immediately

if

when  separated,  using  plastic  caps  or  plugs,

this  occurs.  Use  Polythene  sheets  in  boot  to

to

prevent

loss of  fluid and entry of  dirt.

protect carpets.

4.

Close  open  ends  of  oilways,  exposed  by

4.

Always  use  a  recommended Service

Tool,  or

component  removal,  with  tapered  hardwood

a satisfactory equivalent, where specified.

plugs or  readily visible plastic  plugs.

5.  Protect

temporarily

exposed  screw threads  by

5.

Immediately a component  is removed, place

it

replacing nuts or  fitting plastic caps.

in  a  suitable  container;  use  a  separate

container  for  each  component  and  its

SAFETY  PRECAUTIONS

(See  also  SECTION

01

associated parts.

Poisonous Substances)

6.

Before  dismantling  a  component,  clean

it

thoroughly  with  a  recommended  cleaning

1.

Whenever  possible  use  a  ramp  or  pit  when

agent;  check  that  agent  is'  suitable  for  all

working  beneath  vehicle,  in  preference

to

materials of  component.

jacking.  Chock  wheels  as  well  as  applying

7 .

Clean  bench  and  provide  marking  materials,

hand brake.

labels,  containers  and  locking  wire  before

2.  Never  rely  on  a jack  alone to  support  vehicle.

Use  axle  stands  or  blocks  carefully  placed at

jacking points

to

provide rigid location.

3.

Ensure that a suitable form

of

fire extinguisher

is conveniently located.

1.

Observe

scrupulous

cleanliness

when

4.

Check  that  any  lifting  equipment  used  has

dismantling  components,  particularly  when

adequate capacity and is

fully  serviceable.

brake, fuel or  hydraulic system parts are being

5.  Inspect  power  leads  of  any  mains  electrical

worked  on.  A  particle

of  dirt  or  a  cloth

equipment  for  damage  and  check  that

it

is

fragment

could

cause

dangerous

properly earthed.

6.

Disconnect  earth  (grounded)  terminal  of

2.

Blow  out  ail  tapped  holes,  crevices,  oilways

vehicle battery.

and  fluid  passages  with  an  air  line.  Ensure

7 .

Do  not  disconnect

any

pipes  in  air

that  any  O-rings used for  sealing are  correctly

conditioning  refrigeration  system,  if  fitted,

replaced or  renewed,

if

disturbed.

unless  trained  and  instructed

to

do

so.

3.

Mark  mating  parts  to  ensure  that  they  are

refrigerant is used which can cause blindness

replaced  as  dismantled.  Whenever  possible

if allowed to contact eyes.

use  marking  ink,  which  avoids  possibilities

of

8.

Ensure  that  adequate  ventilation

is

provided

distortion or  initiation of  cracks,  liable

if

centre

when  volatile  degreasing  agents  are  being

punch

or  scriber  are used.

used.

4.

Wire  together  mating  parts  where  necessary
to  prevent  accidental  interchange  (e.g.  roller

WARNING:  Fume  extraction  equipment

bearing components).

must

be in operation when trachloride,

5.  Wire  labels  on  to  all  parts  which  are  to  be

methylene

chloride,

chloroform

or

renewed,  and  to  parts  requiring  further

perchlorethylene  are

used

for  cleaning

inspection

before

being

passed

for

purposes

reassembly;  place  these  parts  in  separate
containers  from  those  containing  parts  for

9.

Do  not  apply  heat  in  an  attempt  to  free  stiff

rebuild.

nuts

or

fittings;  as  well  as  causing damage to

6.

Do  not  discard  a  part  due  for  renewal  until

protective coatings,  there  is  a  risk  of  damage

after  comparing  it  with  a  new  part,  to  ensure

to  electronic  equipment  and  brake  lines  from

that  its  correct  replacement

has

been

stray heat.

obtained.

10.

Do

not

leave

tools,

equipment,  spilt  oil  etc.,

around or

on work  area.

11.

Wear  protective  overalls  and  use  barrier
creams when necessary.

dismantling a component.

DISMANTLING

malfunction

if

trapped in these systems.

REISSUED:

FEB

1993

GENERAL

FlTTlNG

INSTRUCTIONS

INSPECTION - GENERAL

it

could  be  established  that  damage  was

1.

Never  inspect  a  component  for  wear  or

9.

When  fitting  bearing to  shaft,  apply  force  only

dimensional  check  unless

it

is  absolutely

to  inner  ring of  bearing, and only  to  outer  ring

clean;  a  slight  smear  of  grease  can  conceal
an incipient failure.

2.

When  a  component  is  to  be  checked
dimensionally against figures quoted for  it,  use
correct

equipment

(surface

plates,

micrometers, dial  gauges, etc.)  in  serviceable

condition.  Makeshift  checking  equipment  can

be dangerous.

3.

Reject  a  component

if

its  dimensions  are

outside  limits  quoted,  or

if

damage  is

apparent.  A  part  may,  however,  be  refitted  if

4.  Use plasti-guage 12  Type PG-1  for  checking

bearing  surface  clearances; directions for its

confined to

it

only.

when fitting into housing.

its critical dimesnion is exactly limit size, and

10.

In the case of grease-lubricated  bearings (e.g.

hub  bearings)  fill  space  between  bearing  and
outer  seal with  recommended grade of  grease
before fitting seal.

use, and a scale  giving bearing clearances in

11.

Always

mark  components  of

separable

0,0025

mm steps are provided with it.

bearings  (e.g.  taper  roller  bearings)

in

dismantling,  to  ensure  Correct  reassembly.

Never

fit

new rollers in a used cup.

BALL AND  ROLLER  BEARINGS

NEVER

REPLACE

A BALL OR ROLLER BEARING

O

I

L  SEALS

WITHOUT

FIRST ENSURING THAT

IS IN

A FULLY

SERVICABLE  CONDITION

1.

Always  fit  new  oil  seals  when  rebuilding  an
assembly.  It  is  not  physically  possible  to

1.

Remove  all  traces  of  lubricant  from  bearing

replace  a  seal  exactly  when

it

has  bedded

under  inspection  by  washing

in  petrol  or  a

down.

suitable

degreaser;

maintain

absolute

2.

Carefully  examine seal  before fitting to  ensure

cleanliness throughout operations.

that it is clean and undamaged.

2.  Inspect  visually  for  markings  of  any  form  on

3.

Smear  sealing  lips  with  clean  grease;  pack

rolling  elements,  raceways,  outer  surface  of

dust  excluder  seals

with

grease,  and  heavily

outer  rings  or  inner  surface  of  inner  rings.

grease duplex  seals  in cavity  between sealing

Reject  any  bearings  found  to  be  marked,

lips.

since  any  marking  in  these  areas  indicates

4.

Ensure  that  seal  spring,  if  provided,  is

onset of  wear.

correctly fitted.

Holding  inner  race between finger  and  thumb

5.

Place  lip  of  seal  towards  fluid  to  be  sealed

of  one hand, spin outer  race

and

check that

it

and  slide  into  position  on  shaft,  using  fitting

revolves absolutely  smoothly,  Repeat,  holding

sleeve  when  possible  to  protect  sealing  lip

outer race and spinning inner race.

from  damage  by  sharp  corners,  threads  or

4.

Rotate  outer  ring  gently  with  a  reciprocating

splines,  If  fitting  sleeve  is  not  available,  use

motion,  while  holding  inner  ring;  feel  for  any

plastic  tube

or

adhesive  tape  to  prevent

check  or  obstruction  to  rotation,  and  reject

damage to sealing lip.

bearing if action is not perfectly smooth.

5.

Lubricate  bearing  generously  with  lubricant
appropriate to installation.

6.

Inspect  shaft  and  bearing  housing  for
discolouration  or  other  marking  suggesting

that  movement  has  taken  place  between

bearing  and  seatings.  (This  is  particularly  to

be

expected if  related markings were  found in

operation

2.)

If  markings  are  found,  use

'Loctite'  in installation of  replacement bearing.

7.

Ensure  that  shaft  and  housing  are  clean  and

free from burrs before fitting bearing.

8.

I f  one bearing of a pair shows an imperfection

it

is

generally  advisable  to  renew  both

bearings:  an  exception  could  be  made

if

the

faulty bearing had covered a low mileage, and

REISSUED: FEB 1993

is  otherwise  satisfactory.















Content   ..  4  5  6  7   ..
