Defender Electric Diagrams. Manual - part 241

Connector: C1217

Description: Fuse box

Location:





Part No.:

YPC802120



Colour: BLACK

Cavities: 2WY

Harness:

MAIN LH + RH HARNESS



Wire Chart

CAV  TERMINAL  CSA  COL  CCT  DESTN

1

YPL801890

4.0D NW

200R CTAP

1

YPL801890

4.0D NW

139L CTAP

2

YPL801890

4.0D NS

499

C0151

Service Repair Kits

Connector: C1264

Description: Main harness to LH fender harness

Location: Rear LH side of engine compartment





Part No.:

YPC10549



Colour: GREY

Cavities: 14WY

Harness:

MAIN LH + RH HARNESS



Wire Chart

CAV  TERMINAL  CSA  COL  CCT  DESTN

1

YPL10027

1.5D

US

200R C0581R

1

YPL10027

1.5D

US

139L C0581L

2

YPL10027

1.5D

UK

139L C0581L

2

YPL10027

1.5D

UK

200R C0581R

3

YPL10027

1.5D

B

499

C0550

4

DBP8548

0.5D

GR

499

C0287

5

DBP8548

0.5D

RB

499

C0288

6

DBP8548

0.75D PB

499

C0287

7

DBP8548

1.0D

RO

107

C0286

8

DBP8548

1.0D

OB

22L

C0731L

8

DBP8548

1.0D

OB

22R

C0731R

9

DBP8548

1.0D

B

22

CTAP

10

DBP8548

0.5D

B

22

C0285

11

DBP8548

0.5D

B

22

C0286

12

DBP8548

0.5D

LGB 499

C0285

13

DBP8548

0.5D

BLG 499

C0073

14

DBP8548

1.0D

UY

107

C0093

Service Repair Kits




CSA

0.30- 1.25 CSA

Cavities: 4,5-14

YMI000010

SRK ITEM 090 FAMILY 1.5CSA 1

YPQ000100 SRK ITEM

1

YQD000210 SRK ITEM R/B

1

YRV000040 SRK ITEM PIDG RED

1

YRW000390 SRK ITEM

1

YRW500010 SRK ITEM

1

VUB001120



Connector: C1265

Description: LH fender harness to main harness

Location: Rear LH side of engine compartment





Part No.:

YPC10469



Colour: GREY

Cavities: 14WY

Harness:

WING LH HARNESS



Wire Chart

CAV  TERMINAL  CSA  COL  CCT  DESTN

1

YPJ10008

1.5D

US

ALL C0009

2

YPJ10008

1.5D

UK

ALL C0009

3

YPJ10008

1.5D

B

ALL C0009

4

DBP8550

0.75D GR

ALL C0001

5

DBP8550

0.5D

RB

ALL C0538

6

DBP8550

0.75D PB

2

C0003

6

DBP8550

0.75D PB

3

C1913

7

DBP8550

1.0D

UO

5

C1007

7

DBP8550

0.5D

RO

1

C0071

7

DBP8550

1.0D

UO

3

C1007

8

DBP8550

1.0D

OB

7

C0520

9

DBP8550

1.0D

B

6

C0666

10

DBP8550

0.5D

B

6

C0666

11

DBP8550

0.5D

B

6

C0666

12

DBP8550

0.5D

LGB ALL C0008

13

DBP8550

0.5D

BLG ALL C0021

14

DBP8550

0.5D

UY

1

C0071

Service Repair Kits




CSA

0.30- 1.25 CSA

Cavities: 4,5-14

VDK500010 SRK ITEM GENERAL

1

YMI500070

SRK ITEM HW090/HM090 SEALED FAMILY 1.0CSA 1

YPQ000100 SRK ITEM

1

YRV000040 SRK ITEM PIDG RED

1

YRW000390 SRK ITEM

1

YRW500010 SRK ITEM

1

VUB500580

Connector: C1266

Description: Main harness to RH fender harness

Location: Rear RH side of engine compartment





Part No.:

YPC10633



Colour: GREY

Cavities: 10WY

Harness:

MAIN LH + RH HARNESS



Wire Chart

CAV  TERMINAL  CSA  COL  CCT  DESTN

1

YPL10027

1.5D

UO

139L C0581L

1

YPL10027

1.5D

UO

200R C0581R

2

YPL10027

1.5D

UB

139L C0581L

2

YPL10027

1.5D

UB

200R C0581R

3

YPL10027

1.5D

B

499

C0550

4

DBP8548

0.5D

GW

499

C0287

5

DBP8548

1.0D

RO

200R C0581R

5

DBP8548

1.0D

RO

139L C0581L

6

DBP8548

0.75D PB

499

C0287

7

DBP8548

1.0D

RO

107

C0286

8

DBP8548

1.0D

UY

107

CTAP

9

YPL10027

1.5D

NU

254R CTAP

10

YPL10027

1.5D

NG

765R C0048

Service Repair Kits




CSA

0.30- 1.25 CSA

Cavities: 4,5-8

YMI000010

SRK ITEM 090 FAMILY 1.5CSA 1

YPQ000100 SRK ITEM

1

YQD000210 SRK ITEM R/B

1

YRV000040 SRK ITEM PIDG RED

1

YRW000390 SRK ITEM

1

YRW500010 SRK ITEM

1

VUB001120
