Defender Electric Diagrams. Manual - part 169

C1264

CONNECTOR

DEFENDER 1999 MY

Main harness to wing
harness

Female
GREY

Adjacent pedal box

P5564

C0075

C0029

C1264

C0667

C1265

Cav

Col

CCT

1

US

ALL

2

UK

ALL

3

B

ALL

4

GR

ALL

5

RB

ALL

6

PB

ALL

7

RO

27

Cav

Col

CCT

8

OB

15

9

B

ALL

10

B

15

11

B

15

12

LGB

ALL

13

BLG

ALL

14

UY

27

CONNECTOR

C1266

DEFENDER 1999 MY

Wing harness to main
harness - LH

Male
GREY

Adjacent pedal box

P5564

C0075

C0029

C1264

C0667

C1265

Cav

Col

CCT

1

US

ALL

2

UK

ALL

3

B

25

3

B

27

4

GR

ALL

5

RB

ALL

6

PB

ALL

7

RO

27

Cav

Col

CCT

8

OB

27

9

B

27

10

B

27

11

B

27

12

LGB

ALL

13

BLG

ALL

14

UY

27

C1266

CONNECTOR

DEFENDER 1999 MY

Main harness to wing
harness - RH

Female
GREY

Adjacent heater assembly

P5563

C1267

C0056

C1266

Cav

Col

CCT

1

UO

ALL

2

UB

ALL

3

B

ALL

4

GW

ALL

5

RO

ALL

6

PB

ALL

7

RO

27

8

UY

27

9

NW

25

10

NG

25

CONNECTOR

C1267

DEFENDER 1999 MY

Wing harness to main
harness - RH

Male
GREY

Adjacent heater assembly

P5563

C1267

C0056

C1266

Cav

Col

CCT

1

UO

ALL

2

UB

ALL

3

B

ALL

4

GW

ALL

5

RO

ALL

6

PB

ALL

7

RO

27

8

UY

27

9

NW

27

10

NG

27
