Connector: C1267

Description: RH fender harness to main harness

Location: Rear RH side of engine compartment





Part No.:

YPC10468



Colour: GREY

Cavities: 10WY

Harness:

WING RH HARNESS



Wire Chart

CAV  TERMINAL  CSA  COL  CCT  DESTN

1

YPJ10008

1.5D

UO

ALL C0011

2

YPJ10008

1.5D

UB

ALL C0011

3

YPJ10008

1.5D

B

1

C0011

3

YPJ10008

1.5D

B

2

C0011

3

YPJ10008

1.5D

B

3

C0011

3

YPJ10008

1.5D

B

5

C0011

4

DBP8550

0.75D GW

ALL C0002

5

DBP8550

0.5D

RO

4

C0537

5

DBP8550

0.5D

RB

3

C0537

6

DBP8550

0.75D PB

4

C0004

7

DBP8550

0.5D

RO

1

C0070

7

DBP8550

1.0D

UO

3

C1008

7

DBP8550

1.0D

UO

5

C1008

8

DBP8550

0.5D

UY

1

C0070

9

YPJ10008

1.5D

NW

6

C0014

10

YPJ10008

1.5D

NG

6

C0014

Service Repair Kits




CSA

0.30- 1.25 CSA

Cavities: 4,5-8

VDK500010 SRK ITEM GENERAL

1

YMI500070

SRK ITEM HW090/HM090 SEALED FAMILY 1.0CSA 1

YPQ000100 SRK ITEM

1

YRV000040 SRK ITEM PIDG RED

1

YRW000390 SRK ITEM

1

YRW500010 SRK ITEM

1

VUB500580

Connector: C1269

Description: Relay-Blower

Location: Beneath RH Front seat





Part No.:

AGU1383



Colour: GREEN

Cavities: 5WY

Harness:

MAIN LH + RH HARNESS



Wire Chart

CAV  TERMINAL  CSA  COL  CCT  DESTN

30

AFU3120

1.0D U

14R

CTAP

30

AFU3120

1.0D U

14L

CTAP

85

AFU3119

0.5D BS

14

CTAP

86

AFU3120

1.0D B

14

C0279

87

AFU3120

1.0D B

14

S/JOINT SJ14 (M)

87A

AFU3120

1.0D U

14R

CTAP

87A

AFU3120

1.0D U

14L

CTAP

Service Repair Kits

Connector: C1305

Description: Chassis harness to trailer harness

Location: Below RH rear wheelarch





Part No.:

YPC114850



Colour: GREY

Cavities: 9WY

Harness:

CHASSIS HARNESS



Wire Chart

CAV  TERMINAL  CSA  COL  CCT  DESTN

1

YPL101830

1.5D GR

772

CTAP

2

YPL101830

1.5D RB

772

C0140

3

YPL101830

1.5D GW

772

C1756

4

YPL101830

1.5D RO

772

C0489

5

YPL101830

1.5D GP

772

CTAP

6

YPL101700

3.0D P

772

C1765

7

YPL101830

1.5D GN

772

C1763

8

YPL101830

1.5D RY

772

C1763

9

YPL101700

2.0D B

772

C2120

Service Repair Kits

Connector: C1401

Description: Seat-heat

Location: Beneath LH Front seat





Part No.:

YPC110710



Colour:

Cavities:

Harness:

MAIN LH + RH HARNESS



Wire Chart

CAV  TERMINAL  CSA  COL  CCT  DESTN

1

YPJ100640

0.75D US

766

C0250

2

YPJ100620

0.5D

B

766

S/JOINT SJ12

Service Repair Kits
